- Page 1 User’s Manual EtherFast 10/100M Smart Switch Model No.: SP648B http://www.micronet.info...
-
Page 2: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 3 UL Warning a) Elevated Operating Ambient Temperature- If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer's maximum rated ambient temperature (Tmra).
-
Page 5: Table Of Contents
Ports 1~48 10/100M Status LEDs...10 Ports 49~50 Gigabit Status LEDs ...10 Ports 51~ 52 mini-GBIC Status LEDs ...11 Configuration ...12 Installing the Web Management Utility...12 Discovery List...13 Monitor List ...13 Device Setting...14 Toolbar...16 Configuring the Switch ...16 Login...17 Setup Menu ...18 Table of Content... - Page 6 Configuring Setup Setting...19 Port Settings...19 VLAN Settings (Virtual Local Area Network) ...20 Trunk Setting ...21 Device Status ...22 Statistic...22 System Setting ...23 Trap Setting...23 Set Password ...24 Backup Setting ...24 Reset Setting ...25 Logout...25 Technical Specifications ...26...
-
Page 7: About This Guide
This guide discusses how to install your 48+4G-Port 10/100/1000Mbps Gigabit Ethernet Web Smart Switch. Terms/Usage In this guide, the term “Switch” (first letter upper case) refers to your 48+4G-Port 10/100/1000Mbps Gigabit Ethernet Web Smart Switch, and “switch” (first letter lower case) refers to other Ethernet switches. -
Page 8: Introduction
INTRODUCTION This chapter describes the features of the 48+4G-Port 10/100/1000Mbps Gigabit Ethernet Smart Switch Ethernet/Gigabit Ethernet switching technology. Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the same packet structure, format, and support for CSMA/CD protocol, full duplex, flow control, and management objects, but with a tenfold increase in theoretical throughput over 100-Mbps Fast Ethernet and a hundredfold increase over 10-Mbps Ethernet. -
Page 9: Switching Technology
Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. -
Page 10: Vlan (Virtual Local Area Network)
Cost Reduction, VLANs can be used to create multiple broadcast domains, thus eliminating the need of expensive routers. Port-based (or port-group) VLAN is the common method of implementing a VLAN, and is the one supplied in the Switch. Features 48×10/100Mbps Auto-negotiation Fast Ethernet RJ45 ports 2×10/100/1000Mbps Auto-negotiation Gigabit RJ45 ports... - Page 11 Easy setting via Web Management Utility Standard 19” Rack-mount size...
-
Page 12: Unpacking And Installation
Leave at least 10cm of space at the front and rear of the hub for ventilation. Install the Switch on a sturdy, level surface that can support its weight, or in an EIA standard-size equipment rack. For information on rack installation, see the next section, Rack Mounting. -
Page 13: Connecting Network Cable
Figure 1. Combine the Switch with the provided screws Then, use screws provided with the equipment rack to mount each switch in the rack. Connecting Network Cable The Switch supports 10Mbps Ethernet or 100Mbps Fast Ethernet and it runs both in half and full duplex mode using two pair of Category 5 cable. -
Page 14: Identifying External Components
IDENTIFYING EXTERNAL COMPONENTS This chapter describes the front panel, rear panel, and LED indicators of the Switch. Front Panel The figure below shows the front panels of the Switch. Figure 3. Front panel of 48+4G-port Gigabit Ethernet Switch LED Indicator: Comprehensive LED indicators display the status of the switch and the network (see the LED Indicators chapter below). -
Page 15: Rear Panel
Rear Panel Figure 4. Rear panel of the Switch AC Power Connector: This is a three-pronged connector that supports the power cord. Plug in the female connector of the provided power cord into this connector, and the male into a power outlet. -
Page 16: Understanding Led Indicators
The front panel LEDs provides instant status feedback, and, helps monitor and troubleshoot when needed. Power and System LEDs POWER: Power Indicator : When the Power LED lights on, the Switch is receiving power. : When the Power turns off or the power cord has improper connection. SYSTEM: Management Indicator Blinking : When the CPU is working, the System LED is blinking. -
Page 17: Ports 51~ 52 Mini-Gbic Status Leds
: No link. SPEED: : When the green light is on, the respective port is connected to a (Green) 1000Mbps Gigabit Ethernet network. When the Amber light is on, the respective port is connected to a (Amber) 100Mbps Fast Ethernet network. : When the respective port is connected to a 10Mbps Ethernet or No link Ports 51~ 52 mini-GBIC Status LEDs Link/ACT: Link/Activity... -
Page 18: Configuration
CONFIGURATION Through the Web Browser you can configure the Switch such as VLAN, Trunking, QoS… etc. With the attached Web Management Utility, you can easily discover all the Web Management Switch, assign the IP Address, changing the password and upgrading the new firmware. -
Page 19: Discovery List
Discovery List This is the list where you can discover all the Web management devices in the entire network. By pressing the “Discovery” button, you can list all the Web Management devices in the discovery list. Double click or press the “Add to monitor list” button to select a device from the Discovery List to the Monitor List. -
Page 20: Device Setting
Note: In order to receive Trap information, switch has to be configured with Trap IP and Trap Events in Web browser, which are available in the Trap Setting Menu (see Page 40 for detail). - Page 21 The factory default password is "admin". Figure 9. Configuration Setting Password Change: You can use this Password Change when you need to change the password, fill in the password needed in the dialog box and press “Set” button to proceed the password change immediately.
-
Page 22: Toolbar
The Switch can be configured through the Web Browser. A network administrator can manage, control and monitor the switch from the local LAN. This section indicates how to configure the Switch to enable its smart functions including:... -
Page 23: Login
Login Before you configure this device, note that when the Web Smart Switch is configured through an Ethernet connection, make sure the manager PC must be set on same the IP network. For example, when the default network address of the default IP address of the Web Smart Switch is 192.168.0.1, then the manager PC should be set at 192.168.0.x... -
Page 24: Setup Menu
Figure 14. Device Status Setup Menu When the main page appears, find the Setup menu in the left side of the screen (Figure 15). Click on the setup item that you want to configure. There are eleven options: Port Settings, VLAN Settings, Trunk Setting, Device Status, Statistic, System Settings, Trap Setting, Password Setting, Backup Setting and Reset Setting as shown in the Main Menu screen. -
Page 25: Configuring Setup Setting
Configuring Setup Setting Find that there are four items, including Port Settings, VLAN Settings and Trunk Settings in Setup menu. Port Settings In Port Settings menu (Figure 16), this page will show each port’s status, press the ID parameter to set each port’s Speed, Flow Control, and QoS priority. When you need to renew the posted information, press the “Refresh”... -
Page 26: Vlan Settings (Virtual Local Area Network)
Note: If speed set to be exist 100M full mode or 10M full mode, flow control have fixed setting to disable Flow Control: This setting determines whether or not the Switch will be handling flow control. Set FlowCtrl to Enable for avoiding data transfer overflow. Or it sets to Disable; there is either no flow control or other hardware/software management. -
Page 27: Trunk Setting
Once you want to modify the VLAN Group, check on the ID parameter, the ID VLAN configuration window will pop out. Note 1: group 1 and Group 2 can not be managed at the same time Note 2:When add a new Vlan, the members of default Vlan 1 are removed automatically. Therefore, packets can only transmit among the member ports of new Vlan. -
Page 28: Device Status
Device Status Click on the “Status” to present the device status on this screen, it will show the System Status, Port Status, VLAN Status and Trunk Status . Press “Refresh” when you need to renew the posted information. Statistic The Statistic Menu screen will show the status of each port packet count. Figure 23. -
Page 29: System Setting
Figure 24. System Setting The System Setting includes the System name, Location name, Login Timeout, IP Address, Subnet Mask and Gateway. Through the Web Management Utility, you can easily recognize the device by using the System Name and the Location Name. The Login Timeout is to set the idle time-out for security issue, when there is no action when running the Web Smart Utility and the time is up, you must re-login to Web Smart Utility before you set the Utility. -
Page 30: Set Password
Password is the invaluable tool for the manager to secure Web Management Switch, use this function to change the password. If you forget the password, press the “Reset” button in the rear panel of the Switch, the current setting includes VLAN, Port Setting… etc. will be lost and the Switch will restore to the default setting. -
Page 31: Reset Setting
To restore a current setting file to the device, you must specify the backup file and press “Restore” button to proceed the setting of the recorded file. Figure 28. Backup Setting Note: when restoring a recorded file, the current password will not be erased. Reset Setting The Factory Reset button helps you to reset the device back to the default setting from the factory. -
Page 32: Technical Specifications
TECHNICAL SPECIFICATIONS Standards Protocol Data Transfer Rate Topology Network Cables Number of Ports AC inputs Power Consumption Temperature Humidity Dimensions EMI: Safety: Transmits Method: Filtering Table: Packet Filtering/Forwarding Rate: Learning: Transmits Method: RAM Buffer: General IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3z 1000BASE-SX/LX Gigabit Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3x Full Duplex Flow Control...
