Relion 2940 Chassis Manual
3-2 Rear View
5
4
3
2
1
1 2
3
4
6
No.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
Hardware Installation
6
7
8
12
9 10 11
9 11 10
7
8
5
Decription
VGA port
Serial port
Power Button/LED
ID button/LED
Reset Button
NMI button
System status LED
LAN2 Active/Link LED (top)/
LAN1 Active/Link LED (buttom)
QSFP LAN port
10/100/1000 Server management LAN port
USB 3.0 ports
Power supply fan
Power supply module cord socket
5
4
3
13
2
1
13
1 2
3
4
6
