KTI Networks KGS-800L Specification Sheet

KGS-800L Ver.D
FCC Part 15 Class B
'
CISPR 22 Class B
Katron Technologies Inc.
15F-7, No. 79, Sec. 1, Hsin Tai Wu Rd.,
Hsi-chih, Taipei Hsien, Taiwan.
Te l :886-2-2698-3878
Fax:886-2-2698-3873
E-mail:kti@ktinet.com.tw
URL:http://www.ktinet.com.tw
KTI Networks Inc.
7400 Harwin Dr., Suite 120 Houston,
Texas 77036 U.S.A.
Te l :713-266-3891
Fax:713-914-0555
E-mail:kti@ktinet.com
URL:http://www.ktinet.com
Trademarks: All brand names are trademarks or registered
trademarks of their respective holders.
This information is subject to change without prior notice.
8-Port 10/100/1000Base-T
Gigabit Ethernet Switch
Key Features :
Provides 8 10/100/1000Mbps Gigabit Ethernet ports

All 10/100/1000M ports support auto-negotiation and auto-MDI/MDI-X detection

Supports full/half-duplex transfer mode for 10/100Mbps

Supports full-duplex transfer mode for 1000Mbps

Wire speed reception and transmission

Store-and-Forward switching method

Self learning for active MAC addresses up to 4K entries

Comprehensive front-panel diagnostic LEDs

Supports IEEE 802.3x flow control for full-duplex mode and backpressure flow control for half-

duplex mode
Specifications:
Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T
Cables 10Base-T:
100Base-TX:
1000Base-T:
Number of Ports 8 x 10/100/1000Mbps auto-MDI/MDI-X ports with RJ-45 connectors
Network Data Ethernet:
Transfer Rate Fast Ethernet:
Gigabit Ethernet:
MAC Address Table 4K entries
LEDs Per Unit: Power
Per Port: Link/ACT, 100M/1000M
Environment Operating temperature:
Storage temperature:
Relative Humidity:
Dimension 155 x 109 x 33 mm ( W x D x H)
Power DC 5V/2A
Power 7.5 watts. (max.)
Consumption
Approval FCC Class B, CE mark Class B
Cat.3, 4, 5 or higher ( 100 meters max. )
Cat.5, 5e or higher ( 100 meters max. )
Cat.5e or higher ( 100 meters max. )
10Mbps (Half-duplex) 20Mbps (Full-duplex)
100Mbps (Half-duplex) 200Mbps (Full-duplex)
2000Mbps (Full-duplex)
0 C ~ 40 C
o o
-10 C ~ 70 C
o o
10% ~ 90%RH non-condensing
080110
