- Page 1 CLUX-18W 1 by 8 HDMI 1.3 Splitter Operation Manual CLUX-18W...
- Page 3 Revision History Version No Date Summary of Change 20090209 Preliminary Release 20090403 Cable Distance 1080p/8bit 10M in/15M out 1080p/12bit 6M in/10M out Precautions Failure to follow the precautions described below may cause damage to 1 by 8 HDMI 1.3 Splitter and void the warranty. DO NOT open the case.
-
Page 4: Table Of Contents
Table of Contents Introduction…………………………………………........ Applications......…………………………………………… Package contents..…………………………………………..……. 1 System Requirements....………………………………..……….. Features......……………………………………………….. Installation ......…………………………………………….. Front Panel......…………………………………………….. Bottom Panel......………………………………………….. Connection and Installation.............. Specifications.................. -
Page 5: Introduction
1. Introduction The HDMI v1.3 Splitter is the most advance solution for HDMI signal distribution. This device defines and support Deep Color (8 bit & 12 bit) video with new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, a high bandwidth up to 225MHz (6,75Gbps). -
Page 6: Features
5. Features HDMI v1.3, HDCP1.1 and DVI1.0 compliant Receiver. Deep Color video up to 12bit, 1080p(24/60Hz). One HDMI source connect up to eight HDMI displays simultaneously. HDCP keysets allows each output to work independently when connecting to a HDMI display. Splits a HDMI source up to eight outputs without signal loss. -
Page 7: Installation
6. Installation ① . HDMI OUTPUT 1~8: Front Panel Connect your LCD TV or HD monitor with EHDMI cables. ② . EDID selection: STD/TV – By switching to STD user can select both deep color and audio channels function, if switching to TV the unit will read TV ’... -
Page 9: Bottom Panel
Bottom Panel ① . DC 5V: Plug the 5VDC power supply into the unit and connect the adaptor to AC wall outlet. Red LED will illuminate when the Power is On. ① 7. Connection and Installation LCD TV LCD TV LCD TV LCD TV LCD TV... -
Page 10: Specifications
8. Specifications Frequency bandwidth 2.25Gbps (single link) Input port 1 x HDMI Female port Output ports 8 x HDMI Female ports (single link) HDMI output resolution 480i~1080p, 1080p24, VGA~UXGA Power Supply 5VDC/3.2A (US/EU standards, CE/FCC/UL certified) Dimensions (mm) 93 (W) x 220 (D) x 31 (H) Weight (g) Chassis Material Aluminum... - Page 13 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20090211 MPM-CLUX18W...
