- Page 1 EBM-PNV Intel® Atom™ Dual-Core 5.25” Mini Module with Intel® ICH8-M Chipset User’s Manual Ed – 22 August 2011 Part No. E2047581401R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
-
Page 3: Technical Support
Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification. - Page 4 Avalue Technology Inc. Room 805, Building 9,No.99 Tianzhou Rd., 2F keduka-Bldg, 2-27-3 Taito, Caohejing Development Area, Taito-Ku, Tokyo 110-0016 Japan Xuhui District, Shanghai Tel: +81-3-5807-2321 Tel: +86-21-5169-3609 Fax:+86-21-5445-3266 Fax: +81-3-5807-2322 Information: sales.china@avalue.com.cn Information: sales.japan@avalue.com.tw Service: service@avalue.com.tw Service: service@avalue.com.tw 4 EBM-PNV User‟s Manual...
-
Page 5: Product Warranty
(such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. EBM-PNV User‟s Manual 5... -
Page 6: Table Of Contents
Serial port 3/ 4/ 5/ 6 connector (JCOM3/ JCOM4/ JCOM5/ JCOM6) ........34 2.4.19 General purpose I/O connector (JDIO) ..................34 2.4.20 LED indicator connector (JLED) ....................35 2.4.21 LVDS connector (JLVDS1) ......................36 Signal Description – LVDS Connecter (JLVDS) ................. 36 2.4.21.1 6 EBM-PNV User‟s Manual... - Page 7 Change Supervisor/ User Password ..................61 3.6.5.2 Clear User Password ......................... 62 3.6.5.3 Boot Sector Virus Protection ...................... 62 3.6.6 Advanced Chipset Settings ......................63 3.6.6.1 North Bridge Configuration ......................64 3.6.6.1.1 Video Function Configuration ....................65 EBM-PNV User‟s Manual 7...
- Page 8 Install Chipset Driver (For Intel ICH8-M) ..............72 Install Display Driver (For Intel Pineview) ..............73 Install Audio Driver (For Realtek ALC888) .............. 74 Install Ethernet Driver (For Intel 82574L) ..............75 5. Mechanical Drawing ....................77 8 EBM-PNV User‟s Manual...
-
Page 9: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EBM-PNV with Intel® Atom™ Dual Core & DDR3 SDRAM Mini Module 1 x DVD-ROM or CD-ROM contains the followings: ... -
Page 10: Document Amendment History
EBM-PNV User’s Manual 1.3 Document Amendment History Revision Date Comment August 2011 Initial Release 10 EBM-PNV User‟s Manual... -
Page 11: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to interface with EBM-PNV series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 12: System Specifications
1 x 18-bit, 2 x 18/24-bit LVDS VR, PWM (Setting by BIOS) Backlight Control Touch Screen Interface (Optional) Chipset ETP-CP-S458XRU With 5-pin 2.54mm Pin Header (Can be Selected to Support 4/5-wire Touch Screen Interface Touch Screen) 12 EBM-PNV User‟s Manual... - Page 13 +12V ~ +28V Power Input AT/Adapter Operation Temperature 0 ~ 60°C (32 ~ 140°F) Operating Humidity 0% ~ 90% Relative Humidity, Non-condensing 8” x 5.75” x 0.75” (203mm x 146mm x 19mm) Size ( L x W ) Weight 0.55lb (0.25kg) EBM-PNV User‟s Manual 13...
-
Page 14: Architecture Overview - Block Diagram
EBM-PNV User’s Manual 1.6 Architecture Overview – Block Diagram The following block diagram shows the architecture and main components of EBM-PNV. 14 EBM-PNV User‟s Manual... -
Page 15: Hardware Configuration
User’s Manual 2. Hardware Configuration EBM-PNV User‟s Manual 15... -
Page 16: Product Overview
EBM-PNV User’s Manual 2.1 Product Overview 16 EBM-PNV User‟s Manual... -
Page 17: Installation Procedure
Note: Make sure the heat sink and the CPU top surface are in total contact to avoid CPU overheating problem that would cause the system to hang or show instability. EBM-PNV User‟s Manual 17... -
Page 18: Main Memory
EBM-PNV User’s Manual 2.2.1 Main Memory EBM-PNV provides Onboard 1GB DDR3 SDRAM and One 204-pin SODIMM Supporting Up to 3GB DDR3 SODIMM Make sure to unplug the power supply before adding or removing SODIMMs or other system components. Failure to do so may cause severe damage to both the board and the components. - Page 19 (2) Static electricity can damage the electronic components of the computer or optional boards. Before proceeding, ensure that you are discharged of static electricity by briefly touching a grounded metal object. EBM-PNV User‟s Manual 19...
-
Page 20: Jumper And Connector List
LCD backlight brightness adjustment 3 x 2 header, pitch 2.0mm JVR2 LCD backlight brightness adjustment 3 x 2 header, pitch 2.0mm Multi-function select DIP switch 6pin Serial port 1/ 2 – RS232/ 422/ 485 mode DIP switch 6pin select 20 EBM-PNV User‟s Manual... - Page 21 2 x 2 wafer, pitch 2.0mm Reset button RSBTN S_PWR1 Serial ATA power connector 2 x 1 wafer, pitch 2.0mm Serial ATA connector 1 SATA1 SATA2 Serial ATA connector 2 USB1 USB connector 0&1 VGA connector D-sub 15-pin, female EBM-PNV User‟s Manual 21...
-
Page 22: Setting Jumpers & Connectors
2.4 Setting Jumpers & Connectors 2.4.1 Clear CMOS (JBAT) Protect* Clear CMOS * Default 2.4.2 Multi-function select (SW1) AT SEL ATX SEL CF Master CF Slave Touch off Touch on Touch: 4W Touch: 5W GPIO32:L GPIO32:H GPIO33:L GPIO33:H 22 EBM-PNV User‟s Manual... -
Page 23: Serial Port 1/ 2 - Rs-232/ 422/ 485 Mode Select (Sw2)
Serial port 1/ 2 - RS-232/ 422/ 485 mode select (SW2) In Serial Port 1 mode RS-232 RS-422 RS-485 In Serial Port 2 mode RS-232 RS-422 RS-485 2.4.4 Serial port 1/ 2 pin9 signal select (JRI1/ JRI2) Ring* JRI2 +12V JRI1 * Default EBM-PNV User‟s Manual 23... -
Page 24: Serial Port 1/ 2 Rs-232/ 422/ 485 Mode Select (Jp1/ Jp2)
EBM-PNV User’s Manual 2.4.5 Serial port 1/ 2 RS-232/ 422/ 485 mode select (JP1/ JP2) RS-232* RS-422/ 485 * Default 2.4.6 SATA DOM Pin 7 Power mode selector (JP4) Clear* Power Signal SATA_PWR GND#7_1 * Default 24 EBM-PNV User‟s Manual... -
Page 25: Battery Connector (Bat)
User’s Manual 2.4.7 Battery connector (BAT) Signal EBM-PNV User‟s Manual 25... -
Page 26: Lcd Backlight Brightness Adjustment (Jvr1)
Variation Resistor (Recommended: 4.7KΩ, >1/16W) Note: For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal controlled by JBKL1. Please see the JBKL1 section for detailed circuitry information. 26 EBM-PNV User‟s Manual... -
Page 27: Lcd Backlight Brightness Adjustment (Jvr2)
Variation Resistor (Recommended: 4.7KΩ, >1/16W) Note: For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal controlled by JBKL2. Please see the JBKL2 section for detailed circuitry information. EBM-PNV User‟s Manual 27... -
Page 28: Power Connector (Pwr2)
EBM-PNV User’s Manual 2.4.10 Power connector (PWR2) Signal Signal 2.4.11 Serial ATA power connector (S_PWR1) Signal SATA_PWR 28 EBM-PNV User‟s Manual... -
Page 29: Lcd Inverter Connector (Jbkl1/ Jbkl2)
VR signal controlled by JVR1/ JVR2. Please see the JVR1/ JVR2 section for detailed circuitry information. 2.4.12.1 Signal Description – LCD Inverter Connector (JBKL1/ JBKL2) Signal Signal Description BRIGHT Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W) BKL_ON LCD backlight ON/OFF control signal EBM-PNV User‟s Manual 29... -
Page 30: Optional Lpt Connector (Print)
EBM-PNV User’s Manual 2.4.13 Optional LPT connector (PRINT) PRINT (Rear side) Signal SLIN# PAR_INIT# ERR# AFD# SLCT BUSY ACK# PTD7 PTD6 PTD5 PTD4 PTD3 PTD2 PTD1 PTD0 STB- 30 EBM-PNV User‟s Manual... -
Page 31: Serial Port 1 Connector (Com1)
Serial port 1 connector (COM1) In RS-232 Mode Signal PIN PIN Signal DCD1 RxD1 TxD1 DTR1 DSR1 RTS1 CTS1 In RS-422 Mode Signal PIN PIN Signal TxD1- RxD1+ TxD1+ RxD1- In RS-485 Mode Signal PIN PIN Signal DATA1- DATA1+ EBM-PNV User‟s Manual 31... -
Page 32: Cpu Fan Connector (Cpu_Fan)
EBM-PNV User’s Manual 2.4.15 CPU fan connector (CPU_FAN) Signal FAN_TAC1 +12V 2.4.16 Audio connector (JAUDIO) Signal PIN PIN Signal APM_LOUT_R APM_LOUT_L LINEIN_R LINEIN_L MIC-R MIC-L FRONT-JD LINE1-JD MIC1-JD 32 EBM-PNV User‟s Manual... -
Page 33: Serial Port 2 Connector (Jcom2)
Serial port 2 connector (JCOM2) In RS-232 Mode Signal PIN PIN Signal DCD2 RxD2 TxD2 DTR2 DSR2 RTS2 CTS2 In RS-422 Mode Signal PIN PIN Signal TxD2- RxD2+ TxD2+ RxD2- In RS-485 Mode Signal PIN PIN Signal DATA2- DATA2+ EBM-PNV User‟s Manual 33... -
Page 34: Serial Port 3/ 4/ 5/ 6 Connector (Jcom3/ Jcom4/ Jcom5/ Jcom6)
JCOM4 JCOM5 JCOM3 JCOM6 Signal PIN PIN Signal 2.4.19 General purpose I/O connector (JDIO) Signal PIN PIN Signal DIO0 DIO10 DIO1 DIO11 DIO2 DIO12 DIO3 DIO13 DIO4 DIO14 DIO5 DIO15 DIO6 DIO16 DIO7 DIO17 SMB_CLK_S SMB_DATA_S 34 EBM-PNV User‟s Manual... -
Page 35: Led Indicator Connector (Jled)
User’s Manual 2.4.20 LED indicator connector (JLED) Signal PIN PIN Signal +3.3V HD_ACT# +3.3V LAN1_ACT 3.3V_SB LAN2_ACT 3.3V_SB ROUT- ROUT+ LOUT- LOUT+ PWRBTN# EBM-PNV User‟s Manual 35... -
Page 36: Lvds Connector (Jlvds1)
C interface for panel parameter EEPROM. This EERPOM is mounted on the C_DAT, I C_CLK LVDS receiver. The data in the EEPROM allows the EXT module to automatically set the proper timing parameters for a specific LCD panel. 36 EBM-PNV User‟s Manual... -
Page 37: Ebm-Pnv User"S Manual
If we boot from CRT & LCD, the resolution is fixed by CRT's resolution. If we boot from LCD only and plug the CRT in the OS, LCD works well but the CRT will have wrong resolution. CRT's resolution > LCD's resolution. Everything is fine. EBM-PNV User‟s Manual 37... -
Page 38: Touch Panel Connector (Jtouch)
EBM-PNV User’s Manual 2.4.23 Touch panel connector (JTOUCH) Signal PROBE NOTE: Under 4W situation UL=X+, UR=Y+, LR=Y-, LL=X- 2.4.24 USB connector 4&5, 2&3, 6&7 (JUSB1/ JUSB2) JUSB2 JUSB1 Signal Signal 38 EBM-PNV User‟s Manual... -
Page 39: Usb Connector 9 (Jusb4)
User’s Manual 2.4.25 USB connector 9 (JUSB4) Signal +3.3V 2.4.26 OSD for front panel key (JKEY) Signal K-LED_GREEN K-LED_RED K-POWER K-AUTO K-MENU K-RIGHT K-LEFT EBM-PNV User‟s Manual 39... -
Page 40: Bios Setup
EBM-PNV User’s Manual 3. BIOS Setup 40 EBM-PNV User‟s Manual... -
Page 41: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP EBM-PNV User‟s Manual 41... -
Page 42: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. 42 EBM-PNV User‟s Manual... -
Page 43: Getting Help
Award and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. EBM-PNV User‟s Manual 43... -
Page 44: Bios Setup
Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 44 EBM-PNV User‟s Manual... -
Page 45: Advanced Menu
User’s Manual 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. EBM-PNV User‟s Manual 45... -
Page 46: Cpu Configuration
No-Execution page protection technology. Hyper Threading Disabled, This item allows you to enable or disable Technology Enabled Intel® Hyper Threading technology. Disabled, This item allows you to enable or disable Intel® SpeedStep™ tech Intel® SpeedStep™ tech. Enabled 46 EBM-PNV User‟s Manual... -
Page 47: Ide Configuration
Enabled BIOS. 0/ 5/ 10/ 15/ 20/ 25/ 30/ This allows you to select the time out value for IDE Detect Time Out (Sec) detecting ATA/ ATAPI devices. EBM-PNV User‟s Manual 47... -
Page 48: Ahci Configuration
IDE devices. Item Options Description Auto, SATA Port 0/ 1/ 2 Serial port 0/ 1/ 2 mode select. Not Installed Disabled, Select the smart monitoring, analysis, and S.M.A.R.T. Enabled reporting technology. 48 EBM-PNV User‟s Manual... -
Page 49: Super I/O Configuration
EPP, The Parallel Port Mode selection selects the Parallel Port Mode ECP, mode the parallel port operations in. EPP+ECP IRQ5, The Parallel Port Address BIOS option Parallel Port IRQ IRQ7 assigns the parallel port interrupt address. EBM-PNV User‟s Manual 49... -
Page 50: Hardware Health Configuration
EBM-PNV User’s Manual 3.6.2.4 Hardware Health Configuration This section allows you to control H/W monitoring. 3.6.2.5 ACPI Settings You can use this item to set up ACPI Configuration. Please refer to 3.5.2.5.1 ~ 3.5.2.5.3 for more details. 50 EBM-PNV User‟s Manual... -
Page 51: General Acpi Configuration
POST on S3/ STR resume. Disabled, All PME/ wakeup event will be disabled in S4/ Deep S5 Enabled S5 mode when enabled DEEP S5. Note: Deep S5=ErP ErP mode: 1. No Timer-Power-On 2. No Wake On Ring/ LAN EBM-PNV User‟s Manual 51... -
Page 52: Advanced Acpi Configuration
Include APIC table pointer to RSDT pointer ACPI APIC support Disabled list. Enabled, Include OEMB table pointer to R(x)SDT AMI OEMB table Disabled pointer list. Disabled, Enable/ Disable Headless operation mode Headless mode Enabled through ACPI. 52 EBM-PNV User‟s Manual... -
Page 53: Chipset Acpi Configuration
APIC ACPI SCI IRQ Enabled SCI IRQ. Disabled, This item allows selecting USB device wakeup USB Device Wakeup From S3/ S4 Enabled mode. Disabled, This section helps to set high performance High Performance Event Timer Enabled event timer. EBM-PNV User‟s Manual 53... -
Page 54: Usb Configuration
EHCI driver. A dummy FDD devices is created that will be Enabled, associated with the hotplugged FDD later. Hotplug USB FDD Support Disabled, Auto option creates this dummy device only if Auto there is no USB present. 54 EBM-PNV User‟s Manual... -
Page 55: Apm Configuration
That is, the system is roused by an incoming call on modem. Use the Resume on RTC Alarm option to Disabled, Resume On RTC Alarm specify the time the system should be roused Enabled from a suspend state. EBM-PNV User‟s Manual 55... -
Page 56: Advanced Pci/ Pnp Settings
IRQ. When set to No will Allocate IRQ to PCI VGA not assign IRQ to PCI VGA card even if card requests an IRQ. Disabled, This item designed to solve problems caused PaletteSnooping Enabled by some non-standard VGA card. 56 EBM-PNV User‟s Manual... -
Page 57: Boot Settings
Use the IRQ# address to specify what IRQs Available, IRQ3/ 4/ 5/ 7/ 9/ 10/ 11 can be assigned to a particular peripheral Reserved device. 3.6.4 Boot Settings Use the Boot menu to configure system boot options. EBM-PNV User‟s Manual 57... -
Page 58: Boot Settings Configuration
F1 key to be pressed when error occurs. This Enabled allows option ROM to trap interrupt19. This displays „Press <DEL> to run Setup> in Disabled, Hit ‘DEL’ Message Display Enabled POST. Disabled, Interrupt 19 Capture This allows option ROMs to trap interrupt19. Enabled 58 EBM-PNV User‟s Manual... -
Page 59: Boot Device Priority
3.6.4.2 Boot Device Priority Use the Boot Device Priority menu to specify the boot sequence from the available devices. 3.6.4.3 Hard Disk Devices Use the Hard Disk Drives menu to specify the boot sequence of the available HDDs. EBM-PNV User‟s Manual 59... -
Page 60: Removable Devices
EBM-PNV User’s Manual 3.6.4.4 Removable Devices Use the Removable Drives menu to specify the boot sequence of the available FDDs. 3.6.5 Security Settings Use the Security menu to set system and user password. 60 EBM-PNV User‟s Manual... -
Page 61: Change Supervisor/ User Password
User’s Manual 3.6.5.1 Change Supervisor/ User Password To either install or change the password. EBM-PNV User‟s Manual 61... -
Page 62: Clear User Password
3.6.5.2 Clear User Password Use the Clear User Password to clean a user password. 3.6.5.3 Boot Sector Virus Protection The boot sector virus protection will warn if any program tries to write to the boot sector. 62 EBM-PNV User‟s Manual... -
Page 63: Advanced Chipset Settings
User’s Manual 3.6.6 Advanced Chipset Settings Use the chipset menu to access the Northbridge and Southbridge configuration menus. EBM-PNV User‟s Manual 63... -
Page 64: North Bridge Configuration
Internal Graphics Mode Select Enabled 64MB, can be used by the internal Enabled 128MB graphics device. Use the PEG Port option to Disabled, PEG Port Configuration enable or disable the PCI Express Enabled port. 64 EBM-PNV User‟s Manual... -
Page 65: Video Function Configuration
Combo Mode 64MB, Specifies the amount of DVMT/ DVMT/ FIXED Memory 128MB, FIXED system memory to allocate Maximum DVMT for video memory. VBIOS-Default, CRT, Select boot display device at post Boot Display Device LVDS, stage. CRT+LVDS EBM-PNV User‟s Manual 65... -
Page 66: Ebm-Pnv User"S Manual
This item allows you to select Panel 1/ 2 Back light mode/ DC mode Panel 1/ 2 backlight mode/ Control control. Disabled, This item allows you to enable or Spread Spectrum Clock Enabled disable spread spectrum clock. 66 EBM-PNV User‟s Manual... -
Page 67: South Bridge Configuration
PCIe Wake Enabled wake mode. Disabled, This section allows selecting LAN LAN Boot rom Enabled boot rom mode. Disabled, This section allows selecting PCIE Port 0/ 1/ 2 Enabled, PCIE port 0/ 1/ 2 mode. Auto EBM-PNV User‟s Manual 67... -
Page 68: Exit Options
Use the Exit menu to load default BIOS values, optional failsafe values and to save configuration changes. 3.6.7.1 Save Changes and Exit Use the save changes and reset option to save the changes made to the BIOS options and to exit the BIOS configuration setup program. 68 EBM-PNV User‟s Manual... -
Page 69: Discard Changes And Exit
Use the Discard changes and Exit option to exit the system without saving the changes made to the BIOS configuration setup program. 3.6.7.3 Discard Changes Use the Discard Changes option to discard the changes and remain in the BIOS configuration setup program. EBM-PNV User‟s Manual 69... -
Page 70: Load Optimal Defaults
F9 key can be used for this operation. 3.6.7.5 Load Failsafe Defaults Use the Load Failsafe Defaults option to load failsafe default values for each of the parameters on the Setup menus. F8 key can be used for this operation. 70 EBM-PNV User‟s Manual... -
Page 71: Drivers Installation
User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. EBM-PNV User‟s Manual 71... -
Page 72: Install Chipset Driver (For Intel Ich8-M)
If the warning message appears while the installation Step 3. Click Yes. process, click Continue to go on. Step1. Locate 「\Driver_Chipset\Intel\ OM57\ \infinst_autol.exe」. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. 72 EBM-PNV User‟s Manual... -
Page 73: Install Display Driver (For Intel Pineview)
Note: The installation procedures and screen shots in this section are based on Windows XP operation system. Step 3. Click Yes. Step 1. Locate「Driver_Video\Intel\ Pineview\Setup.exe」. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. EBM-PNV User‟s Manual 73... -
Page 74: Install Audio Driver (For Realtek Alc888)
Windows 2000 operation Step 3. The program executes the Setup system. automatically. Step 1. Locate 「\Driver_Audio\Intel\ Step 4. Click Finish to complete the setup. 6300ESB ALC888\setup.exe」. Step 2. Select Next to the next step. 74 EBM-PNV User‟s Manual... -
Page 75: Install Ethernet Driver (For Intel 82574L)
Windows XP operation system. Step 3. Click Next to run the installation. Step 1. Locate 「\Driver_Gigabit\Intel\ Step 4. Click Accept to continue. 82574L」and choose your system OS. Step 2. Click Next. Step 5. Click Next. EBM-PNV User‟s Manual 75... - Page 76 EBM-PNV User’s Manual Step 5. Click Install to next step. Step 6. Click Next to next step. Step 7. Click Finish to complete the setup. 76 EBM-PNV User‟s Manual...
-
Page 77: Mechanical Drawing
User’s Manual 5. Mechanical Drawing EBM-PNV User‟s Manual 77... - Page 78 EBM-PNV User’s Manual Unit: mm 78 EBM-PNV User‟s Manual...
- Page 79 User’s Manual Unit: mm EBM-PNV User‟s Manual 79...
