Summary of Contents for Avalue Technology FPC-08WA1
- Page 1 FPC 08W Series 8” Widescreen Multi-functional Touch Panel PC Quick Reference Guide Ed – 28 June, 2010 Copyright Notice Copyright © 2007-2009 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E201708WAA1R...
-
Page 2: Table Of Contents
System Overview ....................8 1.4.1 Rear View ............................ 8 1.4.2 Right View ........................... 8 System Dimensions..................... 9 1.5.1 FPC-08WA1/04 Series ........................ 9 1.5.2 FPC-08W05 Series........................10 Hardware Configuration..................11 Jumper and Connector Setting, Driver and BIOS Installing........ 11 Installing Memory ....................12 2.2.1 Install Memory for FPC-08W04 .................... -
Page 3: Getting Started
Quick Reference Guide 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. -
Page 4: System Specifications
FPC-08W Series 1.3 System Specifications Panel Specifications FPC-08WA1 FPC-08W04 8.9" LCD size Display type WSVGA TFT Resolution 1024x600 Color 262K Pixel pitch 0.1905mm(H) x 0.189mm(V) Luminance 250 cd/m² Contrast ratio Viewing angle 15(U), 35(D), 45(L), 45(R) Response time 30 ms... - Page 5 Wall/Stand/VESA 75 mm X 75 mm Dimensions 225 mm X 139 mm X 38.9 mm Weight 1.26 Kgs Note: 1. FPC-08WA1 supports +10V~28V wide range power input. 2. Either RS-232 or RS-422/485 for COM2 only. FPC-08W Series Quick Reference Guide...
- Page 6 FPC-08W Series Panel Specifications FPC-08W05 LCD size 8.9" Display type WSVGA TFT Resolution 1024x600 Color 262K Pixel pitch 0.1905mm(H) x 0.189mm(V) Luminance 250 cd/m² Contrast ratio Viewing angle 15(U), 35(D), 45(L), 45(R) 30 ms Response time Backlight Touch Type 5-wire Resistive Touch Light Transmission Touch Interface System...
- Page 7 Quick Reference Guide Rear Panel I/O Serial Port 1 x RS-232, 1 x RS-232 or optional RS-422/485 Ethernet Intel 82574L GigaLAN 1 x DB-15 Audio port 1 x Line out, 1 x Mic in 4 x USB 2.0 Mouse & KB Mechanical &...
-
Page 8: System Overview
LINE OUT Mic-in audio jack Mic In Power switch Power Power LED Reset Reset button USB 2.0 connector CRT connector DB-15 female connector Note: The optional WiFi will occupy one USB port for FPC-08WA1. 8 FPC-08W Series Quick Reference Guide... -
Page 9: System Dimensions
Quick Reference Guide 1.5 System Dimensions 1.5.1 FPC-08WA1/04 Series 38.9 (Unit: mm) FPC-08W Series Quick Reference Guide... -
Page 10: Fpc-08W05 Series
FPC-08W Series 1.5.2 FPC-08W05 Series 10 FPC-08W Series Quick Reference Guide... -
Page 11: Hardware Configuration
Quick Reference Guide 2. Hardware Configuration 2.1 Jumper and Connector Setting, Driver and BIOS Installing Please refer to ECM-LX800D, ECM-945GSE Quick Installation Guide or User’s Manual for further information. Note: If you need more information, please visit our website: http://www.avalue.com.tw FPC-08W Series Quick Reference Guide 11... -
Page 12: Installing Memory
FPC-08W Series 2.2 Installing Memory 2.2.1 Install Memory for FPC-08W04 12 FPC-08W Series Quick Reference Guide... - Page 13 Quick Reference Guide Step 1. Unfasten 6 screws as to remove the bottom chassis. Step 2. Unlock 4 coppers as from the rear I/O of VGA & COM ports. FPC-08W Series Quick Reference Guide 13...
- Page 14 RAM module into the memory slot. Step 4. Assemble the board and bottom chassis back as step 3 to step 1. Note: Memory installation is not for FPC-08WA1 due to 512MB memory onboard.. 14 FPC-08W Series Quick Reference Guide...
-
Page 15: Installing Cf Card
Quick Reference Guide 2.3 Installing CF Card Step 1. Unlock 2 screws from the rear side of the panel PC as above. Step 2. Put the CF card into the socket and fasten 2 screws back. FPC-08W Series Quick Reference Guide 15... - Page 16 FPC-08W Series 16 FPC-08W Series Quick Reference Guide...
