Design and function

Installation

5.4 Installation
Installation site!
The machine must not be operated in the open air and must only be set up and
operated on a suitable, stable and level base!
•
The operator must ensure that the ground is non-slip and level, and provide sufficient
lighting for the place of work.
•
Safe operation of the machine must be guaranteed at all times.
5.4.1

Protective flap, welding machine control

Item Symbol
1
2
3
•
Push the right-hand bracket of the protective cap to the right and remove the protective cap.
26
Description 0
Protective cap
Lid
Bracket, protective cap
CAUTION
Figure 5-1
099-005319-EW501
22.05.2014
