MULTIQUIP GA3.6HR Operating Manual page 57

HONDA GX240RT2EDN2 — CARbuRETOR ASSy.
NO. paRT NO.
1#@ 16010ZE3701
2@ 16011ZA0931
3@ 16013Z1C003
4@ 16015ZA0931
5@ 16016ZH7W01
6#@ 16024124760
7@ 16028ZA0931
8 16100Z8S932
9@ 16124ZE0005
10@ 16148141881
11@ 16166Z8S931
12@ 16172ZE3W10
13 16211ZE2701
14 16221Z5K000
15 16212Z5K000
16@ 16230ZE3702
17 16260ZE3D22
18& 16261ZE2702
19& 16262ZE2711
20& 16263ZA0000
21& 16264ZE2701
22& 16265ZE2721
23& 16268ZE2721
25& 16400ZE2704
26& 16611ZE3D21
27& 16613893000
28& 16615893000
29 36135ZF6D41
30& 53149964003
31 88911MJ3000
32& 90431ZE2700
33& 90432ZE2700
34& 90433ZE2700
35& 90434ZE2700
36 90650SD9003
37& 93500050120A
38@ 938920501208
39 9405006000
40& 9410305000
41& 9454002010
42& 9454004010
43& 9454007010
44 9500202070
45 950053506510
46 950053513010
47@ 99101ZH80780
47@ 99101ZH80800
47@ 99101ZH80820
48@ 99204ZE00380
49 16220ZA0702
50 17228Z5T000
ga3.6HR 60 hz gENERATOR • OpERATiON ANd pARTs mANuAl — REv. #0 (09/17/14) — pAgE 57
pART NAmE
GASKET SET
VALVE SET, FLOAT
FLOAT SET
CHAMBER SET, FLOAT ....................................1................INCLUDES ITEMS W/#
SCREW SET, PILOT
SCREW SET, DRAIN
SCREW SET
CARBURETOR ASSY. (BE72R A) .....................1................INCLUDES ITEMS W/@
SCREW, THROTTLE STOP
CAP, CHOKE DUST
NOZZLE, MAIN
COLLAR, SETTING
INSULATOR, CARBURETOR
PACKING, CARBURETOR
PACKING, INSULATOR
VALVE ASSY., SOLENOID
STAY ASSY., MANUAL CHOKE .........................1................INCLUDES ITEMS W/&
STAY COMP., SOLENOID
LEVER, CHOKE
JOINT, ROD
ROD, CHOKE
STOPPER, CHOKE ROD
SPRING, MANUAL CHOKE
DIAPHRAGM ASSY.
ROD, CHOKE CONTROL
GROMMET, CHOKE ROD
GUIDE, CHOKE ROD
VALVE, DASHPOT CHECK
BUSH, ARM PIVOT
GROMMET, FENDER
WASHER, CHOKE LEVER
SEAL, CHOKE LEVER
WASHER, THRUST, 2.7X8
COLLAR, LEVER
CLIP, WIRE HARNESS
SCREW, PAN 5X12
SCREW, WASHER 5X12 ..................................2................REPLACES P/N 938920501218
NUT, FLANGE 6MM
WASHER, FLAT 5MM
E-RING 2MM
E-RING 4MM
E-RING 7MM
CLIP, TUBE (B7)
TUBE, 3.5X65
TUBE, 3.5X130
JET, MAIN #78
JET, MAIN #80
JET, MAIN #82
JET SET, PILOT #38
SPACER, CARBURETOR
PACKING, AIR CLEANER
QTY. REmARks
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
2
2
1
1
1
1
4
1
1
1
1
1
1
1
1
