Depaepe Telecom HD2000 User Manual page 32

Account Ring Tone
Disable Call -Waiting
Disable Call –Waiting
Tone
Ring Timeout
Use # as Send Key
Dial Plan
Subscribe for MWI
Send Anonymous
There are 4 uniquely defined ring tones:
• One (1) System Ring Tone: when selected, all calls will ring with
system ring tone.
• Three (3) Customer Ring Tones: when selected, incoming calls
from designated account will play selected ring tone.
Default is No.
Default is No. This is to disable the stutter Call Waiting Tone when
a Call Waiting call arrives. The CWCID will still be displayed.
Incoming call will stop ringing when not picked up given a specific
period of time.
This parameter allows users to configure the "#" key to be used as
the "Send" (or "Dial") key. If set to "Yes", pressing this key will
immediately trigger the sending of dialed string collected so far. In
this case, this key is essentially equivalent to the "(Re)Dial" key. If
set to "No", this "#" key will then be included as part of the dial string
to be sent out.
Dial Plan Rules:-
1. Accept Digits: 1,2,3,4,5,6,7,8,9,0
2. Grammar: x - any digit from 0-9;
a. xx+ - at least 2 digit number;
b. ^ - exclude;
c. [3-5] - any digit of 3, 4, or 5;
d. [147] - any digit 1, 4, or 7;
e. <2=011> - replace digit 2 with 011 when dialing
• Example 1: {[369]11 | 1617xxxxxxx} –
Allow 311, 611, 911, and any 10 digit numbers of leading digits
1617
• Example 2: {^1900x+ | <=1617>xxxxxxx} –
Block any number of leading digits 1900 and add prefix 1617 for
Any dialed 7 digit numbers
• Example 3: {1xxx[2-9]xxxxxx | <2=011>x+} –
Allow any length of number with leading digit 2 and 10 digit-
numbers of leading digit 1 and leading exchange number between 2
and 9; If leading digit is 2, replace leading digit 2 with 011 before
dialing
3. Default: Outgoing - {x+}
Default is No. When set to "Yes" a SUBSCRIBE for Message
Waiting Indication will be sent periodically.
If this parameter is set to "Yes", the "From" header in outgoing
INVITE message will be set to anonymous, essentially blocking the
Caller ID from displaying.
32
