Relion 2940 Chassis Manual
2 Replacing Power Supply Board Cage Cover
Before you remove or install the power supply board cage cover
• Make sure the system is not turned on or connected to AC power.
Follow these instructions to remove the power supply board cage cover:
1. Loosen and remove the screw securing the cover.
2. Holding the cage and vertically lift it from the
system.
1
2
- 17 - Hardware Installation
