MicroNet SP6005P4 Quick Installation Manual

Note:
1. Ports 1 to 4 are used for connecting to PD or PoE splitter for
1. end devices.
2. For high power applications, the PD or PoE splitter has to be
1. c ompliant with pre-802.3at standard.
3. Port 5 is the RJ-45 uplink port that connects with non-PoE
1. Device.
For cable selection, refer to the following table:
Network Speed Cable Type
10M
Cat. 3,4,5,5e UTP/STP
100M
Cat. 5,5e UTP/STP
Note:
To prevent costly equipment damage and downtime, please
consider installing a surge suppression device or a UPS (Un-
interrupted Power Supply).
FCC Certifications
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and radiates radio frequency energy and, if
not installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at own expense. This
device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received; including interference that may cause
undesired operation.
CE Mark Warning
This equipment complies with the requirements relating to
electromagnetic compatibility of the essential protection
requirement of Council Directive 89/336/EEC on the
approximation of the laws of the Member States. Company has
an on-going policy of upgrading its products and it may be
possible that information in this document is not up-to-date.
Please check with your local distributors for the latest
information. No part of this document can be copied or
reproduced in any form without written consent from the
company.
WEEE Directive & Product Disposal
At the end its serviceable life ,this product should not be treated
as household or general waste. It should be handed over to the
applicable collection point for the recycling of electrical and
electronic equipment, or returned to the supplier for disposal.
P/N: 2300-0580
Max. Length
100 meters
100 meters
5
7
Specifications
Module
Standards IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX
IEEE 802.3af / pre-802.3at Power over Ethernet
Hardware 1 x RJ-45 ports of 10/100M (#5)
4 x RJ-45 PoE ports of 10/100M (#1 - #4)
MAC address: 2K
Buffer memory: 512KB
Features Auto negotiation for 10/100M ports
Auto MDI/MDI-X for 10/100M ports
Max. 61.6W system feeding power
Deliver high power 48/30/20W for 1/2/3 PDs
OVP (Over Voltage Protection)
OCP (Over Current Protection)
OTP (Over Temperature Protection)
SCP (Short Circuit Protection)
Surge protection
LED indicators for PoE activity
Power Supply DC 48V, 1.25A
Environment Operating Temperature: 0 55 degree C
Storage Temperature: -20 90 degree C
Relative Humidity: 10 to 90%
Dimension 120 x 90 x 28 (mm)
Emission CE
Quick Installation Guide
5-Port 10/100M PoE Switch, 4 PoE Ports
Model No.: SP6005P4
Web: www.micronet.com.tw ; www.micronet.info
SP6005P4
6
