ADA INSTRUMENTS COSMO 70eter Operating Manual page 12

1 COSMO 70
After the completion of area, press button (1) , the result of addition/substraction of areas is displayed in
the main display area. If the measurements are not finished, press button (5) (addition) or (3) (substraction)
to continue calculations.
Volume
For volume measurements, press button (2) twice until the indicator for volume measurement appears on
the display.
Press button (1) to take the first measurement (for example, length). Measured value is displayed in the
second line.
Press button (1) to take the second measurement (for example, width). Measured value is displayed in the
second line. Area value is displayed in the first line.
Press button (1) to take the third measurement (for example, height). Measured value is displayed in the
second line.
The volume value will be displayed in the main display area and the previous area value is displayed in the first line.
