- Page 1 CLUX-14E 1x4 HDMI 1.3 Splitter Operation Manual CLUX-14E...
- Page 2 Table Of Contents 1. Introduction................2. Features..................3. Operation Controls and Functions.......... 3.1 Front Panel................3.2 Rear Panel................4. Connection and Installation............. 5. Specifications................6. Cypress HDMI v1.3 Series............
- Page 3 1. Introduction The HDMI v1.3 Distribution Amplifier Series is the most advanced solution to HDMI signal distribution. Each product in this series is compatible with HDMI v1.3 specifications, a cutting-edge technology which defines the supports to transfer Deep Color (10-bit and 12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high bandwidth up to 225MHz (6.75Gbps).
-
Page 4: Operation Controls And Functions
ENHANCE HDMI 1 HDMI 2 HDMI 3 HDMI 4 CLUX-14E POWER 1x4 HDMI v1.3 Distribution Amp Power Switch: Press the switch to power on the unit. Power LED Indicator: The LED will illuminate when the power is connected. Sync LED: The LED will illuminate when the HDMI source signal is connected to the input port. - Page 5 3.2 Rear Panel DC 5V HDMI OUT HDMI OUT HDMI OUT HDMI IN HDMI Input: Connect input port to the HDMI or DVI output port of your source equipment such as DVD player or set-top-box. HDMI output 1/2/3/4: Connect each of the output ports to the HDMI display.
-
Page 6: Connection And Installation
4. Connection and Installation LCD TV LCD TV LCD TV LCD TV 5. Specifications Frequency Bandwidth 2.25Gbps (single link) Input Port 1x HDMI female port (Type A connector) Output Ports 4x HDMI female ports (signal link) Power Supply 5VDC/2.6A (US/EU standards, CE/FCC/UL certified) Dimensions (mm) 200(W) x 104(D) x 25(H) Weight(g) - Page 8 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20080204 MPM-CLUX14E...
