MULTIQUIP GA3.6HR Operating Manual page 43

NO. paRT NO.
1 7911002003
1-1
1-2 0601823213
1-2A 0601822638
1-3 0071706304
2 7911017004
3 0801086104
4 A3135000003
5 7901315502
6 7871315022D
7 7875021523
8 7661331003
9 7911316004
10 7871329514
11 0601851760
12 0013608020
13 0040008000
ga3.6HR 60 hz gENERATOR • OpERATiON ANd pARTs mANuAl — REv. #0 (09/17/14) — pAgE 43
pART NAmE
ROTOR ASSY.
FIELD ASSY.
RECTIFIER
SURGE ABSORBER
BEARING
SET BOLT, ROTOR
SET WASHER, BEARING
ARMATURE ASSY.
END BRACKET
END BRACKET ................................................1................REPLACES P/N 7871315022
GUIDE PANEL, AIR
COVER
SET BOLT, STATOR
GROMMET
CAP
HEX. HEAD BOLT
WASHER, LOCK
GA3.6HR — GENERATOR ASSy.
QTY.
1
1
2
2
1
1
1
1
1
1
1
4
1
1
4
4
REmARks
