Operate And Maintain This Gas Heater According To This Instruction Manual.
WARNING: IF THE INFORMATION IN THESE
INSTRUCTIONS IS NOT FOLLOWED EXACTLY, A
FIRE OR EXPLOSION CAN RESULT CAUSING
PROPERTY DAMAGE, PERSONAL INJURY OR
LOSS OF LIFE.
Do not store or use gasoline or other flammable vapors and
liquids near this or any other gas appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use the phone
in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow your gas supplier's
instructions.
If you cannot reach your gas supplier, call the fire
department.
A qualified installer, service agency or gas supplier must
perform installation and service. The Commonwealth of
Massachusetts requires that a licensed gas fitter or licensed
plumber install all gas lines and gas fittings.
READ THIS OWNER'S MANUAL
Save These Instructions!
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE
POUR RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE
OU POUR ÉVITER TOUT DOMMAGE MATÉERIEL,
TOUTE BLESSURE OU LA MORT.
Ne pas entresposer ni utiliser d'essence ni d'autre vaperurs ou
liquides inflammables dans le voisinage de cet apprareil ou de
tout autre appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas vous servir des
téléphones se trouvant dans le batiment où vous vous
trouvez.
Appelez immédiatement votre fournisseur de gaz depuis
un voisin. Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz, appelez
le service des incendies.
L'installation et service doit être exécuté par un installateur
qualifié, agence de service ou le fournisseur de gaz.
Tribute DV
GAS-FIRED DIRECT-VENT HEATER
Owner's Manual
& Installation Guide
(Model 8050)
Tribute Model #8050
Manual: 6400-40423
Revision: 7 - 8/4/2010
Advertisement
Table of Contents
Related Manuals for HearthStone 8050
Summary of Contents for HearthStone 8050
-
Page 1: Save These Instructions
L’installation et service doit être exécuté par un installateur Massachusetts requires that a licensed gas fitter or licensed qualifié, agence de service ou le fournisseur de gaz. plumber install all gas lines and gas fittings. Tribute Model #8050 Manual: 6400-40423 Revision: 7 - 8/4/2010... - Page 2 Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Intentionally Blank...
- Page 3 Use this page to record all relevant information concerning the purchase, installation, and maintenance of your Tribute DV Model 8050 Direct -Vent heater. This information will facilitate servicing, purchase of replacement parts, and warranty claims (if necessary). Keep your original receipt in a safe place as proof of purchase.
-
Page 4: Table Of Contents
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Table of Contents ............................5 NTRODUCTION ..............6 PECIFIED ENTING ANUFACTURER ONTACT NFORMATION ............................7 PECIFICATIONS ’ .......................... 8 WNER NFORMATION ............................8 AILY PERATION ..............................8 FFICIENCY ’ ........................9... -
Page 5: Ntroduction
NTRODUCTION Congratulations on your purchase of Hearthstone’s Never Burn Paper, Wood or Other Tribute DV Model 8050 Gas-Fired Direct Vent heater. Materials The Tribute DV incorporates the latest in balanced This gas heater is designed to burn natural gas (NG) vent gas technology, which will provide you with or liquid propane (LP). -
Page 6: Specified Venting Manufacturer Contact Information
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Certified for use by: Selkirk Corporation Board of State Examiners of Plumbers and Gasfitters http://www.selkirkinc.com/ 100 Cambridge Street, Room 1511 1.800.992.VENT (8368) Boston, Massachusetts 02202 sales@selkirkinc.com custsvc@selkirkinc.com PECIFIED ENTING ANUFACTURER... -
Page 7: Specifications
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 PECIFICATIONS : Gas-Fired Direct-Vent Fireplace Heater ISTED AS Model: Tribute DV Model 8050 Direct-Vent Gas Certified for Canada, CSA P.4.1 Fireplace Heater Testing Agency: Intertek Testing Services, Inc. Approved for Mobile Home Installation Tested to: ANSI Z21.88b –... -
Page 8: Wner Nformation
“OFF”. The unit should be cool prior to back into service, follow the lighting instructions servicing and cleaning. Use of any components not described on page 24. supplied by Hearthstone on the stove voids all warranties. substitute components. -
Page 9: Installer ' S Information
Note: Vent kits and components are supplied separately. Failure to use the venting components NATIONAL FIRE PROTECTION ASSOCIATION, INC. specified by Hearthstone QHHP, Inc. will void your BATTERY MARCH PARK warranty and could risk a fire. QUINCY, MA 02269 www.nfpa.org... -
Page 10: Installing The Tribute Dv
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 NSTALLING RIBUTE Minimum clearances to combustibles must be EARTH EQUIREMENT LOOR ROTECTION maintained as shown in the illustrations of the The Tribute DV may be placed on a noncombustible Clearances To Combustibles section. -
Page 11: Acceptable Direct -Vent Termination Cap Locations
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 CCEPTABLE IRECT ERMINATION OCATIONS Figure 3: Termination Location clearances... -
Page 12: Enting Nformation
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 ENTING NFORMATION 1” - Below and along the side of all horizontal pipes. ONNECTION 2” - On top of all horizontal pipes. 1. The Tribute DV Direct Vent is approved for installation only with the vent connecting &... - Page 13 Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Figure 4: Venting Restrictor configurations...
-
Page 14: Approved Venting System Components
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Thimble Covers PPROVED ENTING YSTEM OMPONENTS Wall thimble (The following are components that are available, but not necessary for all installations) Elbow HIMNEY INER YSTEM Elbow 1. Direct-Vent Chimney Liner Termination Kit 6"... - Page 15 Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Termination wall thimble wall thimble cover You must have a 1/4" of rise per horizontal foot of venting. Depending on your install the centerline will vary. Figure 6: Components for a minimum horizontal vent configuration...
-
Page 16: Electrical Connections
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 LECTRICAL ONNECTIONS NOTE: open valve door on the lower front of unit for electrical and gas connections. HERMOSTAT Placement of the thermostat on an inside wall ON/OFF/T’stat switch wall mounted rather than an outside wall is preferable. -
Page 17: Wiring Instructions
DÉBRANCHEMENT. DES ERREURS DE CÂBLAGE PEUVENT ENTRAÎNER UN FONCTIONNEMENT INADEQUAT ET DANGERUX.) THE PROPER LOCATION OF WIRE CONNECTIONS IS SHOWN IN FIGURE 7. Wiring Diagram - Tribute Wiring Color KEY: 30 c 50 60 70 80 90 Hearthstone 50 70 90 Figure 7: Tribute 8050 Wiring diagram... -
Page 18: As Upply Onnections
ONNECTIONS Figure 8: Gas control valve WARNING: THE UNIT MUST BE INSTALLED AND NFPA Code and Hearthstone require the use of a CONNECTED IN ACCORDANCE WITH LOCAL dedicated sediment trap just upstream of the unit. CODES, OR IN THE ABSENCE OF LOCAL CODES,... - Page 19 Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Specifications for the type of fuel in use (natural gas RESSURE DJUSTMENT or LP), by connecting a manometer to the supply line adjusting incoming pressure NOTE: A QUALIFIED TECHNICIAN MUST...
-
Page 20: Log Placement
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 LACEMENT CAUTION: FRAGILE! HANDLE LOG SET WITH CARE. ALWAYS WEAR GLOVES AND SAFETY GOGGLES WHILE HANDLING THE LOG SET. Place only the ceramic log set supplied with the unit in the firebox. Do not place any other ceramic logs, wood logs, or other materials in the firebox. -
Page 21: Removal Of Log Set
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 EMOVAL OF To remove the Fire log set, follow the Installation of Log Set instructions in the reverse order. CAUTION: THE FIRELOG SET RETAINS HEAT AND CAN BE VERY HOT! ALLOW 2 TO 3 HOURS AFTER PILOT LIGHT IS TURNED OFF BEFORE HANDLING. -
Page 22: Stone Installation
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 TONE NSTALLATION Standard Stone Kit Contents: 3-Top Stones: 6-3/8” x 13-1/8” 4-Side Stones: 7-3/4” x 10-3/4” Standard Kit Part Numbers: 9050-41 Polished Soapstone 9050-63 Aztec Green Marble 9050-53 Autumn Brown Granite... -
Page 23: First Time
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 IGHTING THE NIT FOR THE IRST WARNING: IF YOU DO NOT FOLLOW THESE match or by any means other than the piezoelectric INSTRUCTIONS EXACTLY, FIRE spark. EXPLOSION MAY RESULT CAUSING PROPERTY... -
Page 24: Nitial Djustments
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 NITIAL DJUSTMENTS Once the Tribute DV is in place, connected and 6. Push in control knob all the way and hold in. assembled as described in the “Clearances To Immediately light the pilot with the gas lighter Combustibles”,... -
Page 25: Air Shutter Adjustments
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 ON/OFF/T’stat switch has been turned to “ON”, the Some conditions cannot be corrected through air main burner should light immediately. If you would shutter adjustment; an adjustment must be made to... - Page 26 Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 with the variable output control knob at its highest setting (turn fully clockwise). Allow the unit to operate for 10 minutes enabling the entire unit to PILOT reach temperature and for the flame pattern to...
-
Page 27: Routine Maintenance And Care
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 OUTINE AINTENANCE AND Tribute requires minimal routine burning from each burner port. The pilot flame maintenance and care. It should always be cool and should be large enough to engulf the thermopile off when being cleaned, or serviced. -
Page 28: Glass Cleaning
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Allow an extra 1 to 2” (25-50mm), and mark the occasionally. Do not use abrasive cleaners. spot to be cut. Scratching the glass will weaken the integrity of the glass. Do not clean the glass when hot! Allow the 6. -
Page 29: Parts List
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 ARTS Part No. Description Part No. Description 2010-210 FOOT 7211-580 LOG: CENTER BOTTOM 2010-505 BOTTOM 7211-581 LOG: CENTER REAR 2010-520 COLUMN 7211-582 LOG: LEFT BOTTOM 2010-530 FRONT 7211-583 LOG: LEFT UPPER... -
Page 30: Roubleshooting
Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 ROUBLESHOOTING Symptom Possible Cause Corrective Action 1. Pilot will not A. Insufficient gas pressure, A. Using the piezo sparker, try to light the pilot. If it will not light. air in the pilot line, or dirty or light, check the inlet gas pressure. - Page 31 Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Symptom Possible Cause Corrective Action 3. Pilot burning, no A. Thermostat switch or A. Check thermostat/wiring for proper connections. Place gas to main burner, wires defective. jumper wire across terminals at thermostat. If burner comes valve knob in the on, replace defective thermostat.
- Page 32 Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Symptom Possible Cause Corrective Action 8. Floating flames, A. Potentially dangerous A. Check the appliance input rate and reduce if necessary. lazy ill-defined, incomplete combustion due The air intake/exhaust flow system may be too restrictive or...
-
Page 33: Rating Label
2” / 50mm EDGE OF TOP TO DIAGONAL WALL Several Optional kits are available through HearthStone or your local HearthStone dealer. A blower assembly may be used (kit # 90-57501) , two different remote controls (kit #90-56912 & kit #90-56914), and an optional viewing screen is also available (90-69500). -
Page 34: Limited Warranties
Accessories and electrical components such as blowers, switches and thermo discs, excluding venting components, hearth components, electrical components and other components or accessories used in conjunction with the installation of the Stove not manufactured, or supplied by Hearthstone – against breakage or malfunction. - Page 35 9. A defect in any part of the Stove if the Original Purchaser fails to comply with Hearthstone’s or a Dealer’s request to ship the part or the Stove to Hearthstone or a Dealer, as the case may...
-
Page 36: Warranty Registration
Stove to and from Hearthstone or an authorized Dealer, as the case may be. Notwithstanding any other provision of this document, in no event will Hearthstone pay for any Dealer fees or other fees for pick up or delivery of the Gas Stove returned for repair; the Original Purchaser shall be responsible for any such fees. - Page 37 Hearthstone Quality Home Heating Products, Inc. Tribute DV Model #8050 Notes:...
