5-4-3 BMC network configuration

BMC network configuration
Select NCSI and Dedicated LAN
Switch NCSI and dedicated LAN and send KCS command.
Options available: Mode2(NSCI)/ Mode1 (Dedicated)/Do Nothing. Default setting is Do Nothing.
Lan Channel 1
Configuration Address source
Select to configure LAN channel parameters statically or dynamically (DHCP). Do nothing option willnot
modify any BMC network parameters during BIOS phase.
Options available: Unspecified/Static/DynamicBmcDhcp. Default setting is Unspecified/Static.
Station IP Address
Display IP Address information.
Subnet mask
Display Subnet Mask information.
Please note that the IP address must be in three digitals, for example, 192.168.000.001.
Router IP address
Display the Router IP Address information.
Station MAC Address
Display the MAC Address information.
Real-time synchronize BMC network parameter values
Press [Enter] to synchronize BMC network parameter values.
