Powercom 1000A User Manual page 4

D : \ m a n u a l \ U M _ P C M - B N T \ 6 6 1 - B T 1 K - 0 0 0 . d o c
A T
PPENDIX A ROUBLESHOOTING
PROBLEM POSSIBLE CAUSE
UPS can not Power switch not pushed or
turn on LED not push-time too short
light
Battery voltage less than 20V
PCB failure
Load less than 20W at battery
mode
UPS always at Power cord lose
battery mode
AC fuse burn out
Line voltage too high, too low
or black out
PCB failure
Back up time battery not fully charged
too short
PCB failure
Buzzer Overload
continuous
beeping
A S
PPENDIX B PECIFICATIONS
MODEL 1000A/AP
INPUT Capacity 1000VA
Voltage 100V,110V,115V,120V,220V,230V,240V, +/-25% at
Frequency
OUTPUT Voltage Simulated sine wave like rating voltage, +/-5%
(Backup mode)
Frequency
(Backup Mode)
Auto Voltage AVR automatically increase output voltage 15%
Regulation (AVR above input voltage if -9% to-25% of nominal.
function under AVR decrease output voltage 13% below input
Normal mode)
Transfer Time 2/4 milliseconds, including detection time
ACTION TO TAKE
Press the power switch more
than 1 second
Recharge the UPS at least 6
hours
Replace the PCB, call for
service
Normal condition, "No load
shutdown function" is active
(See 3.2)
Plug in the power cord
Replace the AC fuse or Breaker
Normal condition
Replace PCB, call for service
Recharge the UPS at least 6
hours
Replace PCB, call for service
Remove some loads
1500A/AP 2000A/AP
1500VA 2000VA
line input
50 or 60Hz +/- 10% (auto sensing)
50 or 60Hz +/- 1Hz
voltage if+9% to +25% of nominal
- 7 -
D : \ m a n u a l \ U M _ P C M - B N T \ 6 6 1 - B T 1 K - 0 0 0 . d o c
PROTECTION Overload UPS automatic shutdown if overload exceeds
And Protection 110% of nominal at 60 seconds and 130% at 3
FILTERING
Unit Input Fuse for overload & short circuit protection
Short Circuit UPS output cut off immediately or input fuse
BATTERY Type
Typical
Recharge Time
Back up Time
(PC with 15" minutes
monitor)
PHYSICAL Dimension(mm)
WxDxH
Input Inlet
Receptacles NEMA5-15R(115V), IEC320 female appliance
ALARM Battery Back-Up
Battery Low
Overload
ENVIRONMENT Ambient 3,500 meters max. elevation, 0-95% humidity
operation
Audible Noise
Storage
condition
©2002. July. 29 Version 4.0
All right Reserved. All trademarks are property of their respective owners.
Specifications subject to change without notice.
seconds
protection
Sealed, maintenance-free lead acid
4 hours
(to 90% of full capacity)
60-70 70-80 80-90
minutes minutes
130x382x201
IEC 320 power inlet
coupler(220V)
Slow beeping sound
(once per 2 seconds)
Rapid beeping sound
(once per 0.5 second)
Continue beeping sound
non-condensing, 0-40℃
<40dBA(1 meter from surface)
15,000 meters max.
