ADA INSTRUMENTS COSMO 70eter Operating Manual page 20

0 COSMO 70
* In favourable conditions (good target surface properties, room temperature).
Maximum deviation occurs under unfavorable conditions such as bright sunlight or when measuring to
poorly reflecting or very rough surfaces. Use target plate for accurate results.
Measuring conditions
Measuring range: the range is limited to 70 m. At night, at dusk and when the target is shadowed the mea-
suring range without target plate is increased. Use a target plate to increase the measurement range during
daylight or if the target has a bad reflection.
Measuring Surfaces
Measuring errors can occur when measuring toward colorless liquids (e.g. water) or dust free glass, styro-
foam or similar semi-permeable surfaces. Aiming at high gloss surfaces deflects the laser beam and mea-
surement errors can occur. Against non-reflective and dark surfaces the measuring time can be increased.
