Depaepe Telecom HD2000 User Manual page 33

Anonymous Call
Rejection
Check SIP User ID for
Incoming INVITE
Auto answer
Allow Auto answer
by Call-Info
Session Expiration
Turn off speaker on
remote disconnect
Min-SE
Caller Request Timer
Callee Request
Timer
Force Timer
UAC Specify
Refresher
UAS Specify
Refresher
Force Invite
Hook flash Timing
Default is No. If set to Yes, incoming calls with anonymous Caller
ID will be rejected with 486 Busy message.
When the phone receive INVITE, at first it will check if it is right the
'To' in the message.
Enable or disable the 'auto answer' feature
Enable or disable 'auto answer' when some call use Call-info to
activate this feature
The SIP Session Timer extension enables SIP sessions to be
periodically "refreshed" via a SIP request (UPDATE, or re-INVITE.
Once the session intervaexpires, if there is no refresh via a
UPDATE or re-INVITE message, the session is terminated.
Session Expiration is the time (in seconds) at which the session is
considered timed out, provided no successful session refresh
transaction occurs beforehand. The default value is 180 seconds.
When the remote user hang up, the phone will disable the
speaker.
Defines the minimum session expiration (in seconds). Default is
90 seconds.
If set to "Yes", the phone will use session timer when it makes
outbound calls if remote party supports session timer.
If selecting "Yes", the phone will use session timer when it
receives inbound calls with session timer request.
If set to "Yes", the phone will use session timer even if the remote
party does not support this feature. If set to "No", the session timer
is enabled only when the remote party supports this feature. To
turn off Session Timer, select "No" for Caller Request Timer,
Callee Request Timer, and Force Timer.
As a Caller, select UAC to use the phone as the refresher, or UAS
to use the Callee or proxy server as the refresher.
As a Callee, select UAC to use caller or proxy server as the
refresher, or UAS to use the phone as the refresher.
Session Timer can be refreshed using INVITE method or
UPDATE method. Select "Yes" to use INVITE method to refresh
the session timer.
The time break for hook flash
33
