DRPC-W-TGL
MODEL:
DRPC-W-TGL Series
Fanless System with Intel® Tiger Lake-U Processors, Triple 2.5GbE LAN, HDMI,
DP, 8GB Memory Pre-installed, 12V DC and RoHS
User Manual
Page I
Rev. 1.00 – January 19, 2023
[MODEL NAME]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRPC-W-TGL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology DRPC-W-TGL Series

Summary of Contents for IEI Technology DRPC-W-TGL Series

  • Page 1 DRPC-W-TGL MODEL: DRPC-W-TGL Series Fanless System with Intel® Tiger Lake-U Processors, Triple 2.5GbE LAN, HDMI, DP, 8GB Memory Pre-installed, 12V DC and RoHS User Manual Page I Rev. 1.00 – January 19, 2023 [MODEL NAME]...
  • Page 2 DRPC-W-TGL Revision Date Version Changes January 19, 2023 1.00 Initial release Page II [MODEL NAME]...
  • Page 3 DRPC-W-TGL Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 DRPC-W-TGL Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. NOTE These messages inform the reader of essential but non-critical information.

  • Page 5: Table Of Contents

    DRPC-W-TGL Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 F ........................3 EATURE 1.3 M ....................3 ODEL ARIATIONS 1.4 T ..................4 ECHNICAL PECIFICATIONS 1.5 F ......................5 RONT ANEL 1.6 T ......................... 5 ANEL 1.7 P ....................
  • Page 6 3.14.3 AT/ATX Power Mode Setting ................. 43 4 SYSTEM MOTHERBOARD ..................44 4.1 P ..............45 ERIPHERAL NTERFACE ONNECTORS 4.1.1 DRPC-W-TGL Series Layout ................45 4.1.2 Peripheral Interface Connectors ..............45 4.1.3 External Interface Panel Connectors ............... 46 4.2 I ..............47 NTERNAL ERIPHERAL ONNECTORS 4.2.1 Battery Connector ....................
  • Page 7 DRPC-W-TGL 4.2.11 Power Button Connector ................61 4.2.12 Reset Button Connector ................. 62 4.2.13 RS-232 Serial Port Connector ............... 63 4.2.14 RS-232/422/485 Serial Port Connector ............64 4.2.15 SATA 6Gb/s Drive Connector ................ 65 4.2.16 SATA Power Connector .................. 66 4.2.17 SMBus/I C Connector ..................
  • Page 8 DRPC-W-TGL 5.3.5 RTC Wake Settings ................... 99 5.3.6 Serial Port Console Redirection ..............101 5.3.6.1 Console Redirection Settings ..............103 5.3.7 NVMe Configuration ..................106 5.4 C ......................... 107 HIPSET 5.4.1 System Agent (SA) Configuration ..............108 5.4.1.1 Memory Configuration ................109 5.4.1.2 Graphics Configuration ................
  • Page 9 DRPC-W-TGL List of Figures Figure 1-1: DRPC-W-TGL Series ....................2 Figure 1-2: Front Panel ........................5 Figure 1-3: Top Panel ........................5 Figure 1-4: Physical Dimensions ....................6 Figure 3-1: Remove the Cover .....................14 Figure 3-2: Take out the Disk Bracket ..................14 Figure 3-3: HDD Installation ......................15...
  • Page 10 DRPC-W-TGL Figure 3-27: USB Connection ......................28 Figure 3-28: Digital I/O Connector Location ................28 Figure 3-29: M.2 B key Slot Location ..................29 Figure 3-30: M.2 A-key Slot Location ..................31 Figure 3-31: USB Connector Location ..................33 Figure 3-32: iDPM Slot Location ....................34 Figure 3-33: Audio Connector Location ..................36 Figure 3-34: Power Input &...
  • Page 11 DRPC-W-TGL Figure 4-24: USB 3.2 Gen 2 Port Pinouts ...................73 Figure 4-25: IEI Resource Download Center ................76 Figure 5-1: BIOS Starting Menu ....................78 Figure 5-2: BIOS On-screen Navigation Keys ................80 Figure 5-3: BIOS Options and Configured USB Ports ............114 Page XI [MODEL NAME]...
  • Page 12 DRPC-W-TGL List of Tables Table 1-1: DRPC-W-TGL Series Model Variations ............... 3 Table 1-2: Technical Specifications ....................4 Table 3-1: RJ-45 Ethernet Connector LEDs ................26 Table 3-2: Power Connector Pinouts ..................27 Table 3-3: Digital I/O Connector Pinouts ..................29 Table 3-4: M. 2 B key Slot Pinouts ....................31 Table 3-5: M.2 A-Key Slot Pinouts ....................33...
  • Page 13 DRPC-W-TGL Table 4-18: SMBus Connector Pinouts ..................67 Table 4-19: USB Connector Pinouts ...................68 Table 4-20: HDMI Connector Pinouts ..................70 Table 4-21: DP Connector Pinouts ....................71 Table 4-22: LAN Pinouts ......................72 Table 4-23: RJ-45 Ethernet Connector LEDs ................72 Table 4-24: USB 3.2 Gen 2 Port Pinouts ..................73 Table 5-1: BIOS Navigation Keys ....................79 Page XIII [MODEL NAME]...
  • Page 14 DRPC-W-TGL BIOS Menus BIOS Menu 1: Main (1/2) .......................82 BIOS Menu 2: Main (2/2) .......................82 BIOS Menu 3: Advanced ......................85 BIOS Menu 4: CPU Configuration (1/3)..................86 BIOS Menu 5: CPU Configuration (2/3)..................87 BIOS Menu 6: CPU Configuration (3/3)..................87 BIOS Menu 7: PCH-FW Configuration ..................90 BIOS Menu 8: F81966 Super IO Configuration ................91 BIOS Menu 9: Serial Port 1 Configuration Menu ...............92 BIOS Menu 10: Serial Port 2 Configuration Menu ..............93...
  • Page 15 DRPC-W-TGL BIOS Menu 31: Save & Exit ......................123 Page XV [MODEL NAME]...

  • Page 16: Introduction

    DRPC-W-TGL Chapter Introduction Page 1...

  • Page 17: Overview

    The DRPC-W-TGL Series is an embedded system for wide range temperature environments. It is powered by Intel® Tiger Lake-U processor, and pre-installed 8GB DDR4 SO-DIMM memory (up to 32GB). The DRPC-W-TGL Series includes two HDMI, one DP, three 2.5GbE LAN ports, four USB 3.2 Gen2 ports, and one external fan connector.

  • Page 18: Feature

    1 x M.2 A Key ▪ 1 x M.2 B Key (with SIM card slot) 1.3 Model Variations The model variations of the DRPC-W-TGL Series are listed below (Table 1-1). Model No. Intel ® Celeron™ 6305 1.8GHz DRPC-W-TGL-U-CC-R10 (dual core, TDP 15W) Intel ®...

  • Page 19: Technical Specifications

    DRPC-W-TGL 1.4 Technical Specifications The DRPC-W-TGL Series technical specifications are listed in Table 1-2 Model Name DRPC-W-TGL-U-i7C-R10 DRPC-W-TGL-U-I5C-R10 DRPC-W-TGL-U-i3C-R10 DRPC-W-TGL-U-CC-R10 Color Black Dimensions 176x116x67.8 （WxDxH)(mm） Chassi Fanless System Fan Chassis Construction Extruded aluminum alloys Intel® Core™ i7-1185G7E Intel® Core™ i5-1145G7E Intel®...

  • Page 20: Front Panel

    DRPC-W-TGL 1.5 Front Panel The front panel of the DRPC-W-TGL Series has the following features. Figure 1-2: Front Panel 1.6 Top Panel The top panel of the DRPC-W-TGL Series is shown below. Figure 1-3: Top Panel Page 5...

  • Page 21: Physical Dimensions

    DRPC-W-TGL 1.7 Physical Dimensions The physical dimensions are shown in Figure 1-4. Figure 1-4: Physical Dimensions Page 6...

  • Page 22: Unpacking

    DRPC-W-TGL Chapter Unpacking Page 7...

  • Page 23: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the DRPC-W-TGL Series. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the DRPC-W-TGL Series or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 24: Unpacking Checklist

    If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the DRPC-W-TGL Series from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@ieiworld.com.
  • Page 25 DRPC-W-TGL Quantity Item and Part Number Image Standard Chassis screws The following table lists the optional items that can be purchased separately. Optional Wi-Fi module (P/N: EMB-WIFI-KIT02I3-R10) VGA module (P/N: iDPM-VGA-R10) Serial cable (P/N: 32005-003500-200-RS) GPIO cable (P/N: 32031-000600-100-RS) Power adapter (P/N: 63040-010060-211-RS) Page 10...
  • Page 26 DRPC-W-TGL Optional Power cord (P/N: 32000-000002-RS) * Each Wi-Fi module needs two antennas and two RF cables to fully support Wi-Fi function. Page 11...

  • Page 27: Installation

    DRPC-W-TGL Chapter Installation Page 12...

  • Page 28: Installation Precautions

    Electric shock and personal injury might occur if the rear panel of the DRPC-W-TGL Series is opened while the power cord is still connected to an electrical outlet.

  • Page 29: Cover Removal

    Loosen the four screws and remove the hard disk bracket (Figure 3-2). Figure 3-2: Take out the Disk Bracket 3.4 Storage Installation The DRPC-W-TGL Series supports two types of storage, one M.2 B Key & one 2.5" SSD Page 14...

  • Page 30: Inch Ssd Installation

    DRPC-W-TGL 3.4.1 2.5-inch SSD Installation Put the hard disk bracket on the hard disk, secure the bracket with 4 screws, and connect the SATA cable Install the hard disk and bracket back to the host (Figure 3-3). Figure 3-3: HDD Installation 3.4.2 M.2 SSD Installation To install an M.2 B Key NVME, please follow the steps below.

  • Page 31: Wi-Fi Module Installation (Optional)

    DRPC-W-TGL Step 4: Secure the M.2 module with the previously removed retention screw (Figure 3-5). Figure 3-5: Securing the M.2 Module 3.5 Wi-Fi Module Installation (Optional) The Wi-Fi module is an optional accessory. You can purchase it from IEI or other providers.

  • Page 32: Figure 3-7: Securing The Wlan Module

    DRPC-W-TGL Figure 3-7: Securing the WLAN Module Step 5: Connect the two RF cables to the antenna connectors on the WLAN module (Figure 3-8). Figure 3-8: Connecting RF Cables Step 6: Remove the nut and washer from the SMA connector at the other end of the RF cable.

  • Page 33: Expansion I/O Installation (Optional)

    Figure 3-9: Securing SMA Connector and External Antenna Installation 3.6 Expansion I/O Installation (Optional) The DRPC-W-TGL Series has reserved GPIO port, serial port, iDPM slot for function expansions. Optional cable or module are ready for purchase. To install these expansion components, follow the steps below.

  • Page 34: Gpio Installation

    DRPC-W-TGL Figure 3-11: Knock out the reserved holes 3.6.2 GPIO Installation Step 1: Locate the GPIO port connector. Step 2: Connect the GPIO cable to the GPIO connector on the mainboard. Figure 3-12: Connect the GPIO cable to the GPIO connector Step 3: Knock out the reserved holes on the chassis and Secure the DB15 end of the GPIO cable to the panel.

  • Page 35: Idpm Installation

    DRPC-W-TGL Figure 3-13: Knock out the reserved holes 3.6.3 iDPM Installation Step 1: Locate the iDPM module slot. Step 2: Remove the retention screw secured on the motherboard. Step 3: Line up the notch on the module with the notch on the slot. Slide the iDPM module into the socket at an angle of about 20º...

  • Page 36: Figure 3-15: Securing The M.2 Module

    DRPC-W-TGL Figure 3-15: Securing the M.2 Module Step 5: Connect the VGA cable to the VGA connector on the iDPM module. Figure 3-16: Connect the VGA cable to the VGA connector Step 6: Knock out the reserved holes on the chassis and Secure the DB15 end of the VGA cable to the panel.

  • Page 37: Cover Installation

    3.8 System Fan Installation (Optional) When encountering high performance and high heat, additional cooling was needed. The optional external fan can help the DRPC-W-TGL Series solve the thermal problem. To install the optional external fan, follow the steps below. Step 1: Remove the 4 screws (2 on the front panel, 2 on the rear panel) on the DRPC-W-TGL Series as shown in the figure below.

  • Page 38: Mounting Brackets Installation

    DRPC-W-TGL Figure 3-19: External Fan Module Installation 3.9 Mounting Brackets Installation DRPC-W-TGL Series comes with DIN-RAIL mounting bracket, follow the steps below to install. Step 1: Turn the embedded system over. Step 2: Align the retention screw holes in each bracket with the corresponding retention screw holes on the bottom surface.

  • Page 39: Figure 3-21: Secure The Brackets

    DRPC-W-TGL Step 3: Secure the brackets to the system by inserting retention screws into each bracket. Figure 3-21: Secure the brackets Step 4: Attach the upper edge of the mounting bracket at an angle. Push the system towards the DIN rail until mounting bracket hangs securely. Figure 3-22: Mounting the system Page 24...

  • Page 40: External Peripheral Interface Connectors

    DRPC-W-TGL 3.10 External Peripheral Interface Connectors The DRPC-W-TGL Series has the following connectors. Detailed descriptions of the connectors can be found in the subsections below. ▪ Ethernet ▪ Power button ▪ Power DC jack ▪ HDMI ▪ ▪ 3.10.1 HDMI/DP Connector...

  • Page 41: Figure 3-24: Lan Connection

    DRPC-W-TGL Figure 3-24: LAN Connection Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable RJ-45 connector into the on-board RJ-45 connector The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the port is linked.

  • Page 42: Power Connector

    Table 3-2: Power Connector Pinouts Figure 3-26: Power Connector 3.10.4 USB 3.2 Gen 2 (10Gb/s) Connectors The DRPC-W-TGL Series have four USB 3.2 ports. To connect a USB device, please follow the instructions below Step 1: Located the USB connectors. The locations of the USB connectors are shown in...

  • Page 43: Internal Peripheral Interface Connectors (Optional)

    DRPC-W-TGL Figure 3-27: USB Connection 3.11 Internal Peripheral Interface Connectors (Optional) 3.11.1 Digital I/O Connector CN Label: DIO1 CN Type: 14-pin header, p=2.00 mm CN Location: See Figure 3-28 CN Pinouts: See Table 3-3 The 12-bit digital I/O connector provides programmable input and output for external devices.

  • Page 44: Slot, B-Key

    DRPC-W-TGL PIN NO. DESCRIPTION PIN NO. DESCRIPTION DOUT5 DOUT4 DOUT3 DOUT2 DOUT1 DOUT0 DIN5 DIN4 DIN3 DIN2 DIN1 DIN0 Table 3-3: Digital I/O Connector Pinouts 3.11.2 M.2 Slot, B-key CN Label: M2_1 CN Type: M.2 B-key slot CN Location: Figure 3-29 791H CN Pinouts: See Table 3-4...
  • Page 45 DRPC-W-TGL PIN NO. DESCRIPTION PIN NO. DESCRIPTION CONFIG_3 +3.3V +3.3V POWER_OFF USB_D+ W_DISABLE USB_D- DAS/DSS# Module Key Module Key Module Key Module Key Module Key Module Key Module Key Module Key CONFIG_0 GNSS_DISABLE PCIE_RXN1 UIM_RST PCIE_RXP1 UIM_CLK UIM_DATA PCIE_TXN1 UIM_VCC PCIE_TXP1 DEVSLP PCIE_RXN0...

  • Page 46: Slot, A-Key

    DRPC-W-TGL WWAN_RST PEDET +3.3V +3.3V +3.3V CONFIG_2 Table 3-4: M. 2 B key Slot Pinouts 3.11.3 M.2 Slot, A-key CN Label: M2_A1 CN Type: M.2 A-key slot CN Location: See Figure 3-30 CN Pinouts: See Table 3-5 The M.2 slot is keyed in the A position and accepts 2230 size of M.2 modules. The M.2 slot supports PCIe x2 and USB 2.0 signals.
  • Page 47 DRPC-W-TGL Description Description +V3.3A USB+ +V3.3A USB- Module Key Module Key Module Key Module Key Module Key Module Key Module Key Module Key PCIE_TX0+ PCIE_TX0- PCIE_RX0+ PCIE_RX0- CLK_PCIE0+ CLK_PCIE0- BUF_PLT_RST# PCIE_CLKREQ# Pull Up +V3.3A PCIE_WAKE# Pull Up +V3.3A PCIE_TX1+ PCIE_TX1- PCIE_RX1+ Page 32...

  • Page 48: Usb 2.0 Connector

    DRPC-W-TGL Description Description PCIE_RX1- CLK_PCIE1+ +V3.3A CLK_PCIE1- +V3.3A Table 3-5: M.2 A-Key Slot Pinouts 3.11.4 USB 2.0 Connector CN Label: USB3 CN Type: 8-pin header, p=2.00 mm CN Location: See Figure 3-31 CN Pinouts: See Table 3-6 The USB connector provides two USB 2.0 ports by dual-port USB cable. Figure 3-31: USB Connector Location PIN NO.

  • Page 49: Idpm1 Display Connector

    DRPC-W-TGL 3.11.5 IDPM1 Display Connector CN Label: IDPM CN Type: 75-pin slot, p=0.5 mm CN Location: Figure 3-32 791H CN Pinouts: See Table 3-7 Figure 3-32: iDPM Slot Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V +3.3V +3.3V +3.3V Module Key Module Key Module Key...

  • Page 50: Table 3-7: Idpm Connector Pinouts

    DRPC-W-TGL DISPLAY_DETECT_PIN23 +3.3VS +3.3VS EDP_TX3_DN +12VS EDP_TX3_DP +12VS +12VS EDP_TX2_DN +12VS EDP_TX2_DP SMB_CLK EDP_TX1_DN SMB_DATA EDP_TX1_DP EC_BKLT_CTRL EDP_TX0_DN EDP1_BKLT_CTRL EDP_TX0_DP EDP1_BKLT_EN EDP1_VDD_EN # EDP_AUX_DN EDP_HPD_R EDP_AUX_DP BUF_PLT_RST# LVDS_EN +V5S +V5S +V5S +V5S +12VA +12VA +12VA +12VA Table 3-7: iDPM Connector Pinouts Page 35...

  • Page 51: Audio Connector

    DRPC-W-TGL 3.11.6 Audio Connector CN Label: IAUDIO1 CN Type: 10-pin header, p=2.00 mm CN Location: See Figure 3-33 CN Pinouts: See Table 3-8 The audio connector is connected to external audio devices (AC-KIT-888S-R10) including speakers and microphones for the input and output of audio signals to and from the system.

  • Page 52: Powering On/Off The System

    DRPC-W-TGL 3.12 Powering On/Off the System WARNING: Make sure a power supply with the correct input voltage is being fed into the system. Incorrect voltages applied to the system may cause damage to the internal electronic components and may also cause injury to the user. The power of the system needs more than 12V5A Step 1: Connect the power source to the power input jack.

  • Page 53: Available Drivers

    DRPC-W-TGL Figure 3-35:Power Button 3.13 Available Drivers All the drivers for the DRPC-W-TGL Series are available on IEI Resource Download Center (https://download.ieiworld.com). Type DRPC-W-TGL Series and press Enter to find all the relevant software, utilities, and documentation. Figure 3-36: IEI Resource Download Center...

  • Page 54: Driver Download

    To download drivers from IEI Resource Download Center, follow the steps below. Step 1: Go to https://download.ieiworld.com . Type DRPC-W-TGL Series and press Enter. Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result.

  • Page 55: Maintenance

    DRPC-W-TGL NOTE: To install software from the downloaded ISO image file in Windows 10 (or later), double-click the ISO file to mount it as a virtual drive to view its content. 3.14 Maintenance To configure the jumper settings, please follow the steps below. Step 1: Remove the top cover.

  • Page 56: Flash Descriptor Security Override Jumper

    DRPC-W-TGL 3.14.1 Flash Descriptor Security Override Jumper CN Label: ME_FLASH1 CN Type: 2-pin header, P=1.27mm CN Location: Figure 3-37 CN Pinouts: See Table 3-9 The ME_FLASH1 connector is used for Flash Descriptor Security Override or ME Debug Mode Figure 3-37: ME Override Setting Jumper Locations Setting Description Open...

  • Page 57: Clear Cmos Button

    DRPC-W-TGL Step 3: Remove the metal clip on the Flash Descriptor Security Override jumper to its default setting Step 4: Restart the system. The system will reboot 2 ~ 3 times to complete the ME firmware update 3.14.2 Clear CMOS Button CN Label: J_CMOS1 CN Type:...

  • Page 58: At/Atx Power Mode Setting

    DRPC-W-TGL 3.14.3 AT/ATX Power Mode Setting CN Label: J_ATX_AT1 CN Type: 3-pin switch CN Pinouts: See Table 3-11 The AT/ATX power mode selection is made through the AT/ATX power mode switch which is shown in. PIN NO. DESCRIPTION Short A - B ATX Power Mode (default) Short B –...

  • Page 59: System Motherboard

    DRPC-W-TGL Chapter System Motherboard Page 44...

  • Page 60: Peripheral Interface Connectors

    DRPC-W-TGL 4.1 Peripheral Interface Connectors This chapter details all the jumpers and connectors. 4.1.1 DRPC-W-TGL Series Layout The figures below show all the connectors and jumpers. Figure 4-1: Connector and Jumper Locations 4.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board.

  • Page 61: External Interface Panel Connectors

    DRPC-W-TGL M.2 2230 A-key slot M.2 A-key slot M2_AE1 M.2 3052/2042 B-key slot M.2 B-key slot M2_B1 Memory module slot 260-pin DDR4 SO-DIMM DIMM1 Power connector 4-pin Molex PWR1 Power button connector 2-pin wafer PWR_BTN1 Reset button connector 2-pin wafer RST_BTN1 RS-232 serial port connector 10-pin header...

  • Page 62: Internal Peripheral Connectors

    DRPC-W-TGL 4.2 Internal Peripheral Connectors The section describes all of the connectors on the DRPC-W-TGL Series. 4.2.1 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.

  • Page 63: Figure 4-2: Battery Connector Location

    DRPC-W-TGL Figure 4-2: Battery Connector Location Description VBAT+ Table 4-3: Battery Connector Pinouts Page 48...

  • Page 64: Digital I/O Connector

    DRPC-W-TGL 4.2.2 Digital I/O Connector CN Label: DIO1 CN Type: 14-pin header, p=2.00 mm CN Location: See Figure 4-3 CN Pinouts: See Table 4-4 The 12-bit digital I/O connector provides programmable input and output for external devices. Figure 4-3: Digital I/O Connector Location PIN NO.

  • Page 65: Fan Connector

    DRPC-W-TGL 4.2.3 Fan Connector CN Label: CPU/FAN1 CN Type: 4-pin wafer, p=2.54 mm CN Location: See Figure 4-4 CN Pinouts: See Table 4-5 The fan connector attaches to a smart cooling fan. Figure 4-4: Fan Connector Location Description +12V FANIO Table 4-5: Fan Connector Pinouts Page 50...

  • Page 66: Front Panel Connector

    DRPC-W-TGL 4.2.4 Front Panel Connector CN Label: F_PANEL1 CN Type: 6-pin wafer, p=2.00 mm CN Location: See Figure 4-5 CN Pinouts: See Table 4-6 The front panel connector connects to the power LED indicator and HDD LED indicator on the system front panel. Figure 4-5: Front Panel Connector Location Description PWR_LED+...

  • Page 67: Lan Led Connectors

    DRPC-W-TGL 4.2.5 LAN LED Connectors CN Label: JLAN_LED2, JLAN_LED3 CN Type: 2-pin header, p=2.00 mm CN Location: See Figure 4-6 CN Pinouts: See Table 4-7 The LAN LED connectors connect to the LAN link LEDs on the system. Figure 4-6: LAN LED Connector Locations Description +3.3V LAN1_LED_LNK#_ACT...

  • Page 68: Idpm Connector

    DRPC-W-TGL 4.2.6 iDPM Connector CN Label: IDPM CN Type: 75-pin slot, p=0.5 mm CN Location: See Figure 4-7 CN Pinouts: See Table 4-8 The iDPM slot only use for IEI eDP/LVDS/VGA module Figure 4-7: iDPM Connector Location Description Description +3.3V +3.3V +3.3V +3.3V...

  • Page 69: Table 4-8: Idpm Connector Pinouts

    DRPC-W-TGL Description Description Module Key +3.3VS DISPLAY_DETECT_P +3.3VS IN21 DISPLAY_DETECT_P +3.3VS IN23 +3.3VS EDP_TX3_DN +12VS EDP_TX3_DP +12VS +12VS EDP_TX2_DN +12VS EDP_TX2_DP SMB_CLK EDP_TX1_DN SMB_DATA EDP_TX1_DP EC_BKLT_CTRL EDP_TX0_DN EDP1_BKLT_CTRL EDP_TX0_DP EDP1_BKLT_EN EDP1_VDD_EN # EDP_AUX_DN EDP_HPD_R EDP_AUX_DP BUF_PLT_RST# LVDS_EN +V5S +V5S +V5S +V5S +12VA +12VA...

  • Page 70: Slot, B-Key

    DRPC-W-TGL 4.2.7 M.2 Slot, B-key CN Label: M2_B1 CN Type: M.2 B-key slot CN Location: See Figure 4-8 CN Pinouts: See Table 4-9 The M.2 slot is keyed in the B position and accepts 3052/2242 size of M.2 modules. The M.2 slot supports PCIe x2 and USB 2.0 signals.

  • Page 71: Table 4-9: M.2 B-Key Slot Pinouts

    DRPC-W-TGL Description Description Module Key Module Key Module Key CONFIG_0 PCIE_RXN5 WWAN_UIM_RST PCIE_RXP5 WWAN_UIM_CLK WWAN_UIM_DATA PCIE_TXN5 UIM_PWR PCIE_TXP5 DEVSLP PCIE_RXN4 PCIE_RXP4 PCIE_TXN4 PCIE_TXP4 BUF_PLT_RST# REFCLKN PCIE_WAKE# REFCLKP WWAN_RST +3.3V +3.3V +3.3V Table 4-9: M.2 B-Key Slot Pinouts Page 56...

  • Page 72: Slot, A-Key

    DRPC-W-TGL 4.2.8 M.2 Slot, A-key CN Label: M2_A1 CN Type: M.2 A-key slot CN Location: See Figure 4-9 CN Pinouts: See Table 4-10 The M.2 slot is keyed in the A position and accepts 2230 size of M.2 modules. The M.2 slot supports PCIe x1 and USB 2.0 signals.

  • Page 73: Table 4-10: M.2 A-Key Slot Pinouts

    DRPC-W-TGL Description Description PCIE_TX9+ PCIE_TX9- CL_RST# CL_DATA PCIE_RX9+ CL_CLK PCIE_RX9- CLK_M2_A+ CLK_M2_A- BUF_PLT_RST# Pull Up +V3.3A Pull Up +V3.3A +V3.3A +V3.3A Table 4-10: M.2 A-Key Slot Pinouts Page 58...

  • Page 74: Ddr4 So-Dimm Socket

    DRPC-W-TGL 4.2.9 DDR4 SO-DIMM Socket CN Label: DIMM1 CN Type: 260-pin DDR4 SO-DIMM socket CN Location: Figure 4-10 791H The SO-DIMM slot is for installing the DDR4 SO-DIMM. Figure 4-10: DDR4 SO-DIMM Socket Location Page 59...

  • Page 75: Power Connector

    DRPC-W-TGL 4.2.10 Power Connector CN Label: PWR1 CN Type: 4-pin Molex, p=4.2 mm CN Location: See Figure 4-11 CN Pinouts: See Table 4-11 The connector supports the +12V power supply. Figure 4-11: +12V DC-IN Power Connector Location PIN NO. DESCRIPTION PIN NO.

  • Page 76: Power Button Connector

    DRPC-W-TGL 4.2.11 Power Button Connector CN Label: PWR_BTN1 CN Type: 2-pin wafer, p=2.00 mm CN Location: See Figure 4-12 CN Pinouts: See Table 4-12 The power button connector is connected to a power switch on the system chassis to enable users to turn the system on and off. Figure 4-12: Power Button Connector Location Description PWR_BTN+...

  • Page 77: Reset Button Connector

    DRPC-W-TGL 4.2.12 Reset Button Connector CN Label: RST_BTN1 CN Type: 2-pin wafer, p=2.00 mm CN Location: See Figure 4-13 CN Pinouts: See Table 4-13 The reset button connector is connected to a reset switch on the system chassis to enable users to reboot the system when the system is turned on.

  • Page 78: Serial Port Connector

    DRPC-W-TGL 4.2.13 RS-232 Serial Port Connector CN Label: COM1 CN Type: 10-pin header, p=2.0 mm CN Location: See Figure 4-14 CN Pinouts: See Table 4-14 The serial connector provides RS-232 connection. Figure 4-14: RS-232 Serial Port Connector Location PIN NO. DESCRIPTION PIN NO.

  • Page 79: Rs-232/422/485 Serial Port Connector

    DRPC-W-TGL 4.2.14 RS-232/422/485 Serial Port Connector CN Label: COM2, COM3 CN Type: 10-pin header, p=2.0 mm CN Location: See Figure 4-15 CN Pinouts: See Table 4-15 This connector provides RS-232, RS-422 or RS-485 communications. The default mode is set to RS-232. Use BIOS to configure the connectors as RS-422 or RS-485. Figure 4-15: RS-232/422/485 Connector Location RS-232 RS-422...

  • Page 80: Sata 6Gb/S Drive Connector

    DRPC-W-TGL Use the optional RS-232/422/485 cable to connect to a serial device. The pinouts of the DB-9 connector are listed below. RS-232 RS-422 RS-485 TXD422- TXD485- TXD422+ TXD485+ RXD422+ RXD422- Table 4-16: DB-9 RS-232/422/485 Pinouts 4.2.15 SATA 6Gb/s Drive Connector CN Label: SATA1 CN Type:...

  • Page 81: Sata Power Connector

    DRPC-W-TGL 4.2.16 SATA Power Connector CN Label: SATA_PWR1 CN Type: 2-pin wafer, p=2.00 mm CN Location: See Figure 4-17 CN Pinouts: See Table 4-17 The SATA power connector provides +5 V power output to the SATA connector. Figure 4-17: SATA Power Connector Location Description Table 4-17: SATA Power Connector Pinouts Page 66...

  • Page 82: Smbus/I C Connector

    DRPC-W-TGL 4.2.17 SMBus/I C Connector CN Label: I2C1 CN Type: 4-pin wafer, p=1.25 mm CN Location: See Figure 4-18 CN Pinouts: See Table 4-18 The SMBus (System Management Bus) connector provides low-speed system management communications. Figure 4-18: SMBus Connector Location Description SMBus_DATA SMBus_CLK...

  • Page 83: Usb 2.0 Connector

    DRPC-W-TGL 4.2.18 USB 2.0 Connector CN Label: USB2_CN1 CN Type: 8-pin header, p=2.00 mm CN Location: See Figure 4-19 CN Pinouts: See Table 4-19 The USB connector provides two USB 2.0 ports by dual-port USB cable. Figure 4-19: USB Connector Location PIN NO.

  • Page 84: External Peripheral Interface Connector Panel

    DRPC-W-TGL 4.3 External Peripheral Interface Connector Panel Figure 4-20 shows the DRPC-W-TGL Series external peripheral interface connector (EPIC) panel. The EPIC panel consists of the following: ▪ 2 x HDMI connector ▪ 1 x DP connector ▪ 3 x 2.5GbE RJ-45 connector ▪...

  • Page 85: Hdmi Connectors

    DRPC-W-TGL 4.3.1 HDMI Connectors CN Label: HDMI1 CN Type: HDMI connector CN Location: See Figure 4-20 CN Pinouts: See Table 4-20 and Figure 4-21 The HDMI connectors can connect to HDMI devices. Description Description HDMI_DATA2 HDMI_DATA2# HDMI_DATA1 HDMI_DATA1# HDMI_DATA0 HDMI_DATA0# HDMI_CLK HDMI_ CLK# HDMI_SCL...

  • Page 86: Dp Connector

    DRPC-W-TGL 4.3.2 DP Connector CN Label: CN Type: DP connector CN Location: See Figure 4-20 CN Pinouts: See Table 4-21 and Figure 4-22 The DP connectors can connect to DP devices. PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA_0P DATA_3N DATA_0N CONFIG1 DATA_1P CONFIG2...

  • Page 87: Lan Connectors

    DRPC-W-TGL 4.3.3 LAN Connectors CN Label: LAN1, LAN2, LAN3 CN Type: RJ-45 CN Location: Figure 4-20 808H CN Pinouts: Figure 4-23 and Table 4-22 8 0 9H The LAN connector connects to a local network. Description Description MDIA0+ MDIA2+ MDIA0- MDIA1- MDIA1+ MDIA3+...

  • Page 88: Usb 3.2 Gen 2 Connectors

    Table 4-24 and Figure 4-24 8 1 5H The DRPC-W-TGL Series has four external USB 3.2 Gen 2 ports. The USB connector can be connected to a USB 2.0 or USB 3.2 device. The pinouts of USB 3.2 Gen 2 connectors are shown below.

  • Page 89: Driver Download

    DRPC-W-TGL 4.4 Driver Download To download drivers from IEI Resource Download Center, follow the steps below. Step 4: Go to https://download.ieiworld.com. Type DRPC-W-TGL Series and press Enter. Step 5: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result.
  • Page 90 DRPC-W-TGL NOTE: To install software from the downloaded ISO image file in Windows 8, 8.1 or 10, double-click the ISO file to mount it as a virtual drive to view its content. Page 75...

  • Page 91: Available Drivers

    DRPC-W-TGL 4.5 Available Drivers All the drivers for the DRPC-W-TGL Series are available on IEI Resource Download Center (https://download.ieiworld.com). Type DRPC-W-TGL Series and press Enter to find all the relevant software, utilities, and documentation. Figure 4-25: IEI Resource Download Center...

  • Page 92: Bios

    DRPC-W-TGL Chapter BIOS Page 77...

  • Page 93: Introduction

    DRPC-W-TGL 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 94: Using Setup

    DRPC-W-TGL 5.1.2 Using Setup The BIOS Setup menu can be navigated by using a keyboard or a touchscreen. 5.1.2.1 Keyboard Navigation For keyboard navigation, use the navigation keys shown in Table 5-1 Function Up arrow Move to previous item Down arrow Move to next item Left arrow Move to the item on the left hand side...

  • Page 95: Touch Navigation

    DRPC-W-TGL 5.1.2.2 Touch Navigation For touchscreen navigation, use the on-screen navigation keys shown below. On-screen Button Function Previous Values Load the last value you set. Optimized Defaults Load the factory default values in order to achieve the best performance. Back Return to the previous menu.

  • Page 96: Getting Help

    DRPC-W-TGL 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window, press the key. 5.1.4 Unable to Reboot after Configuration Changes If the computer cannot boot after changes to the system configuration is made, CMOS defaults.

  • Page 97: Main

    DRPC-W-TGL 5.2 Main The Main BIOS menu (BIOS Menu 1 & BIOS Menu 2) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS Menu 1: Main (1/2) BIOS Menu 2: Main (2/2) Page 82...
  • Page 98 DRPC-W-TGL ➔ BIOS Information The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information cannot be changed. The items shown in the system overview include: ▪ BIOS Vendor: Installed BIOS vendor ▪ Core Version: Current BIOS version ▪...
  • Page 99 DRPC-W-TGL ➔ PCH Information The PCH Information lists a brief summary of the PCH. The fields in PCH Information cannot be changed. The items shown in the system overview include: ▪ Name: Displays the PCH Name ▪ PCH SKU: Displays the PCH SKU ▪...

  • Page 100: Advanced

    DRPC-W-TGL 5.3 Advanced Use the Advanced menu (BIOS Menu 3 ) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.

  • Page 101: Cpu Configuration

    DRPC-W-TGL 5.3.1 CPU Configuration Use the CPU Configuration menu (BIOS Menu 4 & BIOS Menu 5 & BIOS Menu 6) to view detailed CPU specifications or enable the Intel Virtualization Technology. BIOS Menu 4: CPU Configuration (1/3) Page 86...
  • Page 102 DRPC-W-TGL BIOS Menu 5: CPU Configuration (2/3) BIOS Menu 6: CPU Configuration (3/3) Page 87...
  • Page 103 DRPC-W-TGL ➔ Power Limit 1 [0] Use the + or – key to change the Power Limit 1 value. BIOS will program the default values for Limit 1 and Power Limit 1 Time Window. For 12.50W, enter 12500. ➔ Power Limit 2 [0] Use the + or –...
  • Page 104 DRPC-W-TGL ➔ Enable one core in the processor package. ➔ Enable two cores in the processor package. ➔ Enable three cores in the processor package. Hyper-Threading [Enabled] ➔ Use the Hyper-Threading option to enable or disable the Hyper-Threading Technology. ➔ Disabled Disables Hyper-Threading Technology ➔...

  • Page 105: Trusted Computing

    DRPC-W-TGL 5.3.2 Trusted Computing Use the Trusted Computing menu (BIOS Menu 7) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). BIOS Menu 7: PCH-FW Configuration ➔ Security Device Support [Enable] Use the Security Device Support option to configure support for the TPM. ➔...

  • Page 106: F81216 Super Io Configuration

    DRPC-W-TGL 5.3.3 F81216 Super IO Configuration Use the F81216 Super IO Configuration menu (BIOS Menu 8) to set or change the configurations for the serial ports. BIOS Menu 8: F81966 Super IO Configuration Page 91...

  • Page 107: Serial Port 1 Configuration

    DRPC-W-TGL 5.3.3.1 Serial Port 1 Configuration Use the Serial Port 1 Configuration menu (BIOS Menu 9) to configure the serial port n. BIOS Menu 9: Serial Port 1 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ➔...

  • Page 108: Serial Port 2 Configuration

    DRPC-W-TGL 5.3.3.2 Serial Port 2 Configuration Use the Serial Port 2 Configuration menu (BIOS Menu 10) to configure the serial port. BIOS Menu 10: Serial Port 2 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ➔...

  • Page 109: Serial Port 3 Configuration

    DRPC-W-TGL ➔ Serial Port Mode [RS232] Use the Serial Port Mode option to set RS232/422/485 mode. ➔ RS232 Serial Port Mode is RS232 mode ➔ RS422 Serial Port Mode is RS422 mode ➔ RS485 Serial Port Mode is RS485 mode 5.3.3.3 Serial Port 3 Configuration Use the Serial Port 3 Configuration menu (BIOS Menu 11) to configure the serial port 3.
  • Page 110 DRPC-W-TGL ➔ Enabled Enable the serial port EFAULT ➔ Device Settings The Device Settings option shows the serial port IO port address and interrupt address. ➔ IO=2E0h; Serial Port I/O port address is 2E0h and the interrupt IRQ=10 address is IRQ10 ➔...

  • Page 111: It5571 H/W Monitor

    DRPC-W-TGL 5.3.4 IT5571 H/W Monitor The IT5571 H/W Monitor menu (BIOS Menu 12) contains the smart fan mode configuration submenu and shows the state of H/W real-time operating temperature, fan speeds and system voltages. BIOS Menu 12: IT5571 H/W Monitor ➔...

  • Page 112: Smart Fan Mode Configuration

    DRPC-W-TGL +V5S +V12S +VDDQ +V3.3S 5.3.4.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 13) to configure the CPU/system fan start/off temperature and control mode. BIOS Menu 13: Smart Fan Mode Configuration ➔ CPU_FAN1 Smart Fan Control [Auto Mode] Use the CPU_FAN1 Smart Fan Control option to configure the CPU Smart Fan.
  • Page 113 DRPC-W-TGL ➔ Auto Mode The fan adjusts its speed using Auto Mode EFAULT settings. ➔ CPU_FAN1 Start Temperature If the CPU temperature is between fan off and fan start, the fan speed change to fan start PWM. To set a value, Use the + or – key to change the value or enter a decimal number between 1 and 100.

  • Page 114: Rtc Wake Settings

    DRPC-W-TGL ➔ SYS_FAN1 Off Temperature If the System temperature is lower than the value set this option, the fan speed change to be lowest. To set a value, Use the + or – key to change the value or enter a decimal number between 1 and 100.
  • Page 115 DRPC-W-TGL BIOS Menu 15: RTC Wake Settings (2/2) ➔ Wake system with Fixed Time [Disabled] Use the Wake system with Fixed Time option to enable or disable the system wake on alarm event. ➔ Disabled The real time clock (RTC) cannot generate a wake EFAULT event ➔...

  • Page 116: Serial Port Console Redirection

    DRPC-W-TGL from a suspend state when the alarm goes off. 5.3.6 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 16 & BIOS Menu 17) allows the console redirection options to be configured. Console Redirection allows users to maintain a system remotely by re-directing keyboard input and text output through the serial port.
  • Page 117 DRPC-W-TGL BIOS Menu 17: Serial Port Console Redirection (2/2) ➔ Console Redirection [Disabled] Use Console Redirection option to enable or disable the console redirection function. ➔ Disabled Disabled the console redirection function EFAULT ➔ Enabled Enabled the console redirection function The Console Redirection Settings submenu will be available when the Console Redirection option is enabled.

  • Page 118: Console Redirection Settings

    DRPC-W-TGL 5.3.6.1 Console Redirection Settings The following options are available in the Console Redirection Settings submenu (BIOS Menu 18) when the COM Console Redirection (for COM1 to COM6) option is enabled. BIOS Menu 18: COM Console Redirection Settings ➔ Terminal Type [ANSI] Use the Terminal Type option to specify the remote terminal type.
  • Page 119 DRPC-W-TGL ➔ Bits per second [115200] Use the Bits per second option to specify the serial port transmission speed. The speed must match on the other side. Long or noisy lines may require lower speeds. ➔ 9600 Sets the serial port transmission speed at 9600. ➔...
  • Page 120 DRPC-W-TGL ➔ Stop Bits [1] Use the Stop Bits option to specify the number of stop bits used to indicate the end of a serial data packet. Communication with slow devices may require more than 1 stop bit. ➔ Sets the number of stop bits at 1. EFAULT ➔...

  • Page 121: Nvme Configuration

    DRPC-W-TGL 5.3.7 NVMe Configuration Use the NVMe Configuration (BIOS Menu 19) menu to display the NVMe controller and device information. BIOS Menu 19: NVMe Configuration Page 106...

  • Page 122: Chipset

    DRPC-W-TGL 5.4 Chipset Use the Chipset menu (BIOS Menu 20) to access the PCH IO and System Agent (SA) configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. BIOS Menu 20: Chipset Page 107...

  • Page 123: System Agent (Sa) Configuration

    DRPC-W-TGL 5.4.1 System Agent (SA) Configuration Use the System Agent (SA) Configuration menu (BIOS Menu 21) to configure the System Agent (SA) parameters. BIOS Menu 21: System Agent (SA) Configuration ➔ VT-d [Enabled] Use the VT-d option to enable or disable the VT-d capability. ➔...

  • Page 124: Memory Configuration

    DRPC-W-TGL 5.4.1.1 Memory Configuration Use the Memory Configuration submenu (BIOS Menu 22) to view memory information. BIOS Menu 22: Memory Configuration Page 109...

  • Page 125: Graphics Configuration

    DRPC-W-TGL 5.4.1.2 Graphics Configuration Use the Graphics Configuration (BIOS Menu 23) menu to configure the video device connected to the system. BIOS Menu 23: Graphics Configuration ➔ Primary Display [Auto] Use the Primary Display option to select the primary graphics controller the system uses. The following options are available: ▪...
  • Page 126 DRPC-W-TGL ➔ Internal Graphics [Enabled] Use the Internal Graphics option to configure whether to keep IGFX enabled. If user wants to support dual display by internal graphics and external graphics, this Internal Graphics option should be set to Enabled and the above Primary Display option should be set to IGFX.

  • Page 127: Pch-Io Configuration

    DRPC-W-TGL 5.4.2 PCH-IO Configuration Use the PCH-IO Configuration menu (BIOS Menu 24) to configure the PCH parameters. BIOS Menu 24: PCH-IO Configuration ➔ Auto Power Button Function [Enabled(AT)] Use the Auto Power Button Function BIOS option to show the power mode state. Use the J_ATX_AT1 to switch the AT/ATX power mode.
  • Page 128 DRPC-W-TGL ➔ Power Off The system remains turned off ➔ Power On The system turns on ➔ Last State The system returns to its previous state. If it was on, it EFAULT turns itself on. If it was off, it remains off. ➔...

  • Page 129: Pci Express Configuration

    DRPC-W-TGL BIOS Options Configured USB Ports K/M_USB1 (external USB 2.0 ports) USB Power SW1 LAN1_USB1 (external USB 3.2 Gen 2 ports) LAN2_USB2 (external USB 3.2 Gen 1 ports) USB1 (internal USB 2.0 ports) USB Power SW2 USB2 (internal USB 2.0 ports) USB3-1 (internal USB 3.2 Gen 1 ports) Figure 5-3: BIOS Options and Configured USB Ports 5.4.2.1 PCI Express Configuration...

  • Page 130: Bios Menu 26: Pcie Slot Configuration Submenu

    DRPC-W-TGL Use the PCIEX4_1, PCIEX4_2, PCIEX16_1, M2_A1, M2_M1, PCIEX4_3 submenu (BIOS Menu 26) to configure the PCI Root Port Setting. BIOS Menu 26: PCIe Slot Configuration Submenu ➔ PCIe Speed [Auto] Use the PCIe Speed option to specify the PCI Express port speed. Configuration options are listed below.
  • Page 131 DRPC-W-TGL ➔ Disabled Do not detect if a non-compliance PCI Express EFAULT device is connected to the PCI Express port. ➔ Enabled Detect if a non-compliance PCI Express device is connected to the PCI Express port. Page 116...

  • Page 132: Sata Configuration

    DRPC-W-TGL 5.4.2.2 SATA Configuration Use the SATA Configuration menu (BIOS Menu 27) to change and/or set the configuration of the SATA devices installed in the system. BIOS Menu 27: SATA Configuration ➔ SATA Controller(s) [Enabled] Use the SATA Controller(s) option to configure the SATA controller(s). ➔...
  • Page 133 DRPC-W-TGL Use the SATA Mode Selection option to determine how the SATA devices operate. ➔ AHCI Configures SATA devices as AHCI device. EFAULT ➔ Intel Configures SATA devices to the Intel RST Premium With Premium Intel Optane System Acceleration mode. With Intel Optane...

  • Page 134: Hd Audio Configuration

    DRPC-W-TGL 5.4.2.3 HD Audio Configuration Use the HD Audio Configuration menu (BIOS Menu 28) to configure the PCH Azalia settings. BIOS Menu 28: HD Audio Configuration ➔ HD Audio [Auto] Use the HD Audio option to enable or disable the High Definition Audio controller. ➔...

  • Page 135: Security

    DRPC-W-TGL 5.5 Security Use the Security menu (BIOS Menu 29) to set system and user passwords. BIOS Menu 29: Security ➔ Administrator Password Use the Administrator Password to set or change a administrator password. ➔ User Password Use the User Password to set or change a user password. Page 120...

  • Page 136: Boot

    DRPC-W-TGL 5.6 Boot Use the Boot menu (BIOS Menu 30) to configure system boot options. BIOS Menu 30: Boot 5.6.1 Boot Configuration Quiet Boot [Enabled] ➔ Use the Quiet Boot BIOS option to select the screen display when the system boots. ➔...

  • Page 137: Boot Option Priorities

    DRPC-W-TGL ➔ Launch PXE OpROM [Disabled] Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices. ➔ Disabled Ignore all PXE Option ROMs EFAULT ➔ Enabled Load PXE Option ROMs. ➔ Option ROM Messages [Force BIOS] Use the Option ROM Messages option to set the Option ROM display mode.

  • Page 138: Save & Exit

    DRPC-W-TGL 5.7 Save & Exit Use the Safe & Exit menu (BIOS Menu 31) to load default BIOS values, optimal failsafe values and to save configuration changes. BIOS Menu 31: Save & Exit ➔ Save Changes and Reset Use the Save Changes and Reset option to save the changes made to the BIOS options and reset the system.
  • Page 139 DRPC-W-TGL ➔ Restore Defaults Use the Restore Defaults option to load the optimal default values for each of the parameters on the Setup menus. F3 key can be used for this operation. ➔ Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults. ➔...

  • Page 140: A Regulatory Compliance

    DRPC-W-TGL Appendix Regulatory Compliance Page 125...
  • Page 141 DRPC-W-TGL DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: ◼...

  • Page 142: B Product Disposal

    DRPC-W-TGL Appendix Product Disposal Page 127...
  • Page 143 DRPC-W-TGL CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. ▪ Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 144: Cbios Options

    DRPC-W-TGL Appendix BIOS Options Page 129...
  • Page 145 DRPC-W-TGL Below is a list of BIOS configuration options in the BIOS chapter. ➔ BIOS Information .........................83 ➔ Processor Information ......................83 ➔ PCH Information ........................84 ➔ System Date [xx/xx/xx] ......................84 ➔ System Time [xx:xx:xx] .......................84 ➔ Power Limit 1 [0] ........................88 ➔...
  • Page 146 DRPC-W-TGL ➔ Auto Mode Fan Slope PWM ....................99 ➔ Wake system with Fixed Time [Disabled] ................100 ➔ Console Redirection [Disabled]..................102 ➔ Terminal Type [ANSI] ......................103 ➔ Bits per second [115200] ....................104 ➔ Data Bits [8] ........................104 ➔ Parity [None] ........................104 ➔...
  • Page 147 DRPC-W-TGL ➔ Save as User Defaults .......................124 ➔ Restore User Defaults .......................124 Page 132...

  • Page 148: D Watchdog Timer

    DRPC-W-TGL Appendix Watchdog Timer Page 133...
  • Page 149 DRPC-W-TGL NOTE: The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for other operating systems. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug.
  • Page 150 DRPC-W-TGL NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ; ADD THE APPLICATION PROGRAM HERE EXIT_AP, 1 ;is the application over? W_LOOP...

  • Page 151: E Error Beep Code

    DRPC-W-TGL Appendix Error Beep Code Page 136...

  • Page 152: Pei Beep Codes

    DRPC-W-TGL E.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available E.2 DXE Beep Codes Number of Beeps...

  • Page 153: F Hazardous Materials Disclosure

    DRPC-W-TGL Appendix Hazardous Materials Disclosure Page 138...

  • Page 154: Rohs Ii Directive (2015/863/Eu)

    DRPC-W-TGL F.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 155: China Rohs

    DRPC-W-TGL F.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 140...

This manual is also suitable for:

Drpc-w-tgl-u-i7c-r10Drpc-w-tgl-u-i5c-r10Drpc-w-tgl-u-i3c-r10Drpc-w-tgl-u-cc-r10

Table of Contents
