Relion 2940 Chassis Manual

5-4-3 BMC network configuration

BMC network configuration
Lan Channel 1
Configuration Address source
Select to configure LAN channel parameters statically or dynamically (DHCP). Do nothing option willnot
modify any BMC network parameters during BIOS phase.
Options available: Unspecified/Static/DynamicBmcDhcp. Default setting is DynamicBmcDhcp.
Station IP Address
Display IP Address information.
Subnet mask
Display Subnet Mask information.
Please note that the IP address must be in three digitals, for example, 192.168.000.001.
Router IP address
Display the Router IP Address information.
Station MAC Address
Display the MAC Address information.
Real-time synchronize BMC network parameter values
Press [Enter] to synchronize BMC network parameter values.
- 105 - BIOS Setup
