- Page 1 Quick Installation Guide 8-Port 10/100M PoE Switch Model No.: SP6008P http://www.micronet.info...
-
Page 2: Package Contents
That makes it suitable to various applications that demand for remote power feeding and meet high level requirement for power. SP6008P is totally equipped with 15.4 Watts per PoE port, which effectively helps allocate power for connected multiple devices and enhances network management. -
Page 3: Back Panel
Back Panel Power Switch and Power Cord Connector LED Indicator For definitions of LED indicators, please refer to the following table: Status Description On/Green Power is On. Power is off. The Ethernet port is connecting with On/Green the device. 10/100M, Blink/Green Receiving or transmitting data. -
Page 4: Hardware Installation
Hardware Installation The setup of the switch can be performed using the following steps: Step 1: Connect the Power Cord to SP6008P and then to a power outlet. Step 2: : Connect a RJ-45 Ethernet cable from IEEE802.3af-compliant devices (PD) to an available PoE port of SP6005P8. - Page 5 Specification Standards IEEE 802.3af IEEE 802.3 10 BaseT IEEE 802.3u 100 BaseTX IEEE 802.3x Flow Control Features Number of Ports: 8 PoE/PSE ports MAC Address: 1k Buffer Memory: 512 bits Transmission Method: Store and Forward Filtering/ 100Mbps port-148,800pps Forwarding 10Mbps port-14,880pps Rates Transmission 10 BaseT Cat 3,4,5 UTP/STP...
- Page 6 Power 130 Watts (Max) Consumption Dimension 20(H) x 58(W) x 87(D) mm Temperature Operating: 0~60oC, Storage: -20~90oC Humidity Operating: 10~90% (Non-Condensing)
-
Page 7: Fcc Certifications
FCC Certifications This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
