Table of Content ------------------------------------------------------------------------------------------------------------------------- Introduction ................2 Package Contents ................2 Features .................... 2 Physical Description................3 Installation .................4 Preparing the Site................4 Settling the Switch................4 Connecting to Power................. 4 Connecting to Network..............4 Configuration................6 Setting UP Connection ..............6 Main Page ..................
Compliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE802.1q tag-based VLAN, IEEE802.1p traffic prioritization (CoS) and IEEE802.3x flow control standards Support auto-link and auto-negotiation for all 6 RJ-45 ports Support one 100M multi-mode fiber optic connection with ST (SP607FA) or SC (SP607FB) connector Provide web-based management interface Support DHCP client for IP configuration Support 16 groups of port-based or tag-based (802.1q) VLAN...
1.3 Physical Description SP607FA front view SP607FB front view SP607FA/SP607FB rear view Please refer to the following table for LED definition Status Operation POWER On/Green Power is on Power is off 10/100M 100M link detected 10M link detected LINK/ACT On/Green...
Step 4: Once the connections between two end-devices are made successfully, turn on the power. SP607FA/B provides 6 RJ-45 ports of 10/100M, plus 1 fiber port of 100M. Just connect your stations to it and play. These RJ-45 ports support auto-uplink, and you can make inter-switch connection with no more cross-over cable.
Page 6
For cable selection, refer to the following table: Network Speed Cable Type Max. Length 10Mbps Cat. 3, 4, 5 UTP/STP 100 meters 100Mbps Cat. 5 UTP/STP 100 meters Fiber, 50 or 62.5/125µm 2000 meters multi-mode Note: To prevent costly equipment damage and downtime, please consider installing a surge suppression device or a UPS (Un-interrupted Power Supply).
Configuration 3.1 Setting UP Connection SP607FA/SP607FB is embedded in an http server, and users can access it by web browser over Internet. Default system information of SP607FA/B is IP address: 192.168.0.2 Mask: 255.255.255.0 Login Password: 123 3.2 Main Page After passing the authentication, the main page appears as below.
3.4 IP Setup The switch must be assigned an IP address before it can be managed via web browser. The switch provides two methods for IP configuration: DHCP mode: The switch supports DHCP client, and can request a dynamic IP address from the first discovered DHCP server in the network when boot up.
Note: Any changes are only effective after next bootup. 3.5 VLAN Setup SP607FA/SP607FB supports two modes of VLAN: One is Port-based VLAN, and the other is 802.1Q tag-based VLAN. There are three necessary configurations for VLAN setup: VLAN Mode: Port-based or 802.1Q VLAN...
Note: Tag mode settings are preset with untagged mode for all ports and not changeable in Port-based VLAN mode. VLAN tag in every input tagged packet is ignored. 802.1Q tag-based VLAN Mode This mode supports 16 VLAN groups, Group 0 ~ Group 15. Select Yes to setup members of VLAN in VLAN mapping table.
3.7 Restore Default Enter the page of Restore Default and then click on Restore button. Note: One “RESET” button located on rear panel is used to disable DHCP mode and restore setting back to default. It is useful when the switch is out of control by loss of IP address or login password.
