Machine description – quick overview
Description 0
Transport bar
Carrying handle
Protective cap
Cover for the wire feed mechanism and other operating elements.
Depending on the machine series, additional stickers with information on the
replacement parts and JOB lists will be located on the inside.
Wire spool inspection window
Check wire supply
Slide latch, lock for the protective cap
Machine control
See Machine control – operating elements chapter
Cooling air inlet
Welding torch connection (Euro torch connector)
Welding current, shielding gas and torch trigger integrated
Machine feet
Park socket, polarity selection plug
Retainer for the polarity selection plug in MMA mode or for transport.
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, etc.)
Connection socket, "+" welding current
•
MIG/MAG cored wire welding:
•
TIG welding:
•
MMA welding:
"-" welding current connection socket
•
MIG/MAG welding:
•
TIG welding:
•
MMA welding:
Welding current cable, polarity selection
Welding current to the central connector/torch, enables polarity selection.
• MIG/MAG: Connection socket for "+" welding current
• Self-shielding cored wire/TIG: Connection socket for "-" welding current
Key switch for protection against unauthorised use (ex works option)
Position "1" > changes possible,
Position "0" > changes not possible.
Please take note of chapter "Protecting welding parameters from unauthorised access"
Protective cap (see Sect. "Protective cap")
Workpiece connection
Workpiece connection
Workpiece connection
Workpiece connection
Welding current connection for welding torch
electrode holder connection
