10.2
Contact assignment
10.2.1
LAN/WAN interface 10/100Base-TX, DSL interface
8-pin RJ45 socket, corresponding to ISO 8877, EN 60603-7
Connector
10.2.2
Configuration interface (Outband)
8-pin mini-DIN socket
Connector
Pin
IAE
1
T+
2
T-
3
R+
4
PoE/G
5
PoE/G
6
R-
7
PoE/-48 V
8
PoE/-48 V
Pin
1
2
3
4
5
6
7
8
U
LANCOM 3850 UMTS
Chapter 10: Appendix
IAE
CTS
RTS
RxD
RI
TxD
DSR
DCD
DTR
GND
83
