MicroNet SP659A User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
SP659A
10/100/1000 Mbps Gigabit Smart Switch
Website: http://www.micronet.com.tw
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP659A and is the answer not in the manual?

Questions and answers

Related Manuals for MicroNet SP659A

Summary of Contents for MicroNet SP659A

  • Page 1 User’s Manual SP659A 10/100/1000 Mbps Gigabit Smart Switch Website: http://www.micronet.com.tw...
  • Page 2 FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limitations are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Table Of Contents

    FDX/COL LED 2.3.3 Gigabit Port LEDs The Rear Panel 2.4.1 Power Connecting 2.4.2 Console Port 3. Installing And Using SP659A 10/100/1000M Smart Switch Installing The SP659A 10/100/1000M Smart Switch 3.1.1 Desktop Installation 3.1.2 Rack-Mount Installation 3.1.3 Installing Network Cables 3.1.3.1 Station Connection with Twisted-Pair Cable 3.1.3.2...

  • Page 4: Unpacking Information

    1. Unpacking Information Thank you for purchasing the SP659A 10/100/1000 Mbps Smart Switch. Before you start, please check all the contents of this package. The product package should include the following: 1. SP659A 10/100/1000Mbps Gigabit Smart Switch 2. Console Cable 2.

  • Page 5: Introduction To Sp659A 10/100/1000M Smart Switch

    2. Introduction To SP659A 10/100/1000M Smart Switch 2.1 General Description Micronet SP659A is a powerful, high-performance 10/100/1000 Mbps Fast Ethernet and Gigabit switch, with all 24 ports capable of 10 or 100Mbps auto-negotiation operation (NWay), which means the switch could automatically negotiate with the connected partners on the network speed and duplex mode.

  • Page 6: Key Features

    The switch can use the following types of cabling: 10BASE-T: Category 3, 4 or 5 UTP/STP 100BASE-TX: Category 5 UTP/STP 1000BASE-T: Category 5 or Category 5E UTP/STP Category 5E cable is preferred to be using with this product in structured wiring environments.
  • Page 7 The auto-negotiation feature of the switch allows each port of the device running at one of the following four operation modes: Port Speed Duplex Mode 10/100M 100 Mbps Full-duplex Half-duplex 10 Mbps Full-duplex Half-duplex Gigabit 1000 Mbps Full-duplex 100 Mbps Full-duplex 10 Mbps Full-duplex...

  • Page 8: System Leds

    2.3.1 System LEDs System LED indicators are located on the front panel for showing the operating status of the whole device. 2.3.1.1 Power LED This indicator lights green when the hub is receiving power; otherwise, it is off. 2.3.2 10/100 Port LEDs 10/100 Port LED indicators are located on the front panel for showing the operating status of each 10/100 Mbps port.

  • Page 9: The Rear Panel

    2.3.2.3 Gigabit LED The Gigabit ports support 1000BASE-T media connection and diagnostic LEDs. There are five LEDs for gigabit switching port including 10M, 100M, 1000M, FDX, Link/ACT. 2.4 The Rear Panel The rear panel of the hub is shown below 2.4.1 Power Connecting For compatibility with electric service in most areas of the world, the switching hub’s power supply automatically adjusts to line power in the range...

  • Page 10: Installing And Using Sp659A 10/100/1000M Smart Switch

    3. Installing &Using SP659A 10/100/1000M Smart Switch 3.1 Installing The SP659A 10/100/1000M Smart Switch The switch does not require software configuration. Users can immediately use most of the features of this product simply by attaching the cables and turning the power on.

  • Page 11: Installing Network Cables

    6. Insert the unit into the 19" rack and secure with screws (not provided). 7. Reconnect all cables. 3.1.3 Installing Network Cables After placing the switch on the desktop, then we need to know how to connect the device to network. 3.1.3.1 Station Connections with Twisted-Pair Cable Connect each station to the switch by a Category 5 or Category 5E twisted-pair cable (straight-through or cross-over cable).

  • Page 12: Mac Address Table & Learning

    4. Switch Operation 4.1 MAC Address Table and Learning The switch is implemented with a MAC address table which is composed of many entries. Each entry is used to store the address information of network nodes on the network, including MAC address, port ID, etc. The information is the most important base to do packet filtering and forwarding.

  • Page 13: Console Program

    5. Console Program The switch has an RS-232 console port for direct console management Pin Description DCD (Data Carrier Detect) RX (Receive) TX (Transmit) DTR (Data Terminal Ready) GND (Ground) DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) (RS-232 DB-9, DCE/female connector) When connecting a terminal directly to the switch, use a serial RS232 (straight through) cable.
  • Page 14 1. Port Status/Configuration This function is used to check operating status of all ports and setup the port configuration, like half/full duplex mode and auto-negotiation. 2. VLAN Status/Configuration The device supports six port-based VLAN groups (1, 2, 3, 4, 5 and 6) and the group overlap is allowed.
  • Page 15 4. Factory Reset If you face some problem on current setting and want to make the system go back to the initial state, you can use factory reset. 5. Warm Start System will reboot after selecting this item. The following is the function keys to navigate the console program screens. To do this …...
  • Page 16 Note : If you press [Enter] key without selecting any number of function in advance, the system will return to the previous screen. Port Selection Screen You could select 1-5 to setup duplex mode for each port or select [6] key to return to the previous screen.
  • Page 17 VLAN Group Setting Screen You can select [1] key to add this port to VLAN or select [2] key to remove this port form the VLAN. If you want to return the previous screen or abort the setting, please press [3] key. Trunk Status/Configuration Screen This screen indicates the trunk status of all ports.
  • Page 18 Trunk Group Setting Screen After selecting port number, you can set trunk group function enable/disable of each port. Select [1] key to disable port trunk function or select [2] key to enable the function. If you want to return to the previous screen or abort the setting, please press [3] key.
  • Page 19 Factory Default Screen Warm Start Screen...

  • Page 20: Product Specifications

    6. Product Specifications Standard IEEE802.3, 10BASE-T IEEE802.3u, 100BASE-TX IEEE802.3ab, 1000BASE-T Interface RJ-45 x 24 10/100 auto MDI-X switching ports RJ-45 x 2 10/100/1000 auto MDI-X switching ports One RS-232 console port Cable Connections RJ-45 (10BASE-T) : UTP Cat. 3,4,5 RJ-45 (100BASE-TX) : UTP Cat. 5 RJ-45 (1000BASE-T): UTP Cat.
