MULTIQUIP GA3.6HR Operating Manual page 20

14. Full power switch – The generator is provided with a
full power switch. Figure 6 and Figure 7 show simplified
wiring diagrams of the dual voltage system.
When the full power switch is in the 120 volt (up)
position, you can access the full rated power of the
generator at 120 volts from the GFCI duplex receptacle
and the120V twist-lock receptacle, or a combination
of both receptacles as long as the total load does not
exceed the generating set capacity.
V
H
U1
W
V1
U2
SW 120V
V2
9 8 7
6 5 4
3 2 1
Figure 6. 120V Full Power Switch
Simplified Diagram (Up Position)
NOTICE
When the full power switch is in the 120V position, the
240V twist-lock receptacle cannot be used..
page 20 — ga3.6HR 60 hz gENERATOR• OpERATiON ANd pARTs mANuAl — REv. #0 (09/17/14)
GA-3.6HR
120V 120V
20A 20A
Figure 5. Full Power Switch
CON1 CON3
CB
22 CON2
CON4
COmPONENTS (GENERATOR)
ON ON
0N 0N
V V 120 120
120 120 OFF OFF
P P F F
O O A A
IDLE OFF OFF
W W U U
E E L L AC VOLTMETER AC VOLTMETER
R R T T CONTROL OPERATION OPERATION
SWITCH SWITCH
120V 120V
MANUAL RESET MANUAL RESET
AC CIRCUIT BREAKER AC CIRCUIT BREAKER
QUARTZ QUARTZ GFCI PROTECTED GFCI PROTECTED
240/120V 240/120V
120V 120V
FULL POWER FULL POWER
SWITCH SWITCH
120V 120V 120V 120V 120/240V 120/240V
20A 20A
20A 20A 30A 30A 30A 30A
When the switch is in the 240 volt (down) position, you can
access half of the rated power of the generating set at 120
volts from the GFCI duplex receptacle and up to half of the
rated power of the set at 120 volts from 120V twist-lock
receptacle; or full rated power of the set at 240 volts from
the 240V twist-lock receptacle.
U1
W
V1
U2
V2
CON5
Figure 7. 240/120V Full Power Switch
Simplified Diagram (Down Position)
NOTICE
When using a combination of receptacles, total load
should not exceed the rated capacity of the generator.
14
V CB
H
SW 120/240V
22
9 8 7
6 5 4
3 2 1
CON1 CON3
CON5
CON2
CON4
