Mute Operation

LCD Setting

After pressing and holding ENTER button for 3 seconds, the unit will enter setting mode. Press "UP" or "DOWN"
button to select setting programs. And then, press "ENTER" button to confirm the selection or ESC button to
exit.
Setting Programs:
Program
00 Exit setting mode
Power saving mode
04
enable/disable
Auto restart when overload
06
occurs
Auto restart when over
07
temperature occurs
09 Output frequency
18 Alarm control
Auto return to default
19
display screen
Indicates the DC/AC inverter circuit is working.
Indicates unit alarm is disabled.
Description Selectable option
Escape
Saving mode disable
(default)
Saving mode enable
Restart disable
(default)
Restart disable
(default)
50Hz (default)
Alarm on (default)
Return to default
display screen
(default)
Stay at latest screen
If disabled, no matter connected load
is low or high, the on/off status of
inverter output will not be effected.
If enabled, the output of inverter will
be off when connected load is pretty
low or not detected.
Restart enable
Restart enable
60Hz
Alarm off
If selected, no matter how users
switch display screen, it will
automatically return to default display
screen (Input voltage /output voltage)
after no button is pressed for 1
minute.
If selected, the display screen will stay
at latest screen user finally switches.
8
