ANTENNA AND ACTIVATION INFORMATION
Chapter 4 – Antenna and Activation Information

Antenna

The antenna intended for use with this unit meets the requirements for mobile operating configurations and for
fixed mounted operations, as defined in 2.1091 and 1.1307 of the FCC rules for satisfying RF exposure compliance.
If an alternate antenna is used, consult user documentation for required antenna specifications.

Antenna System Cellular Devices

The cellular/wireless performance depends on the implementation and antenna design. The integration of the
antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early
so the performance is not compromised. If changes are made to the device's certified antenna system, then
recertification will be required by specific network carriers.

LTE Cat M1/Cat 4 Antenna

Devices were approved with the following antenna or for alternate antennas meeting the given specifications:
Manufacturer:
Description:
Model Number
MultiTech ordering information:
Model
ANLTE4-1HRA
ANLTE4-2HRA
ANLTE4-10HRA
ANLTE4-50HRA

Antenna Specifications

Category
Frequency Range
VSWR
Gain
Impedance
Radiation
Polarization
22
Wieson
LTE Antenna with SMA-Male Connector
GY115IE002-001
Quantity
1
2
10
50
Description
0.698 - 0.96 GHz
1710 - 2170 GHz
2.30 - 2.69 GHz
3:1 maximum
2.06 dBi
50Ω nominal
Omni-directional
Linear, vertical
®
