Tribute DV
(Model 8050)
GAS-FIRED DIRECT-
VENT HEATER
Owner's Manual &
Installation Guide
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion can result
causing property damage, personal injury or loss of
life.
Do not store or use gasoline or other flammable vapors
and liquids near this or any other gas appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use
phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow your gas supplier's
instructions.
If you cannot reach your gas supplier, call the fire
department.
A qualified installer, service agency or gas supplier
must
perform
installation
Commonwealth of Massachusetts requires that a
licensed gas fitter or licensed plumber install all gas
lines and gas fittings.
HearthStone Quality Home Heating Products, Inc.
317 Stafford Avenue,
Morrisville, Vermont 05661-8695
E-Mail: Inquiry@hearthstonestoves.com
www.hearthstonestoves.com
READ THIS OWNER'S MANUAL -
and maintain this gas heater according to this instruction
manual.
AVERTISSEMENT: Assurez-vous de bien suivre les
instructions donné dans cette notice pour réduire au
minimum le risque d'incendie ou pour éviter tout
dommage matéeriel, toute blessure ou la mort.
Ne pas entresposer ni utiliser d'essence ni d'autre
vaperurs ou liquides inflammables dans le voisinage de
cet apprareil ou de tout autre appareil.
the
and
service.
The
L'installation et service doit être exécuté par un
installateur qualifié, agence de service ou le
fournisseur de gaz.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur.
servir des téléphones se trouvant dans le
batiment où vous vous trouvez.
Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incendies.
Operate
Ne pas vous
du
Tribute Model #8050
Manual: 6400-40423
Revised: 1/10/2008
