- Page 1 USER’S MANUAL 8 Port Gigabit Web Smart Switch Model No.: SP6108WS...
- Page 3 FCC Certifications This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 4: Table Of Contents
Table of Contents 1. GENERAL DESCRIPTION ................4 1.1 K .................... 5 EATURES 1.2 P ................... 5 ACKAGE ONTENTS 2. HARDWARE DESCRIPTION................6 2.1 P .................. 6 HYSICAL IMENSION 2.2 T ..................6 RONT ANEL 2.3 LED D ..................7 EFINITION 2.4 T .................. -
Page 5: General Description
1. General Description Easily boosting your networking throughput, the Gigabit Web smart switch SP6108WS provides you 8* 10/100/1000Mbps Gigabit ports that lead you to a real Gigabit connection. Users are now able to transfer high bandwidth-demanded files faster and hence get a real efficiency improvement with the user-friendly Web-based management interface. -
Page 6: Key Features
1.1 Key Features 8* fixed 10/100/1000Mbps Gigabit Ethernet ports for easy network connecting application. Provide Auto-discovery Function for easy Network management. Provide 8K MAC address entries and 8 groups VLAN table Support up to 7 ports and 4 groups port aggregation. Support QoS for better communication quality. -
Page 7: Hardware Description
2. Hardware Description This Section mainly describes the hardware of the 8-port Gigabit Ethernet Web Smart Switch, and gives a physical and functional overview. 2.1 Physical Dimension The 8-port Gigabit Ethernet Web Smart Switch physical dimension is: 266mm x 160mm x 44mm (W x D x H) 2.2 The Front Panel The front panel consists of LED indicators, a restore default button and 8* 10/100/1000 Mbps RJ-45 ports. -
Page 8: Led Definition
2.3 LED Definition LED for the device: The switch provides a power LED for the device. Status Operation Steady Green The switch is powered on Power The switch is powered off LED for each port: The switch provides one “1000M” LED and one “10/100M” LED for each port. -
Page 9: The Rear Panel
2.4 The Rear Panel The rear panel of the switch: Power Receptacle To be compatible with the electric service standards around the world, the switch is designed to afford the power supply in the range from 100 to 240VAC, 50/60Hz. Please make sure that your outlet standard to be within this range. -
Page 10: Installation
3. Installation This switch can be placed on your desktop directly, or mounted in a rack. Please refer to the instructions for installation. Before installing the switch, we recommend: The switch is placed with appropriate ventilation environment. A minimum 25mm space around the unit is recommended. The switch and the relevant components are away from sources of electrical noise such as radios, transmitters and broadband amplifiers The switch is away from environments beyond recommend moisture... -
Page 11: Installing Network Cables
3.3 Installing Network Cables 1. Crossover or straight-through cable: All the ports on the switch support Auto-MDI/MDI-X functionality. Both straight-through or crossover cables can be used as the media to connect the switch with PCs as well as other devices like switches, hubs or router. 2. -
Page 12: Functional Description
4. Functional Description 4.1 Jumbo Frame With Jumbo Frame supported, it is allowed for the switch to transport identical data in fewer frames. Hence helps to ensure fewer overheads, shorten processing time, and reduce interrupts. Note: To enable Jumbo Frame, Flow Control should be enabled in advance. 4.2 Flow Control and Back Pressure Flow control and Back Pressure both contributes for lower and higher speed devices to communicate to each other hence ensures the correctness of... -
Page 13: Quality Of Service (Qos)
4.6 Quality of Service (QoS) The QoS service classifies packets into different precedence. The packets are transmitted and received by their classified priorities. This mechanism helps high bandwidth demanded applications such as VoIP to get an unobstructed connection. 4.7 SNMP This device is SNMP(Simple Network Management Protocol)-management supported. -
Page 14: Web-Based Management
5. Web-Based Management 5.1 Preparing for Web Management Before using web management, install the switch on the network and make sure that any one of the PCs on the network can connect with the switch through the web browser. The switch default of IP, subnet mask, username and password are as follows: 5.2 System Login This section instructs you how to enter and proceed the advanced... -
Page 15: Homepage
5.3 Homepage After authentication procedure, the “SYSTEM Configuration” page shows up as the Homepage. You may click the hyperlinks on the left side of each page to get access to each management functions. 5.4 System The System window provides the switch information and allows users to configure the switch properties. -
Page 16: Port
To save the configuration of the system, click “Apply” to save Note: After applying your configuration, a new login page will be started automatically. Please login again to proceed other configurations. 5.5 Port This Port Configuration page shows the link status of each port and allows users to configure speed, flow control and Max frame size for each port. -
Page 17: Vlan
5.6 VLAN VLAN divides the network members into groups to reduce packets collisions and improve the network efficiency. The switch supports 802.1Q tag-based VLAN. Please follow the instructions to configure. To add new VLAN groups, 1. Fill in a VLAN id from 2 to 4094 in the “VLAN\Port” column. 2. -
Page 18: Pvid
5.7 PVID When the VLAN-enabled switch receives a tagged packet, the packet will be sent to the port’s default VLAN according to the PVID (port VLAN ID) of the receiving port. Items Functions Port Port Number 1~8 Select “tagged” in the drop list to enable the Egress PVID checking and tag inserting of one port, and select “untagged”... -
Page 19: Aggregation/ Trunk Configuration
5.8 Aggregation/ Trunk Configuration To set up the Port trunk groups, put the ports number into the same Aggregation group. There are eight groups to choose. Don’t forget to click the “Apply” to save the setting. There three aggregation modes for you to setup, SMAC (Source MAC), DMAC (Destination MAC), and XOR. -
Page 20: Quality Of Service
5.9 Quality of Service QoS enhances the communication quality by giving different precedence to classified packets. This switch provides port-based, tag-based and DSCP QoS modes: Port-based mode QoS: The port-based QoS allows users to configure certain ports as high or low priority. - Page 21 Tag based QoS: The Tag based QoS decides packet priority according to the tags that adding on the packets. To configure Tag Based QoS configuration: Select “Tagged” in the “Mode” column for those ports that are going to perform tag-based QoS. Click the “Apply” button. Click the “Tag priority”...
- Page 22 Bit 0 (Delay) Bit 1 (Throughput) Bit 3 (Reliability) 0 (Normal) 0 (Normal) 0 (Normal) 1 (Low) 1 (High) 1 (High) Note: The device distinguishes packets with DSCP precedence “000(routine)” only. To configure DSCP Based QoS configuration: Select “DSCP” in the “Mode” column for those ports that are going to perform DSCP-based QoS.
-
Page 23: Mirror
5.10 Mirror The Mirror function copies all the packets that are transmitted by the source port. Those copied packets will be delivered to the destination port. It allows administrators to analyze the traffic of those ports that are monitored. Mirror Configuration: 1. -
Page 24: Storm Filter
5.11 Storm Filter This “storm filter” page allows users to configure the rules for Storm Control, which limits the flow of broadcast and multicast To perform storm control: 1. Click on each drop list to specify a speed for each frame type. 2. -
Page 25: Discovery
5.13 Discovery After installing series of our switches, the discovery management tool helps users to search and get access to those switches within the LAN. Note. The discovery tool lists the Maximum 16 devices respectively for auto and manual modes. Auto Search 1. -
Page 26: Statistics Overview
5.14 Statistics Overview The Statistics Overview is provided for users to see the general transmitting and receiving status of each port. You may click the “Clear” button to clean all statistics or click the “Refresh” button to renew the statistics. 5.15 Detailed Statistics The Detailed Statistics is provided for users to see the detailed transmitting and receiving status of each port. -
Page 27: Restart
5.16 Restart Restart: To restart the system, click the “Yes” button. The system restarts and shows the authentication window. Please fill in the username and password to continue. 5.17 Factory Default Restore Factory Default: To restore the factory default value, click the Yes button. Note: The IP address of the device will also be configured as factory-default setting, which is 192.168.1.1. -
Page 28: Specification
6. Specification IEEE802.3 IEEE802.3u Standards IEEE802.3ab IEEE802.3x 8 RJ-45 ports (10/100M/1000Mbps), Interface Console Port Restore Default Button 10BASE-T : Category 3, 4, 5 UTP/STP Cable Connection 100BASE-TX : Category 5 UTP/STP 1000BASE-TX : Category 5, 5e UTP/STP 10/100/1000Mbps Network Speed Half/Full Duplex Auto Detection 9KByte...
