- Page 1 User’s Manual Gigabit Smart Switch Model No.: SP698A http://www.micronet.info...
-
Page 2: Table Of Contents
Table of Content ------------------------------------------------------------------------------------------------------------------------- Introduction ................2 Package Contents ................2 Features .................... 2 Physical Description................3 Installation .................4 Preparing the Site................4 Settling the Switch................4 Connecting to Power................. 4 Connecting to Network..............4 Console Interface Configuration..........6 Setting UP Connection ..............6 Main Menu.................. -
Page 3: Introduction
Rack-mount brackets Rubber foot and screws Power cord 1.2 Features Micronet SP698A provides the following features: Compliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX, and IEEE802.3x flow control standards Support auto-negotiation function to automatically select optimal speed (10/100/1000M) and mode (full/half duplex) Support 802.3x flow control for full-duplex mode and back-pressure flow control for... -
Page 4: Physical Description
Support console port for management Standard 19" rack-mount size, one-unit-height 1.3 Physical Description Front view POWER LED This LED comes on when the switch is properly connected to power. Port LEDs Every RJ-45 port on the front panel relevant four LEDs (10M LINK, 100M LINK, 1000M LINK and ACT) for indicating the connection speed and activity status. -
Page 5: Installation
Installation 2.1 Preparing the Site Select the site that meets the following requirements: Characteristic Requirement Temperature 32 to 122˚F (0 to 50˚C) Humidity 10% ~ 90%, non-condensing 2.2 Settling the Switch Mounted to 19-inch standard rack Locate the accessories provided in the product package. Use the rack-mount brackets and screws to install the switch into any EIA 19”... - Page 6 Step 3: Connect one end of the cable to the switch and the other end to a desired device. Step 4: Once the connections between two end-devices are made successfully, turn on the power. In making a switch interconnection, you could use any port to connect another switch with straight or crossover cable.
-
Page 7: Console Interface Configuration
Console Interface Configuration 3.1 Setting UP Connection Users can configure the switch in command line via console port. The operating mode of the console port is 9600 (Fix baud rate) n (No parity checking) 8 (8 Data bits) 1 (1 stop bit) None (No flow control) After attaching a RS-232 cable to the serial port of a PC running a terminal emulation program, press “Enter”... -
Page 8: System Configuration
Port Mirror Configuration Configure source port and target port for mirroring. Reset and Save Save the configured values or reset the switch. Exit Exit the management program. <TAB> Next Item Move to the next item. <ESC> Back Return to previous hierarch or screen. <Enter>... -
Page 9: Port Status
Jumbo Packet: Select Jumbo Packet for 9K, 12K or disable Jumbo Packet. 3.4 Port Status Ports Configuration is applied to change the setting of each port. After pressing enter on the port status on the main menu, the screen will show as below: The [Port Config] menu includes: Admin: Enable a port (On) or disable a port(Off). -
Page 10: Vlan Configuration
There are two modes to choose in flow control, including Enable and Disable. If flow control is set Enable, both parties can send PAUSE frame to the transmitting device(s) if the receiving port is too busy to handle. When it is set Disable, there will be no flow control in the port. -
Page 11: Trunk Configuration
3.6 Trunk Configuration This switch provides 2 trunk groups. Simply by press [Enter] key to enable Trunk groups. Port-1 and port-2 belong to “Trunk A”, port-7 and port-8 belongs to “Trunk B”. For Example: Simply by press [Enter] key to enter the mode and [Space Bar] to enable Trunk A or B Press [ESC] to return to the previous item Remark:... -
Page 12: Port Mirror Configuration
Mirror and Trunk functions cannot be enabled simultaneously. For example, when you activate Port 1 Trunking Function, you cannot use Port1 for as Mirror port, neither source nor target port. 3.7 Port Mirror Configuration The Smart Switch provides Mirror Configuration to snoop a specified port. Setup a monitored port and monitored mode. - Page 13 To save your settings and disconnect the connectivity simultaneously, use [Tab] to select and press [Enter] to activate. Note: Please note that you should save the changes after doing any configuration for the switch. The parameters will be ignored if you restart the switch without saving. Reset to Factory Default: To restore all values to back to the factory default, use [Tab] to select and press [Enter] to activate.
-
Page 14: Specifications
Specifications IEEE802.3, IEEE802.3u, IEEE802.3ab Standard IEEE802.3x flow control 8 * RJ-45 ports (10/100/1000M) Interface 1 * RS-232 console port 10BASE-T: Category 3, 4, 5 UTP/STP Cable Connections 100BASE-TX: Category 5 UTP/STP 1000BASE-T: Category 5, 5e UTP/STP 10/100/1000M & full/half duplex mode auto detection (1000M for full Network Speed duplex only) Feature...
