MULTIQUIP GA3.6HR Operating Manual page 47

NO. paRT NO.
1 A3417000502
2 A3417100204
3 011106015
4 7915443003
5 7895419004
6 1665419004
7 020108060
8 0017108030
9 0017108040
10 Y0207008000
11 A3361000004
12 0430430120
13 0641360030
14 0602125034
15 16950ZB4015
15-1 16952KJ9752
16 Y0605513215
17 950024080008
18 7855525514
19 7855525604
20 011208030
21 011008020
22 A9117200103
23 0601850097
24 011208025
25 020108060
26 0601851116
27 011208025
28 0207608000
29 0042108000
30 0019206015
31 7915455103
32 7855455003
33 011106015
34 0605507002
35 0605513202
36 Y0605513210
37 0605513189
38 0605515223
39 A3261600103
40 A3261600204
41 011106015
42 0605515170
43 Y0605515229
ga3.6HR 60 hz gENERATOR • OpERATiON ANd pARTs mANuAl — REv. #0 (09/17/14) — pAgE 47
pART NAmE
PIPE FRAME
BRACKET
HEX. HEAD BOLT ..............................................4................REPLACES P/N 0017106015
BASE
RUBBER SUSPENSION
RUBBER SUSPENSION ...................................2................REPLACES P/N 1725419214
HEX. NUT ..........................................................8................REPLACES P/N 0207008000
HEX. HEAD BOLT
HEX. HEAD BOLT
HEX. NUT
FUEL TANK
CAP, FUEL TANK ...............................................1................REPLACES P/N 0605505068
FUEL FILTER .....................................................1................REPLACES P/N 0605505162
FUEL GAUGE
FUEL STRAINER ...............................................1................REPLACES P/N 0605510068
SCREEN SET ....................................................1................REPLACES P/N 16952ZB4005
HOSE
HOSE BAND
RUBBER CUSHION
COLLAR
HEX. HEAD BOLT ..............................................2................REPLACES P/N 0017108030
HEX. HEAD BOLT ..............................................2................REPLACES P/N 0017108020
HANGER
STOPPER
MACHINE SCREW ............................................1................REPLACES P/N 0021008025
HEX. NUT ..........................................................1................REPLACES P/N 0207008000
PLASTIC WASHER
HEX. HEAD BOLT ..............................................2................REPLACES P/N 0011308025
HEX. NUT
WASHER, FLAT
HEX. HEAD BOLT
COVER
COVER
HEX. HEAD BOLT ..............................................6................REPLACES P/N 0017106015
CANISTER
HOSE
HOSE
HOSE
HOSE BAND
BRACKET
STOPPER
HEX. HEAD BOLT ..............................................3................REPLACES P/N 0016906015
HOSE BAND
HOSE BAND
GA3.6HR — PIPE FRAmE ASSy.
QTY.
1
1
1
2
2
2
2
1
1
1
2
2
2
1
1
2
2
2
1
1
1
1
1
1
1
2
1
1
1
1
REmARks
