- Page 1 CLUX-18EU 1 by 8 HDMI v1.3 Splitter Operation Manual Draft Manual CLUX-18EU...
- Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 3 Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 4: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Applications ................. 1 3. Package Contents ..............1 4. System Requirements ..............1 5. Features ..................1 6. Specifications ................2 7. Operation Controls and Functions ..........3 Front Panel ..............3 Rear Panel ..............4 8. Connection and Installation . -
Page 5: Introduction
1. Introduction With eight HDMI outputs and capable of distributing 3D content the HDMI v1.3 1 by 8 splitter is a forward looking device that helps you handle futuristic technology today. Compatible with HDMI v1.3 which defines the ability to transfer 3D content, Deep Color (10-bit and 12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, this device doesn’t merely handle splitting and distributing, far from it,... -
Page 6: Specifications
6. Specifications TMSD Clock Frequency 225MHz Input Port 1 x HDMI Output port 8 x HDMI ESD Protection Human Body model: ± 8kV (air-gap discharge) ± 4kV (contact discharge) Dimensions (mm) 240(W) x 103(D) x 25(H) Weight(g) Chassis Material Metal Silkscreen Color Black Operating Temperature... -
Page 7: Operation Controls And Functions
7. Operation Controls and Functions The following sections describe the hardware components of the unit. 7.1 Front Panel . HDMI OUT 1/2/3/4: Using HDMI cables connect these slots to displays in order to show HDMI content. Note: A.This system was tested with 24AWG cables if using cables of another type, the performance of this system may be different. -
Page 8: Rear Panel
7.2 Rear Panel . USB: For software update only. . HDMI OUT 5/6/7/8: Using HDMI cables connect these slots to displays in order to show HDMI content. . SYS Reset ON/OFF: This switch allows the user to perform a system reset. The default setting is OFF, leave as is when in normal use. By switching ON, the unit will perform a reset every 8~10 minutes, in order to perform this function the displays must have CEC support. -
Page 9: Connection And Installation
8. Connection and Installation BluRay Monitor Monitor BluRay Monitor Monitor Monitor Monitor Monitor Monitor... - Page 10 Acronyms Acronym Complete Term CAT5/6 Category 5 / 6 Cable Electrostatic Discharge Light-emitting Diode RJ45 Registered Jack 45 Universal Serial Bus...
