EWM Phoenix 355 Progress puls MM TKM Operating Instructions Manual page 66

Design and function
MIG/MAG welding
Example 1: Welding workpieces with different sheet metal thicknesses (non-latched)
Example 2: Welding different positions on a workpiece (latched)
Example 3: Aluminium welding of different sheet metal thicknesses (non-latched or latched
special)
Up to 16 programs (P
An operating point (wire speed, arc length correction, dynamics/choke effect) can be defined
permanently in each program.
Program P0 is an exception: the settings for operating points are made manually here.
Changes to the welding parameters are saved immediately!
66
Figure 5-36
Figure 5-37
Figure 5-38
NOTE
to P ) can be defined.
A0 A15
099-005319-EW501
22.05.2014
