Relion 2940 Chassis Manual
8
Replacing the Power Supply
CAUTION!
• In order to reduce the risk of injury from electric shock, disconnect AC power from the power
supply before removing it from the system.
Follow these instructions to replace the power supply:
1.
Disconnect the three power cables.
2.
Pull up the power supply handle.
3.
Press the retaining clip on the right side of the power supply along the direction of the arrow.
4.
At the same time, pull out the power supply by using its handle.
5.
Insert the replacement power supply firmly into the chassis. Connect the AC power cord to the
replacement power supply.
Hardware Installation
- 28 -
