Coding Transmitters
fi g 24
fi g 25
fi g 26
GDO-6v4 EasyRoller
20
® Owner Installation Instructions
Step 10.5 - Code a Transmitter Button to
Enable AUX OUTPUT
a. Briefl y press the DOOR CODE button two (2)
times, then press it again and hold (will beep
three times on third press (Fig. 24)).
b. Press one of the four buttons on the transmitter
for two (2) seconds, pause for two (2) seconds,
then press the same button again for two (2)
seconds.
c. Release the DOOR CODE button.
d. Press the transmitter button to test.
Step 11 - Easy Access Transmitter (EAT)
Coding
a. Press and hold the DOOR CODE button (Fig. 24).
b. Press the EAT's button for two (2) seconds, pause
for two (2) seconds, then press the button again
for two (2) seconds (Fig. 25).
c. Release the DOOR CODE button.
d. Press the transmitter button to test.
Step 12 - Remotely Coding Transmitters
Using this method, transmitters can be coded without
access to the opener's control panel as long as a pre-
coded transmitter is available.
IMPORTANT NOTE: The door or courtesy light
must activate when the steps below are performed.
This indicates that the pre-coded transmitter is in
range of the opener, and the correct button has
been pressed.
a. Take any pre-coded transmitter. Press the button
for the function to be duplicated and release. If
the door is running, stop it by pressing the same
button again
b. Using a small needle, press and hold fi rmly for (2)
two seconds through the Coding Hole (Fig. 26).
c. WITHIN 10 SECONDS, take the additional
transmitter you wish to code. Decide which
button that you want to activate the function to
be duplicated (e.g. activate the door, or turn on
the courtesy light).
d. Hold the new transmitter's button for two (2)
seconds, pause for two (2) seconds, hold again
for two (2) seconds and then release.
e. Wait for 10 seconds and then press the new
transmitter's button to test.
