9700 Mobile Computer (CE)

1.1. TAKE A TOUR

This section shows the major components on the mobile computer and inside battery
chamber. You will also learn how to power on/off the mobile computer and how the mobile
computer gives information about its status.

1.1.1. OVERVIEW

Figure 1: Overview
No. Description
1
Status LED (refer to
3 Touchscreen
5 Side-trigger (user definable)
7 Direct charging & communication port
9 Scan window
11 Speaker
13 Side-trigger (user definable)
15 Handstrap
4
Notifications
)
No. Description
2 Light sensor
4 Scan key
6 Microphone
8 Power key
10 Headset jack
12 Battery
14 Stylus (with attaching cord)
