Summary of Contents for Martin JEM K1 Hazer
- Page 1 P/N 35010031-G K1 HAZER user manual...
-
Page 2: Table Of Contents
Safety information........................3 Product overview ........................6 Product description........................ 6 Features at a glance ......................6 Product details ........................7 Quick Start ..........................8 Setting up..........................8 Making haze........................... 8 Shutting down........................8 Installation and setting up ......................9 Location ..........................9 AC power .......................... -
Page 3: Safety Information
• Before connecting the JEM K1 Hazer to power, check that the voltage indicated on the machine’s serial label matches your local AC power voltage. If your AC power voltage does not match, do not use the machine. - Page 4 Do not spill fluid over or inside the machine. If fluid is spilled, disconnect AC power and clean with a damp cloth. If fluid is spilled onto electronic parts, take the system out of service and contact Martin for advice. •...
- Page 5 Avoid installing over people’s heads - Evitez d' installer au dessus des • personnes. • Use only Martin K1 Haze fluid - Utilisez que du fluide Martin K1. • Prolonged use may cause condensation to form; check floors and surfaces regularly - Une utilisation prolongée peut causer la formation de condensation;...
-
Page 6: Product Overview
P r o d u c t d e s c r i p t i o n The JEM K1 Hazer™ from Martin is a top of the range solution to a wide variety of atmospheric requirements whether permanently installed or taken on the road. -
Page 7: Product Details
P r o d u c t d e t a i l s Digital control Fast access panel buttons 3 pin DMX input and link Remote control socket 5 pin DMX input and link Main power switch Power inlet connector External fuse Flying kit eyelet... -
Page 8: Quick Start
Locate the machine in a suitably large area with nothing in front of the haze output. Fill the fluid tank with MARTIN-approved haze fluid (see page 17). Connect a suitably rated power supply to the machine. The power requirements are: 6.3A at 230V (EU) or 10A at 120V (US) -
Page 9: Installation And Setting Up
“Safety information” on page 3. L o c a t i o n The JEM K1 Hazer™ should be located on a solid surface such as the floor. The machine can operate in any orientation from 45 degrees upwards to 45 degrees downwards. -
Page 10: Setting Up
• for safe operation listed on page 3 • the haze fluid is genuine Martin fluid listed under “Haze fluid options” on page 17 • the machine is electrically grounded (earthed) •... -
Page 11: Control Settings
Control settings O v e r v i e w By selecting either ECO / PRE1/ PRE2 from the Fast Access buttons below the digital display at the rear of the unit allow you to quickly turn the haze on or off at three different settings. -
Page 12: Setting Fan Speed
S e t t i n g F a n s p e e d Use the Previous / Next buttons to select the option. Use the Up/Down buttons to select the fan speed from – . Press the Enter button to store the fan setting. The fan will run continuously if set above 0% and the ... -
Page 13: Setting The Dmx Base Address
S e t t i n g t h e D M X b a s e a d d r e s s Use the Previous / Next buttons to select the option. Use the Up/Down buttons to set the DMX base address from to . If you hold down the button the address will count up or down, getting faster the longer you hold it. -
Page 14: Resetting Options To Factory Settings
R e s e t t i n g o p t i o n s t o f a c t o r y s e t t i n g s The factory settings configure a standard mode of operation for the machine. Use the Previous / Next buttons to select the ... -
Page 15: Remote Control
O v e r v i e w The JEM K1™ Digital Remote control, available separately, may be used for remote control of the JEM K1 Hazer™. Several machines may be controlled from one remote using the LINK function (see page 13). -
Page 16: Dmx Control
245-255 Machine shutdown, heaters off For example if the JEM K1 Hazer™ is set to DMX address 100, channel 1 will be controlled by address 100 and channel 2 will be controlled by address 101. When the machine is at running temperature and is under DMX control it displays . -
Page 17: Fog Fluid Type
Use only the following genuine Martin fog fluid. No other fluid is suitable for use. DANGER! The JEM K1 Hazer™ can run safely only on the specific haze fluid it is designed for. Use ONLY the Martin haze fluid designated in this manual. NEVER use any other type of fluid, or toxic gas may be produced. -
Page 18: Basic Service
F u s e r e p l a c e m e n t The main fuse for the JEM K1 Hazer™ is in a fuse holder located adjacent to the power inlet. To replace the fuse, disconnect the power cord from the supply, unscrew the cap of the fuse holder and pull out the fuse. -
Page 19: Troubleshooting
Troubleshooting Problem Probable cause(s) Suggested remedy Machine not at operating Wait 5 to 7 minutes temperature Machine will not produce set to 0 Increase setting haze when control panel or remote control HAZE switch set to 0 Increase setting turned on... -
Page 20: Status Messages
shutdown sequence. The machine has detected an error with its calibration settings and will not operate. Call Martin Service. The air pump is not working. This indicates a fault. Turn the machine off and call Martin Service. -
Page 21: Specifications
Specifications P h ys i c a l Length ......................544mm Width ......................459mm Height......................344mm Dry weight ....................21.5Kg P e r f o r m a n c e Effect coverage ..................5000m /min Operating time ..................continuous Warm up time ..................5 minutes Safety device..................DTP device C o n t r o l a n d p r o g r a m m i n g Control options .............. - Page 22 O r d e r i n g i n f o r m a t i o n Martin JEM K1 Hazer™ 120V ..............92225900 Martin JEM K1 Hazer™ 230V ..............92225901 JEM K1™ digital remote control..............92765036 Flying Kit for Martin JEM K1 Hazer™ ............92610002 Flightcase for Martin JEM K1 Hazer™............91540012 Specifications...
-
Page 23: Notes
Notes Notes... - Page 24 Martin Professional A/S,Olof Palmes Allé 18, DK-8200,Aarhus N Phone: +45 87 40 00 00 Internet: www.martin.com...
