5.
Click Next . The program extracts the firmware files and places them in a folder
identified in the InstallShield Wizard window.
NOTE:
Note the folder to which the firmware file is saved.
6.
Click Finish to exit the program.
7. Connect a computer that runs the Windows operating system to either the RS-232 port
or the Configuration port of the DA (see
page 4, for more details).
8. Start the FOX Extenders Program and connect to the front panel Configuration (USB)
port on the DA (see "Starting the
9.
Click Tools > Update firmware
Firmware Loader appears (see figure 13, below).
10
Figure 13. Extron Firmware Loader Window and File Menu
10. Select the FOX DA8 Plus and click
appears (see figure 14, below).
Figure 14. Choose Firmware File Window
11.
Navigate to and select the new firmware file. Click
window closes.
ATTENTION: The firmware file must have an .s19 extension. Other file types can
cause the DA to stop functioning.
NOTES: • When downloaded from the Extron website, the firmware is placed in a
subfolder of
• Valid firmware files must have the file extension .S19. A file with any
other extension is not a firmware upgrade.
• The original factory-installed firmware is permanently available on the
DA. If the attempted firmware upload fails for any reason, the DA reverts
to the factory-installed firmware.
"Installation and
program," on page 14).
or the Update Firmware button ( ). The Extron
> . The Choose Firmware File screen
File Open
11
11
Open
C:\Program Files\Extron\Firmware
FOX DA8 Plus • Remote Control
Operation," starting on
. The Choose Firmware File
.
17
