NANO-ADL-P
MODEL:
NANO-ADL-P
EPIC SBC Supports Intel® Alder Lake-P Processor,
Dual HDMI, DP, iDPM, M.2 A Key, M.2 B Key, USB 3.2, SATA
6Gb/s, COM, iAUDIO, PCIe x4 for Riser Card and RoHS
User Manual
Page 1
Rev. 1.00 – June 27, 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NANO-ADL-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology NANO-ADL-P

Summary of Contents for IEI Technology NANO-ADL-P

  • Page 1 NANO-ADL-P MODEL: NANO-ADL-P EPIC SBC Supports Intel® Alder Lake-P Processor, Dual HDMI, DP, iDPM, M.2 A Key, M.2 B Key, USB 3.2, SATA 6Gb/s, COM, iAUDIO, PCIe x4 for Riser Card and RoHS User Manual Page 1 Rev. 1.00 – June 27, 2023...
  • Page 2 NANO-ADL-P Revision Date Version Changes June 27, 2023 1.00 Initial release Page 2...
  • Page 3 NANO-ADL-P Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 NANO-ADL-P Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    ...................... 26 PTIONAL TEMS 3 CONNECTORS ......................28 ..............29 ERIPHERAL NTERFACE ONNECTORS 3.1.1 NANO-ADL-P Layout ..................29 3.1.2 Peripheral Interface Connectors ..............29 3.1.3 External Interface Panel Connectors ............... 31 ..............31 NTERNAL ERIPHERAL ONNECTORS 3.2.1 Battery Connector .................... 31 3.2.2 AT/ATX Power Mode Setting ................
  • Page 6 NANO-ADL-P 3.2.12 I C Connector ....................43 3.2.13 SMBus Connector ..................44 3.2.14 M.2 A-key Slot ....................45 3.2.15 M.2 B-key Slot ....................47 3.2.16 PCIe x4 Slots ....................49 3.2.17 IDPM Slot ...................... 50 3.2.18 Power button connector ................. 52 3.2.19 Reset button connector ...................
  • Page 7 NANO-ADL-P ......................83 NTRODUCTION 5.1.1 Starting Setup ....................83 5.1.2 Using Setup ...................... 84 5.1.2.1 Keyboard Navigation ................84 5.1.2.2 Touch Navigation ..................85 5.1.3 Getting Help ..................... 86 5.1.4 Unable to Reboot after Configuration Changes ..........86 5.1.5 BIOS Menu Bar ....................86 ........................
  • Page 8 NANO-ADL-P ....................... 128 ECURITY ........................130 5.6.1 Boot Configuration ..................130 5.6.2 Boot Option Priorities ..................131 & E ......................132 A REGULATORY COMPLIANCE ................134 B PRODUCT DISPOSAL .................... 136 C BIOS OPTIONS ......................138 D WATCHDOG TIMER ....................142 E ERROR BEEP CODE ....................
  • Page 9 NANO-ADL-P List of Figures Figure 1-1: NANO-ADL-P ......................16 Figure 1-2: Connectors ........................18 Figure 1-3: NANO-ADL-P Dimensions (mm) ................19 Figure 1-4: Data Flow Diagram ....................20 Figure 3-1: Peripheral Interface Connectors ................29 Figure 3-2: Battery Connector Location ..................32 Figure 3-3: AT/ATX Power Mode Switch Location ..............33 Figure 3-4: 12V Power Input Connector Location ..............34...
  • Page 10 NANO-ADL-P Figure 3-28: External Peripheral Interface Connector ..............61 Figure 3-29: External dual USB 3.2 Gen 2 connectors .............61 Figure 3-30: HDMI Connectors ....................62 Figure 3-31: LAN LED Location ....................63 Figure 3-32: DP Connector ......................64 Figure 4-1: Inserting the M.2 Module into the Slot at an Angle..........68 Figure 4-2: Securing the M.2 Module ..................68...
  • Page 11 NANO-ADL-P List of Tables Table 1-1: NANO-ADL-P Specifications..................22 Table 2-1: Packing List .........................25 Table 2-2: Optional Items ......................27 Table 3-1: Peripheral Interface Connectors ................30 Table 3-2: Rear Panel Connectors ....................31 Table 3-3: Battery Connector Pinouts ..................32 Table 3-4: AT/ATX Power Mode Switch Settings ...............33 Table 3-5: 12V Power Input Connector Pinouts ................34...
  • Page 12 NANO-ADL-P Table 3-29: HDMI Connector Pinouts ..................63 Table 3-30: 2.5GbE RJ45 Pinouts ....................63 Table 3-31: LAN LED Pinouts ......................63 Table 3-32: DP Connector Pinouts ....................64 Table 5-1: BIOS Navigation Keys ....................84 Table 5-2: BIOS On-screen Navigation Keys ................85 Page 12...
  • Page 13 NANO-ADL-P BIOS Menus BIOS Menu 1: Main (1/3) .......................87 BIOS Menu 2: Main (2/3) .......................87 BIOS Menu 3: Main (3/3) .......................88 BIOS Menu 4: Advanced ......................90 BIOS Menu 5: CPU Configuration (1/3)..................91 BIOS Menu 6: CPU Configuration (2/3)..................92 BIOS Menu 7: CPU Configuration (3/3)..................92 BIOS Menu 8: Trusted Computing Configuration ..............95...
  • Page 14 NANO-ADL-P BIOS Menu 32: PCI Express Configuration ................123 BIOS Menu 33: PCIe Slot Configuration Submenu ..............124 BIOS Menu 34: SATA Configuration ..................125 BIOS Menu 35: HD Audio Configuration ..................127 BIOS Menu 36: Security (1/2) .....................128 BIOS Menu 37: Security (2/2) .....................129 BIOS Menu 38: Boot ........................130...

  • Page 15: Introduction

    NANO-ADL-P Chapter Introduction Page 15...

  • Page 16: Ntroduction

    Introduction Figure 1-1: NANO-ADL-P The NANO-ADL-P is powered by 12th Gen. Intel® mobile Alder Lake-P on board SoC and on-board 8GB 3200 MHz LPDDR4x memory (up to 16GB). The NANO-ADL-P supports one SATA 6Gb/s drive. Moreover, the NANO-ADL-P includes DP, two HDMI and IEI iDPM slot for quadruple independent display.

  • Page 17: Features

    NANO-ADL-P Features Some of the NANO-ADL-P motherboard features are listed below: ▪ 12th Gen. Intel® mobile Alder Lake-P on board SoC ▪ On-board 8GB 3200 MHz LPDDR4x memory, up to 16GB ▪ 2 x Intel® I225V 2.5GbE controller ▪ Quadruple independent display by two HDMI, DP and IEI iDPM slot ▪...

  • Page 18: Connectors

    NANO-ADL-P Connectors The connectors on the NANO-ADL-P are shown in the figure below. Figure 1-2: Connectors Page 18...

  • Page 19: Dimensions

    NANO-ADL-P Dimensions The main dimensions of the NANO-ADL-P are shown in the diagram below. Figure 1-3: NANO-ADL-P Dimensions (mm) Page 19...

  • Page 20: Data Flow

    NANO-ADL-P Data Flow Figure 1-4 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-4: Data Flow Diagram Page 20...

  • Page 21: Technical Specifications

    NANO-ADL-P Technical Specifications The NANO-ADL-P technical specifications are listed below. 747H Specification/Model NANO-ADL-P EPIC Form Factor 12th Gen. Intel® mobile Alder Lake-P on board SoC CPU Supported On-board 8GB 3200 MHz LPDDR4x memory, up to 16GB Memory Intel® Xe Graphics architecture, 4 independent displays, up to...

  • Page 22: Table 1-1: Nano-Adl-P Specifications

    LPDDR4x memory, max. loading, EuP mode enabled) 0ºC ~ 60ºC Operating Temperature -30ºC ~ 70ºC Storage Temperature 5% ~ 95% (non-condensing) Operating Humidity Physical Specifications 115 mm x 165 mm Dimensions Weight (GW/NW) 900g / 400g Table 1-1: NANO-ADL-P Specifications Page 22...

  • Page 23: Packing List

    NANO-ADL-P Chapter Packing List Page 23...

  • Page 24: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. Unpacking Precautions When the NANO-ADL-P is unpacked, please do the following: ▪ Follow the anti-static guidelines above. ▪...

  • Page 25: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the NANO-ADL-P was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.

  • Page 26: Optional Items

    NANO-ADL-P Optional Items The following are optional components which may be separately purchased: Item and Part Number Image SATA power cable (P/N: 32102-000100-200-RS) Realtek ALC888S 7.1 Channel HD Audio board, RoHS (P/N: AC-KIT-888S-R10) Dual-port USB cable with bracket, 300mm, p=2.0 (P/N: CB-USB02A-RS) RS-232/422/485 cable, 200mm, p=2.0...

  • Page 27: Table 2-2: Optional Items

    NANO-ADL-P Item and Part Number Image PCIe x2 to two PCIe x1 riser card for NANO on the right side (P/N: NWR-R2S-R10) Table 2-2: Optional Items Page 27...

  • Page 28: Connectors

    NANO-ADL-P Chapter Connectors Page 28...

  • Page 29: Peripheral Interface Connectors

    NANO-ADL-P Peripheral Interface Connectors This chapter details all the peripheral interface connectors. 3.1.1 NANO-ADL-P Layout The figures below show all the peripheral interface connectors. Figure 3-1: Peripheral Interface Connectors 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board.

  • Page 30: Table 3-1: Peripheral Interface Connectors

    NANO-ADL-P Connector Type Label Audio connector for IEI AC-KIT-888S kit 10-pin header IAUDIO1 12V power input connector 4-pin connector PWR1 RTC battery connector 2-pin header BAT1 Buzzer connector 2-pin header Digital I/O connector 14-pin header J_DIO1 EC debug connector 6-pin header...

  • Page 31: External Interface Panel Connectors

    External dual USB 3.2 Gen 2 connectors USB3_1, USB3_2 Table 3-2: Rear Panel Connectors Internal Peripheral Connectors The section describes all of the connectors on the NANO-ADL-P. 3.2.1 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery.

  • Page 32: Figure 3-2: Battery Connector Location

    NANO-ADL-P CN Label: BAT1 CN Type: 2-pin header CN Location: See Figure 3-2 CN Pinouts: See Table 3-3 A system battery is placed in the battery holder. The battery provides power to the system clock to retain the time when power is turned off.

  • Page 33: At/Atx Power Mode Setting

    NANO-ADL-P 3.2.2 AT/ATX Power Mode Setting CN Label: J_ATX_AT1 CN Type: 3-pin switch CN Location: Figure 3-3 CN Pinouts: See Table 3-4 The AT/ATX power mode selection is made through the AT/ATX power mode switch. Figure 3-3: AT/ATX Power Mode Switch Location...

  • Page 34: Power Input Connector

    NANO-ADL-P 3.2.3 12V Power Input Connector CN Label: PWR1 CN Type: 4-pin Molex CN Location: Figure 3-4 CN Pinouts: See Table 3-5 The 12V power input connector supports the +12V power supply. Figure 3-4: 12V Power Input Connector Location Description...

  • Page 35: Digital I/O Connector

    NANO-ADL-P 3.2.4 Digital I/O Connector CN Label: J_DIO1 CN Type: 14-pin header, p=2.0 mm CN Location: See Figure 3-5 CN Pinouts: See Table 3-6 The Digital I/O connector provides programmable input and output for external devices. Figure 3-5: Digital I/O Connector Location...

  • Page 36: Ec Debug Connector

    NANO-ADL-P 3.2.5 EC Debug Connector CN Label: EC_DEBG1 CN Type: 6-pin header CN Location: See Figure 3-6 CN Pinouts: See Table 3-7 The EC debug connector is used for EC debug. Figure 3-6: EC Debug Connector Location Description Description EDICLK...

  • Page 37: Flash Descriptor Security Override Setting Jumper

    NANO-ADL-P Figure 3-7: Clear CMOS Jumper Location Description Keep CMOS Setup (Normal Operation) Press Clear CMOS Setup Table 3-8: Clear CMOS Jumper Pinouts 3.2.7 Flash Descriptor Security Override Setting Jumper CN Label: ME_FLASH1 CN Type: 2-pin header CN Location: See Figure 3-8...

  • Page 38: Figure 3-8: Flash Descriptor Security Override Setting Jumper Location

    NANO-ADL-P Figure 3-8: Flash Descriptor Security Override Setting Jumper Location Description Open Disabled (default) Short Enabled Table 3-9: Flash Descriptor Security Override Setting Jumper Pinouts Page 38...

  • Page 39: Fan Connector (Cpu)

    NANO-ADL-P 3.2.8 Fan Connector (CPU) CN Label: CPU/FAN1 CN Type: 4-pin header, p=2.54 mm CN Location: See Figure 3-9 CN Pinouts: See Table 3-10 The fan connector attaches to a CPU cooling fan. Figure 3-9: CPU Fan Connector Location Description...

  • Page 40: Audio Connector

    NANO-ADL-P 3.2.9 Audio Connector CN Label: IAUDIO1 CN Type: 10-pin header, p=2.54 mm CN Location: See Figure 3-10 CN Pinouts: See Table 3-11 This connector connects to speakers, a microphone and an audio input. Figure 3-10: Audio Connector Location Description...

  • Page 41: Buzzer Connector

    NANO-ADL-P 3.2.10 Buzzer Connector CN Label: CN Type: 2-pin header, p=2.54 mm CN Location: See Figure 3-11 CN Pinouts: See Table 3-12 The buzzer connector is connected with the buzzer to give a beep warning when the motherboard goes wrong.

  • Page 42: Front Panel Connector

    NANO-ADL-P 3.2.11 Front Panel Connector CN Label: F_PANEL1 CN Type: 6-pin header, p=2.54 mm CN Location: See Figure 3-12 CN Pinouts: See Table 3-13 The front panel connector connects to the power LED indicator and HDD LED indicator on the system front panel.

  • Page 43: I 2 C Connector

    NANO-ADL-P 3.2.12 I C Connector CN Label: J_I2C1 CN Type: 4-pin wafer, p=1.25 mm CN Location: See Figure 3-13 CN Pinouts: See Table 3-14 The I C connector is used to connect I C-bus devices to the mainboard. Figure 3-13: I...

  • Page 44: Smbus Connector

    NANO-ADL-P 3.2.13 SMBus Connector CN Label: J_SMB1 CN Type: 4-pin wafer, p=1.25 mm CN Location: See Figure 3-14 CN Pinouts: See Table 3-15 The SMBus is a two-wire bus used for communication with low bandwidth devices on a motherboard such as power related chips and temperature sensors.

  • Page 45: A-Key Slot

    NANO-ADL-P 3.2.14 M.2 A-key Slot CN Label: M2_A1 CN Type: M-key slot CN Location: See Figure 3-15 CN Pinouts: See Table 3-16 The M.2 2230 slot is keyed in the A position. Figure 3-15: M.2 A-key Slot Location Description Description +3.3V...

  • Page 46: Table 3-16: M.2 A-Key Connector Pinouts

    NANO-ADL-P Description Description PCIE_TX_DP PCIE_TX_DN WLAN_CL_RST_N WLAN_CL_DATA PCIE_RX_DP WLAN_CL_CLK PCIE_RX_DN PCIE_CLK+ PCIE_CLK- PLT_RST BT_ON PCH_WAKE_N WLAN_OFF +3.3V +3.3V Table 3-16: M.2 A-key Connector Pinouts Page 46...

  • Page 47: B-Key Slot

    NANO-ADL-P 3.2.15 M.2 B-key Slot CN Label: M2_B1 CN Type: M-key slot CN Location: See Figure 3-16 CN Pinouts: See Table 3-17 The M.2 2242/2280 slot is keyed in the B position. Figure 3-16: M.2 B-key Slot Location Description Description +V3.3...

  • Page 48: Table 3-17: M.2 B-Key Connector Pinouts

    NANO-ADL-P Description Description PCIE_1_RX_DN SIM_RST PCIE_1_RX_DP SIM_CLK SIM_CIO PCIE_1_TX_DN SIM_VCC PCIE_1_TX_DP M.2_SMCLK PCIE_0_RX_DN M.2_SMDATA PCIE_0_RX_DP PCIE_0_TX_DN PCIE_0_TX_DP PLT_RST_N PCIE_CLK_DN M.2_B_WAKE PCIE_CLK_DP +V3.3 +V3.3 +V3.3 Table 3-17: M.2 B-key Connector Pinouts Page 48...

  • Page 49: Pcie X4 Slots

    NANO-ADL-P 3.2.16 PCIe x4 Slots CN Label: PCIEX4_1 CN Type: PCIe x4 Slot CN Location: See Figure 3-17 The PCIe x4 slot enables a PCIe x4 expansion module to be connected to the board. Figure 3-17: PCIe x4 Slot Location...

  • Page 50: Idpm Slot

    NANO-ADL-P 3.2.17 IDPM Slot CN Label: IDPM CN Type: IEI iDPM slot CN Location: See Figure 3-18 The iDPM slot is only for IEI eDP/LVDS/VGA module Figure 3-18: IDPM Slot Location Description Description +3.3V +3.3V +3.3V +3.3V +3.3V Module Key...

  • Page 51: Table 3-18: Idpm Connector Pinouts

    NANO-ADL-P +3.3VS EDP_TX3_DN +12VS EDP_TX3_DP +12VS +12VS EDP_TX2_DN +12VS EDP_TX2_DP SMB_CLK EDP_TX1_DN SMB_DATA EDP_TX1_DP EC_BKLT_CTRL EDP_TX0_DN EDP1_BKLT_CTRL EDP_TX0_DP EDP1_BKLT_EN EDP1_VDD_EN # EDP_AUX_DN EDP_HPD_R EDP_AUX_DP BUF_PLT_RST# LVDS_EN +V5S +V5S +V5S +V5S +12VA +12VA +12VA +12VA Table 3-18: iDPM Connector Pinouts Page 51...

  • Page 52: Power Button Connector

    NANO-ADL-P 3.2.18 Power button connector CN Label: PWR_BTN1 CN Type: 2-pin header CN Location: See Figure 3-19 CN Pinouts: See Table 3-19 The power button allows users to turn the system on and off. Figure 3-19: Power Button Connector Location...

  • Page 53: Reset Button Connector

    NANO-ADL-P 3.2.19 Reset button connector CN Label: RST_BTN1 CN Type: 2-pin header CN Location: See Figure 3-20 CN Pinouts: See Table 3-20 The reset button connector is connected to a reset switch on the system chassis to enable users to reboot the system when the system is turned on.

  • Page 54: Sata 6Gb/S Connectors

    NANO-ADL-P 3.2.20 SATA 6Gb/s Connectors CN Label: SATA1 CN Type: 7-pin SATA connector CN Location: See Figure 3-21 CN Pinouts: See Table 3-21 The SATA drive connectors can be connected to SATA drives and support up to 6Gb/s data transfer rate.

  • Page 55: Sata Power Connectors

    NANO-ADL-P 3.2.21 SATA Power Connectors CN Label: SATA_PWR1 CN Type: 2-pin header CN Location: See Figure 3-22 CN Pinouts: See Table 3-22 The SATA power connector provides +5 V power output to the SATA connector. Figure 3-22: SATA Power Connector Location PIN NO.

  • Page 56: Serial Port Connectors

    NANO-ADL-P 3.2.22 RS-232 Serial Port Connectors CN Label: COM1, COM2, COM3, COM4 CN Type: 10-pin wafer, p=2.54 mm CN Location: See Figure 3-23 CN Pinouts: See Table 3-23 Each of these connectors provides RS-232 communications. Figure 3-23: RS-232 Connector Locations...

  • Page 57: Rs-232/422/485 Serial Port Connectors

    NANO-ADL-P 3.2.23 RS-232/422/485 Serial Port Connectors CN Label: COM5, COM6 CN Type: 10-pin wafer, p=2.54 mm CN Location: See Figure 3-24 CN Pinouts: See Table 3-24 Each of these connectors provides RS-232/422/485 communications. Figure 3-24: RS-232/422/485 Connector Locations Description Description...

  • Page 58: Flash Spi Rom Connector

    NANO-ADL-P 3.2.24 Flash SPI ROM Connector CN Label: J_SPI1 CN Type: 6-pin header, p=1.25 mm CN Location: See Figure 3-25 CN Pinouts: See Table 3-25 The Flash SPI ROM connector is used to flash the SPI ROM. Figure 3-25: Flash SPI ROM Connector Location...

  • Page 59: Flash Ec Rom Connector

    NANO-ADL-P 3.2.25 Flash EC ROM Connector CN Label: EC_SPI1 CN Type: 8-pin header, p=1.25 mm CN Location: See Figure 3-26 CN Pinouts: See Table 3-26 The Flash EC ROM connector is used to flash the EC ROM. Figure 3-26: Flash EC ROM Connector Location...

  • Page 60: Internal Usb 2.0 Connectors

    NANO-ADL-P 3.2.26 Internal USB 2.0 connectors CN Label: USB2_1, USB2_2 CN Type: 8-pin header, p=1.25 mm CN Location: See Figure 3-27 CN Pinouts: See Table 3-27 Each USB connector provides two USB 2.0 ports by dual-port USB cable. Figure 3-27: Internal USB 2.0 Connector Location...

  • Page 61: External Peripheral Interface Connector Panel

    USB3_1, USB3_2 CN Type: USB 3.2 CN Location: See Figure 3-29 CN Pinouts: See Table 3-28 The external dual USB 3.2 Gen 2 connectors on the NANO-ADL-P. Figure 3-29: External dual USB 3.2 Gen 2 connectors Description Description USB_DATA- USB_DATA- USB_DATA+...

  • Page 62: External Dual Hdmi Connector

    3.3.2 External dual HDMI Connector CN Label: HDMI1 CN Type: HDMI CN Location: See Figure 3-30 CN Pinouts: See Table 3-29 The external dual HDMI connectors on the NANO-ADL-P. Figure 3-30: HDMI Connectors Description Description HDMI_DATA2P HDMI_CLKN HDMI_DATA2N HDMI_DATA1P HDMI_CLK...

  • Page 63: External 2.5Gbe Rj-45 Connectors

    NANO-ADL-P Description Description HDMI_CLKP Table 3-29: HDMI Connector Pinouts 3.3.3 External 2.5GbE RJ-45 connectors CN Label: LAN1, LAN2 CN Type: RJ45 CN Location: See Figure 3-31 CN Pinouts: See Table 3-30 The LAN connector connects to a local network. DESCRIPTION...

  • Page 64: External Dp Connector

    NANO-ADL-P 3.3.4 External DP connector CN Label: CN Type: CN Location: See Figure 3-32 CN Pinouts: See Table 3-32 The external DP connectors on the NANO-ADL-P. Figure 3-32: DP Connector The external DP connectors. Description Description LANE0P LANE3N LANE0N CONFIG_A_1...

  • Page 65: Installation

    NANO-ADL-P Chapter Installation Page 65...

  • Page 66: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the NANO-ADL-P. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the NANO-ADL-P or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 67: Module Installation

    Allow screws to come in contact with the PCB circuit, connector pins, or its components. M.2 Module Installation The NANO-ADL-P provide two ways to install the M.2 expansion card. One is using screw, and the other is using the retainer. Please follow the steps below. Page 67...

  • Page 68: Figure 4-1: Inserting The M.2 Module Into The Slot At An Angle

    NANO-ADL-P Mode One: Using screw Step 1: Locate the M.2 module slot. See Chapter 3. Step 2: Remove the retention screw secured on the motherboard. Step 3: Line up the notch on the module with the notch on the slot. Slide the M.2 module into the socket at an angle of about 20º...

  • Page 69: Figure 4-3: Press The Retainer

    NANO-ADL-P Mode Two: Using the Retainer Step 1: Press the retainer down as shown below. (See Figure 4-3) Figure 4-3: Press the Retainer Step 2: Line up the notch on the M.2 module with the notch on the slot. Slide the M.2 module into the socket at an angle of about 20º.

  • Page 70: Figure 4-5: Securing The M.2 Module

    NANO-ADL-P Step 5: Press the M.2 module down until it is secured into place by the retainer. (See Figure 4-5) Figure 4-5: Securing the M.2 Module Step 6: If you want to remove the M.2 module, you should press the retainer down as described in Step 1 to release the M.2 module.

  • Page 71: Heat Spreader

    NANO-ADL-P without the heat spreader secured to the board. When the NANO-ADL-P is shipped, it is secured to a heat spreader with six retention screws. The heat spreader must have a direct contact with a heat dissipation surface to ensure stable operation.

  • Page 72: Riser Card Installation

    NANO-ADL-P Riser Card Installation The NANO-EHL features a PCIe x4 (x2 signal) slot, which is a new design of the motherboard to expand functionality. By installing an IEI-developed riser card into the PCIe slot, the x4 signal is divided into x2+x2 slots and x2+x1+x1 slots, offering great configuration flexibility and expandability.

  • Page 73: Figure 4-9: Inwards Riser Card Installation Example

    NANO-ADL-P The inwards-facing riser card (P/N: NWR-R2S- R10) is designed with higher height to keep a decent space between the expansion cards and the motherboard. This can help improve the airflow and heat transfer within the system. It is suitable for installation where space is limited.

  • Page 74: Figure 4-11:L-Shaped Bracket Installation Example

    NANO-ADL-P Both of the riser cards can be firmly secured to enhance stability by using the L-shaped bracket, in which screw holes are perfectly matched with those on the side of the heatsink and on the riser card, making it easy and convenient to install. See Figure 4-11.

  • Page 75: Internal Peripheral Device Connections

    This section outlines the installation of peripheral devices to the onboard connectors. 4.6.1 SATA Drive Connection The NANO-ADL-P is shipped with two SATA drive cables. To connect the SATA drives to the connectors, please follow the steps below. Step 1: Locate the connectors.

  • Page 76: At Power Connection

    The SATA power cable can be bought from IEI. See Optional Items in Section 2.4. 4.6.2 AT Power Connection Follow the instructions below to connect the NANO-ADL-P to an AT power supply. WARNING: Disconnect the power supply power cord from its AC power source to prevent a sudden power surge to the NANO-ADL-P.

  • Page 77: Figure 4-14: Power Cable To Motherboard Connection

    NANO-ADL-P Step 2: Connect the power cable to the motherboard. Connect the 4-pin (2x2) Molex type power cable connector to the power connector on the motherboard. See Figure 4-14 Figure 4-14: Power Cable to Motherboard Connection Step 3: Connect power cable to power supply. Connect one of the 4-pin (1x4) Molex type power cable connectors to an AT power supply.

  • Page 78: Channel Audio Kit Installation

    NANO-ADL-P 4.6.3 7.1 Channel Audio Kit Installation NOTE: This item must be ordered separately, and connects to the audio connector. For further information please contact the nearest distributor, reseller or vendor or contact an IEI sales representative directly. The audio kit attaches to the audio connector. The audio kit provides 7.1 channel audio.

  • Page 79: Software Drivers

    Install the driver. Install the 7.1 channel audio driver included with the board. Software Drivers 4.7.1 Software Installation All the drivers for the NANO-ADL-P are available on IEI Resource Download Center (https://download.ieiworld.com). Type NANO-ADL-P and press Enter to find all the relevant software, utilities, and documentation.

  • Page 80: Driver Download

    4.7.2 Driver Download To download drivers from IEI Resource Download Center, follow the steps below. Step 1: Go to https://download.ieiworld.com. Type NANO-ADL-P and press Enter. Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result.
  • Page 81 NANO-ADL-P NOTE: To install software from the downloaded ISO image file in Windows 8, 8.1 or 10, double-click the ISO file to mount it as a virtual drive to view its content. On Windows 7 system, an additional tool (such as Virtual CD-ROM Control Panel from Microsoft) is needed to mount the file.

  • Page 82: Bios

    NANO-ADL-P Chapter BIOS Page 82...

  • Page 83: Introduction

    NANO-ADL-P Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 84: Using Setup

    NANO-ADL-P 5.1.2 Using Setup The BIOS Setup menu can be navigated by using a keyboard or a touchscreen. 5.1.2.1 Keyboard Navigation For keyboard navigation, use the navigation keys shown in Table 5-1. Function Up arrow Move to previous item Down arrow...

  • Page 85: Touch Navigation

    NANO-ADL-P 5.1.2.2 Touch Navigation For touchscreen navigation, use the on-screen navigation keys shown below. On-screen Button Function Previous Values Load the last value you set. Optimized Defaults Load the factory default values in order to achieve the best performance. Back Return to the previous menu.

  • Page 86: Getting Help

    NANO-ADL-P 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window, press the key. 5.1.4 Unable to Reboot after Configuration Changes If the computer cannot boot after changes to the system configuration is made, CMOS defaults.

  • Page 87: Main

    NANO-ADL-P Main The Main BIOS menu (BIOS Menu 2) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS Menu 1: Main (1/3) BIOS Menu 2: Main (2/3) Page 87...
  • Page 88 NANO-ADL-P BIOS Menu 3: Main (3/3) ➔ BIOS Information The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information cannot be changed. The items shown in the system overview include: ▪ BIOS Vendor: Installed BIOS vendor ▪...
  • Page 89 NANO-ADL-P ▪ ID: Displays the Processor ID ➔ PCH Information The PCH Information lists a brief summary of the PCH. The fields in PCH Information cannot be changed. The items shown in the system overview include: ▪ Name: Displays the PCH Name ▪...

  • Page 90: Advanced

    NANO-ADL-P Advanced Use the Advanced menu (BIOS Menu 4) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.

  • Page 91: Cpu Configuration

    NANO-ADL-P 5.3.1 CPU Configuration Use the CPU Configuration menu (BIOS Menu 5) to view detailed CPU specifications or enable the Intel Virtualization Technology. BIOS Menu 5: CPU Configuration (1/3) Page 91...
  • Page 92 NANO-ADL-P BIOS Menu 6: CPU Configuration (2/3) BIOS Menu 7: CPU Configuration (3/3) Page 92...
  • Page 93 NANO-ADL-P ➔ Intel (VMX) Virtualization Technology [Enabled] Use the Intel (VMX) Virtualization Technology option to enable or disable virtualization on the system. When combined with third party software, Intel® Virtualization technology allows several OSs to run on the same system at the same time.
  • Page 94 NANO-ADL-P ➔ Enabled Enables CPU power management ➔ Turbo Mode [Enabled] Use the Turbo Mode option to enable or disable Turbo Mode which requires Intel Speed Step or Intel Speed Shift to be available and enabled. ➔ Disabled Disables Turbo Mode Technology ➔...

  • Page 95: Trusted Computing

    NANO-ADL-P ➔ Hyper-Threading [Enabled] Use the Hyper-Threading option to enable or disable the Hyper-Threading Technology. ➔ Disabled Disables Hyper-Threading Technology ➔ Enabled EFAULT Enables Hyper-Threading Technology 5.3.2 Trusted Computing Use the Trusted Computing menu (BIOS Menu 8) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM).

  • Page 96: Rtc Wake Settings

    NANO-ADL-P ➔ Enable TPM support is enabled. EFAULT ➔ Pending Operation [None] Use the Pending Operation option to schedule an operation for the security device. ➔ None TPM information is previous.S EFAULT ➔ TPM Clear TPM information is cleared 5.3.3 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 9) configures RTC wake event.
  • Page 97 NANO-ADL-P BIOS Menu 10: RTC Wake Settings (2/2) ➔ Wake system with Fixed Time [Enabled] Use the Wake system with Fixed Time option to enable or disable the system wake on alarm event. ➔ Disabled The real time clock (RTC) cannot generate a wake event ➔...

  • Page 98: F81966 Super Io Configuration

    NANO-ADL-P 5.3.4 F81966 Super IO Configuration Use the F81966 Super IO Configuration menu (BIOS Menu 11) to set or change the configurations for serial ports. BIOS Menu 11: F81966 Super IO Configuration Page 98...

  • Page 99: Serial Port 1 Configuration

    NANO-ADL-P 5.3.4.1 Serial Port 1 Configuration Use the Serial Port 1 Configuration menu (BIOS Menu 12) to configure the serial port. BIOS Menu 12: Serial Port 1 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 100: Serial Port 2 Configuration

    NANO-ADL-P 5.3.4.2 Serial Port 2 Configuration Use the Serial Port 2 Configuration menu (BIOS Menu 13) to configure the serial port. BIOS Menu 13: Serial Port 2 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 101: Serial Port 3 Configuration

    NANO-ADL-P 5.3.4.3 Serial Port 3 Configuration Use the Serial Port 3 Configuration menu (BIOS Menu 14) to configure the serial port. BIOS Menu 14: Serial Port 3 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 102: Serial Port 4 Configuration

    NANO-ADL-P 5.3.4.4 Serial Port 4 Configuration Use the Serial Port 4 Configuration menu (BIOS Menu 15) to configure the serial port. BIOS Menu 15: Serial Port 4 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 103: Serial Port 5 Configuration

    NANO-ADL-P 5.3.4.5 Serial Port 5 Configuration Use the Serial Port 5 Configuration menu (BIOS Menu 16) to configure the serial port. BIOS Menu 16: Serial Port 5 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 104: Serial Port 6 Configuration

    NANO-ADL-P ➔ RS232 The serial port mode is RS-232 EFAULT RS422 with Register The serial port mode is RS-422 RS485 with Register The serial port mode is RS-485 5.3.4.6 Serial Port 6 Configuration Use the Serial Port 6 Configuration menu (BIOS Menu 17) to configure the serial port.

  • Page 105: Ec Kb9068 H/W Monitor

    NANO-ADL-P ➔ IO=2C8h; Serial Port I/O port address is 2C8h and the interrupt IRQ=10 address is IRQ10 ➔ Device Mode [RS232] Use the Device Mode option to change the serial port mode. ➔ RS232 The serial port mode is RS-232...
  • Page 106 NANO-ADL-P ➔ PC Health Status The following system parameters and values are shown. The system parameters that are monitored are: ▪ System Temperatures: CPU Temperature System Temperature1 System Temperature2 ▪ Fan Speeds: CPU_Fan1 Speed ▪ Voltages: +VCCCORE +5VS +12S +V3.3S...

  • Page 107: Smart Fan Mode Configuration

    NANO-ADL-P 5.3.5.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 19) to configure the CPU/system fan start/off temperature and control mode. BIOS Menu 19: Smart Fan Mode Configuration ➔ CPU_FAN1 Smart Fan Control [Auto Mode] Use the CPU_FAN1 Smart Fan Control option to configure the CPU Smart Fan.

  • Page 108: Serial Port Console Redirection

    NANO-ADL-P ➔ CPU_FAN1 Off Temperature If the CPU temperature is lower than the value set this option, the fan speed change to be lowest. To set a value, Use the + or – key to change the value or enter a decimal number between 1 and 100.

  • Page 109: Console Redirection Settings

    NANO-ADL-P BIOS Menu 21: Serial Port Console Redirection (2/2) Console Redirection [Disabled] ➔ Use Console Redirection option to enable or disable the console redirection function. ➔ Disabled Disabled the console redirection function EFAULT ➔ Enabled Enabled the console redirection function The Console Redirection Settings submenu will be available when the Console Redirection option is enabled.

  • Page 110: Bios Menu 22: Com Console Redirection Settings

    NANO-ADL-P BIOS Menu 22: COM Console Redirection Settings ➔ Terminal Type [ANSI] Use the Terminal Type option to specify the remote terminal type. ➔ VT100 The target terminal type is VT100 ➔ VT100+ The target terminal type is VT100+ ➔...
  • Page 111 NANO-ADL-P ➔ 57600 Sets the serial port transmission speed at 57600. ➔ 115200 Sets the serial port transmission speed at 115200. EFAULT ➔ Data Bits [8] Use the Data Bits option to specify the number of data bits. ➔ Sets the data bits at 7.

  • Page 112: Nvme Configuration

    NANO-ADL-P 5.3.7 NVMe Configuration Use the NVMe Configuration (BIOS Menu 23) menu to display the NVMe controller and device information. BIOS Menu 23: NVMe Configuration Page 112...

  • Page 113: Chipset

    NANO-ADL-P Chipset Use the Chipset menu (BIOS Menu 24) to access the PCH IO and System Agent (SA) configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 114: System Agent (Sa) Configuration

    NANO-ADL-P 5.4.1 System Agent (SA) Configuration Use the System Agent (SA) Configuration menu (BIOS Menu 25) to configure the System Agent (SA) parameters. BIOS Menu 25: System Agent (SA) Configuration ➔ VT-d [Enabled] Use the VT-d option to enable or disable the VT-d capability.

  • Page 115: Memory Configuration

    NANO-ADL-P 5.4.1.1 Memory Configuration Use the Memory Configuration submenu (BIOS Menu 27) to view memory information. BIOS Menu 26: Memory Configuration (1/2) Page 115...
  • Page 116 NANO-ADL-P BIOS Menu 27: Memory Configuration (2/2) Page 116...

  • Page 117: Graphics Configuration

    NANO-ADL-P 5.4.1.2 Graphics Configuration Use the Graphics Configuration (BIOS Menu 28) menu to configure the video device connected to the system. BIOS Menu 28: Graphics Configuration ➔ Primary Display [Auto] Use the Primary Display option to select the primary graphics controller the system uses.
  • Page 118 NANO-ADL-P option should be set to Enabled and the above Primary Display option should be set to IGFX. ➔ Auto Auto mode ➔ Disabled Disables IGFX. ➔ Enabled Default Enables IGFX. ➔ DVMT Pre-Allocated [160M] Use the DVMT Pre-Allocated option to set the amount of system memory allocated to the integrated graphics processor when the system boots.

  • Page 119: Peg Port Configuration

    NANO-ADL-P 5.4.1.3 PEG Port Configuration BIOS Menu 29: PEG Port Configuration Page 119...

  • Page 120: Pch-Io Configuration

    NANO-ADL-P 5.4.2 PCH-IO Configuration Use the PCH-IO Configuration menu (BIOS Menu 30) to configure the PCH parameters. BIOS Menu 30: PCH-IO Configuration (1/2) Page 120...
  • Page 121 NANO-ADL-P BIOS Menu 31: PCH-IO Configuration (2/2) ➔ Auto Power Button Function [Disabled (AT)] Use the Auto Power Button Function BIOS option to show the power mode state. Use the J_ATX_AT1 to switch the AT/ATX power mode. ➔ Enabled (AT) The system power mode is AT.
  • Page 122 NANO-ADL-P ➔ Power Saving Function (EUP) [Disabled] Use the Power Saving Function (EUP) BIOS option to enable or disable the power saving function. ➔ Disabled Power saving function is disabled. EFAULT ➔ Enabled Power saving function is enabled. It will reduce power consumption when the system is off.

  • Page 123: Pci Express Configuration

    NANO-ADL-P 5.4.2.1 PCI Express Configuration Use the PCI Express Configuration submenu (BIOS Menu 32) to configure the PCI Express slots. BIOS Menu 32: PCI Express Configuration Page 123...

  • Page 124: Pcie Root Port Setting

    NANO-ADL-P 5.4.2.1.1 PCIe Root Port Setting Use the M.2 Slot(M2_M1), PCIE7 Slot(x1), PCIE6 Slot(x4), PCIE1 Slot(x4) submenu (BIOS Menu 33) to configure the PCIe Root Port Setting. BIOS Menu 33: PCIe Slot Configuration Submenu ➔ PCIe Speed [Auto] Use the PCIe Speed option to specify the PCI Express port speed. Configuration options are listed below.

  • Page 125: Sata Configuration

    NANO-ADL-P ➔ Disabled Do not detect if a non-compliance PCI Express EFAULT device is connected to the PCI Express port. ➔ Enabled Detect if a non-compliance PCI Express device is connected to the PCI Express port. 5.4.2.2 SATA Configuration Use the SATA Configuration menu (BIOS Menu 34) to change and/or set the configuration of the SATA devices installed in the system.
  • Page 126 NANO-ADL-P ➔ SATA Mode Selection [AHCI] Use the SATA Mode Selection option to determine how the SATA devices operate. ➔ AHCI EFAULT Configures SATA devices as AHCI device. ➔ Intel RST Premium Configures SATA devices to the Intel RST With...

  • Page 127: Hd Audio Configuration

    NANO-ADL-P 5.4.2.3 HD Audio Configuration Use the HD Audio Configuration menu (BIOS Menu 35) to configure the PCH Azalia settings. BIOS Menu 35: HD Audio Configuration ➔ HD Audio [Enabled] Use the HD Audio option to enable or disable the High Definition Audio controller.

  • Page 128: Security

    NANO-ADL-P Security Use the Security menu (BIOS Menu 37) to set system and user passwords. BIOS Menu 36: Security (1/2) Page 128...
  • Page 129 NANO-ADL-P BIOS Menu 37: Security (2/2) ➔ Administrator Password Use the Administrator Password to set or change an administrator password. ➔ User Password Use the User Password to set or change a user password. Page 129...

  • Page 130: Boot

    NANO-ADL-P Boot Use the Boot menu (BIOS Menu 38) to configure system boot options. BIOS Menu 38: Boot 5.6.1 Boot Configuration ➔ Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.

  • Page 131: Boot Option Priorities

    NANO-ADL-P ➔ Disabled Ignore all PXE Option ROMs EFAULT ➔ Enabled Load PXE Option ROMs. ➔ Option ROM Messages [Force BIOS] Use the Option ROM Messages option to set the Option ROM display mode. ➔ Force Sets display mode to force BIOS.

  • Page 132: Save & Exit

    NANO-ADL-P Save & Exit Use the Save & Exit menu (BIOS Menu 39) to load default BIOS values, optimal failsafe values and to save configuration changes. BIOS Menu 39: Save & Exit ➔ Save Changes and Reset Use the Save Changes and Reset option to save the changes made to the BIOS options and reset the system.
  • Page 133 NANO-ADL-P ➔ Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults. ➔ Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options.

  • Page 134: A Regulatory Compliance

    NANO-ADL-P Appendix Regulatory Compliance Page 134...
  • Page 135 NANO-ADL-P DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the...

  • Page 136: B Product Disposal

    NANO-ADL-P Appendix Product Disposal Page 136...
  • Page 137 NANO-ADL-P CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. ▪ Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 138: Cbios Options

    NANO-ADL-P Appendix BIOS Options Page 138...
  • Page 139 NANO-ADL-P Below is a list of BIOS configuration options in the BIOS chapter. ➔ BIOS Information .........................88 ➔ Processor Information ......................88 ➔ PCH Information ........................89 ➔ System Date [xx/xx/xx] ......................89 ➔ System Time [xx:xx:xx] .......................89 ➔ Intel (VMX) Virtualization Technology [Enabled] ..............93 ➔...
  • Page 140 NANO-ADL-P ➔ CPU_FAN1 Smart Fan Control [Auto Mode] ..............107 ➔ CPU_FAN1 Start Temperature ..................107 ➔ CPU_FAN1 Off Temperature .....................108 ➔ CPU_FAN1 Start PWM .......................108 ➔ Console Redirection [Disabled]..................109 ➔ Terminal Type [ANSI] ......................110 ➔ Bits per second [115200] ....................110 ➔...
  • Page 141 NANO-ADL-P ➔ Restore User Defaults .......................133 Page 141...

  • Page 142: D Watchdog Timer

    NANO-ADL-P Appendix Watchdog Timer Page 142...
  • Page 143 NANO-ADL-P NOTE: The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for other operating systems. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug.
  • Page 144 NANO-ADL-P NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ; ADD THE APPLICATION PROGRAM HERE EXIT_AP, 1 ;is the application over?

  • Page 145: E Error Beep Code

    NANO-ADL-P Appendix Error Beep Code Page 145...

  • Page 146: Pei Beep Codes

    NANO-ADL-P E.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available E.2 DXE Beep Codes...

  • Page 147: F Hazardous Materials Disclosure

    NANO-ADL-P Appendix Hazardous Materials Disclosure Page 147...

  • Page 148: Rohs Ii Directive (2015/863/Eu)

    NANO-ADL-P F.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 149: China Rohs

    NANO-ADL-P F.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572- 2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 149...

Table of Contents
