Antenna and Activation Information

Antenna

The antenna intended for use with this unit meets the requirements for mobile operating configurations and for
fixed mounted operations, as defined in 2.1091 and 1.1307 of the FCC rules for satisfying RF exposure compliance.
If an alternate antenna is used, consult user documentation for required antenna specifications.

EV-DO and CDMA Antenna Information

EV-DO and CDMA Authorized Antennas

These devices were approved with the following antenna:
Manufacturer:
Manufacturer's Model Number:
Multi-Tech ordering information:
Model
ANQB-1HRA
ANQB-10HRA
ANQB-50HRA

EV-DO and CDMA Antenna Requirements

Category
Frequency Range
Impedance
VSWR
Typical Radiated Gain
Radiation
Polarization

Antenna System Cellular Devices

The cellular/wireless performance depends on the implementation and antenna design. The integration of the
antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early
so the performance is not compromised. If changes are made to the device's certified antenna system, then
recertification will be required by specific network carriers.

Account Activation for Cellular Devices

Some Multi-Tech cellular modems are pre-configured to operate on a specific cellular network. Before you can use
the modem, you must set up a cellular data account with your service provider. Each service provider has its own
®
MultiConnect Cell 100 Series MTC-EV3 User Guide
Exceltek Electronics Ltd.
C0081-ANG0002
Quantity
1
10
50
Description
824 - 894 MHz / 1850 - 1990 MHz
50 Ohms
VSWR should not exceed 2.0:1 at any point across the bands of operation
2 dBi on azimuth plane
Omni-directional
Linear vertical
ANTENNA AND ACTIVATION INFORMATION
13
