Account Options - Depaepe Telecom HD2000 User Manual

Account
Settings Options
Account active
SIP Server
Outbound Proxy
NAT Traversal
SIP User ID
Authenticate ID
Authenticate Password
Name
Use DNS SRV
User ID is Phone
Number
SIP Registration
Unregister on Reboot
Register Expiration
Meaning
When set to Yes the FXS port is activated
This field contains the URI string or the IP address (and port, if
different from 5060) of the SIP proxy server. e.g., the following
are
some valid examples: sip.my-voip-provider.com, or
sip:my-company-sip-server.com, or 192.168.1.200:5066
This field contains the URI string or the IP address (and port, if
different from 5060) of the outbound proxy. If there is no
outbound
proxy, this field SHOULD be left blank. If not blank, all outgoing
requests will be sent to this outbound proxy.
This parameter defines whether or not the HD2000IP NAT
traversal
mechanism is activated. If activated (by choosing "Yes") and a
STUN
server is also specified, then the HD2000IP performs according
to the STUN client specification. Using this mode, the embedded
STUN client will detect if and what type of firewall/NAT is being
used. If the detected NAT is a Full Cone, Restricted Cone, or a
Port-Restricted Cone, the HD2000IP will use its mapped public
IP address and port in all of its SIP and SDP messages. If the
NAT Traversal field is set to
"Yes" with no specified STUN server, the HD2000IP will
periodically (every 20 seconds or so) send a blank UDP packet
no payload data) to the SIP server to keep the "hole" on the NAT
open.
SIP service subscriber's User ID
SIP service subscriber's Authenticate ID. Can be identical to or
different from SIP User ID
SIP service subscriber's account password
SIP service subscriber's name which will be used for Caller ID
display
Default is No. If set to Yes the client will use DNS SRV for server
lookup
If the HD2000IP has an assigned PSTN telephone number, this
field
should be set to "Yes". Otherwise, set it to "No". If "Yes" is set, a
"user=phone" parameter will be attached to the "From" header in
SIP request
This parameter controls whether the HD2000IP needs to send
REGISTER messages to the proxy server. The default setting is
"Yes".
Default is "No." If set to "Yes", then the SIP user will be
unregistered on reboot.
This parameter allows the user to specify the time frequency (in
