OPERATION AND PARTS MANUAL
MODEL GA-6H/GA-6HA
Portable Generators
(HONDA GASOLINE ENGINE)
Revision #0 (06/02/05)
THIS MANUAL MUST ACCOMPANY
THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-6H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MULTIQUIP GA-6H

Summary of Contents for MULTIQUIP GA-6H

  • Page 1 OPERATION AND PARTS MANUAL MODEL GA-6H/GA-6HA Portable Generators (HONDA GASOLINE ENGINE) Revision #0 (06/02/05) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 2 PAGE 2 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 3 © COPYRIGHT 2005, MULTIQUIP INC. Multiquip Inc, the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of thier respective owners and used with permission.

  • Page 4: Table Of Contents

    Generators Assembly ........42-43 Control Box Assembly (GA-6H) ......44-45 Control Box Assembly (GA-6HA) ....... 46-47 Muffler Assembly ..........48-49 Pipe Frame Assembly ........50-51 PAGE 4 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 5: Here's How To Get Help

    POST OFFICE BOX 6254 CARSON, CALIFORNIA 90749 310-537-3700 • 800-421-1244 Toll-free nationwide — 800-427-1244 FAX: 310-537-3927 Toll-free FAX — 800-6-PARTS-7 E-MAIL: mq@multiquip.com (800/672-7877) INTERNET: www.multiquip.com GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 5...

  • Page 6: Safety Message Alert Symbols

    You CAN be INJURED if you DO NOT follow WARNING WARNING WARNING WARNING WARNING Respiratory Hazards these directions. ALWAYS wear approved respiratory protection when required. PAGE 6 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 7 CAUTION CAUTION CAUTION CAUTION CAUTION Eye and Hearing Hazards ALWAYS wear approved eye and hearing protection. GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 7...

  • Page 8: Rules For Safe Operation

    ■ NEVER use accessories or attachments, which are not warranties. recommended by Multiquip for this equipment. Damage to the equipment and/or injury to user may result. PAGE 8 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 9: Maintenance Safety

    ■ ALWAYS make sure the generators are properly grounded to a suitable earth ground (GROUND ROD). See installation in this manual. ■ NEVER use gas piping as an electrical ground. GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 9...
  • Page 10 Failure to do so could result in electrical shock or burn causing serious injury or even death! PAGE 10 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 11 Machine Safety Decals The GA-6H/GA-6HA portable generators are equipped with a number of safety decals (Figure 1). These decals are provided for operator safety and maintenance information. The illustration below shows these decals as they appear on the machine. Should any of these decals become unreadable, replacements can be obtained from your dealer.
  • Page 12 Generally, the engine's output power will decrease 3-1/2% for each 1000 feet of altitude above sea level, and 1% for each 10 ° ° ° ° ° Fahrenheit above the standard temperature of 60 PAGE 12 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 13 ) . g In keeping with Multiquip's policy of constantly improving its products, the NOTE specifications quoted herein are subject to change without prior notice. GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 13...
  • Page 14 GA-6H/GA-6HA — DIMENSIONS Figure 2. Dimensions PAGE 14 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 15: Specifications (Generator)

    6HA has two). ■ 21 amp main circuit breaker . ■ AC Voltmeter ■ Ground Terminal ■ Full Power Switch ■ Idle Control Switch ■ Operation Switch GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 15...

  • Page 16: Load Application

    100W. If the NOTE generator. load capacity is less than 100W, place the idle control switch in the OFF position. PAGE 16 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 17: Controls And Indicators

    Operation Switch – Place this rocker switch in the "ON" position (up) for normal operation. To turn-off the generators, place the operation switch in the "OFF" position (down). GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 17...
  • Page 18 Simplified Diagram (Down Position) Simplified Diagram (Up Position) When the full power switch is in the 120V position, the 240V twist-lock NOTE receptacle cannot be used . PAGE 18 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 19 Make sure the generators is placed on level ground. Placing the generators on level ground will ensure that the low oil sensor will function properly. GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 19...

  • Page 20: Generators Refueling

    REMOVE generators from truck bed and place on ground (Figure 4) to refuel. This possibility exist of fire or explosion due to static electricity. Figure 4. Generators Refueling PAGE 20 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 21: Installation

    3. NEC article 250-52(c) specifies that the earth ground boots and gloves to insulate the rod should be buried a minimum of 8 ft. into the ground. body from a short circuit. GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 21...
  • Page 22 At the generator, connect the terminal of the ground cable between the lock washer and the nut (Figure 5) and tighten the nut fully. Connect the other end of the ground cable to a suitable earth ground (ground rod). Figure 5. Generators Grounding PAGE 22 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 23: Pre-Inspection (Engine)

    . t f . t f . t f . t f . t f . t f . t f . t f t l o GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 23...
  • Page 24 4. If the oil level is low (Figure 8), fill to the edge of the oil filler hole with the recommended oil type (Table 5). Maximum oil capacity is 1.16 quarts (1.1 liters) PAGE 24 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 25: Initial Start-Up (Engine)

    DO NOT pull the starter rope all the way to the end. DO NOT release the starter rope after pulling. Allow it to Figure 11. Engine Fuel Valve Lever (ON Position) rewind as soon as possible. GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 25...

  • Page 26: Initial Start-Up/Generators Operation

    1. Place main circuit breaker (Figure 17) in the ON position. Figure 17. Main Circuit Breaker (ON) Figure 20. Full Power Switch 240/120 V Position (Down) PAGE 26 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 27: Generators Operation/Shutdown

    1. If small wattage power tools are required, connect them Figure 25. Engine Fuel Valve Lever (OFF Position) to the 60 Hz output receptacles at this time. 6. Remove all loads from the generator. GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 27...

  • Page 28: Preparation For Long Term Storage

    ■ Clean all external parts of the generating set with a cloth. ■ Cover the generating set and store in a clean, dry place. PAGE 28 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 29 NOTE PAGE GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 29...
  • Page 30 ) 3 ( a i c i t a r e t t n i r e t . s l PAGE 30 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 31: Maintenance (Engine)

    Table 5. For engine oil capacity, see Table 2 (engine specifications). DO NOT overfill. 4. Install drain bolt with sealing washer and tighten se- curely. Figure 27. Engine Oil (Draining) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 31...
  • Page 32 GA-6H — WIRING DIAGRAM (GENERATOR) GA-6H WIRING DIAGRAM Figure 29. Generators Wiring Diagram (GA-6H) PAGE 32 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 33 GA-6HA — WIRING DIAGRAM (GENERATOR) GA-6HA WIRING DIAGRAM Figure 30. Generators Wiring Diagram (GA-6HA) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 33...

  • Page 34: Troubleshooting (Engine)

    . r e u f l o i t t e r . r o r o t o l f . t a PAGE 34 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 35 B " " K v i t r o t . l a t e r . r o e " c i r GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 35...

  • Page 36: Troubleshooting (Generator)

    . d i V " . " T o r t e c i u f l o i t l o r c i v PAGE 36 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 37 NOTE PAGE GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 37...

  • Page 38: Explanation Of Code In Remarks Column

    , belong to the same assembly or kit. If more than one of the same reference number is listed, the NOTE last one listed indicates newest (or latest) part available. PAGE 38 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 39: Suggested Spare Parts

    1 ..3015419604 ....SHOCK MOUNT 4 ..1665419004 ....SHOCK MOUNT 3 ..9807955846 ....SPARK PLUG 1 ..34150ZH7003 ...ALERT UNIT, OIL 2 ..28462ZV7003 ...ROPE, RECOIL 3 ..17211899000 ....ELEMENT AIR CLEANER GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 39...

  • Page 40: Nameplate And Decals

    GA-6H/GA-6HA — NAMEPLATE AND DECALS. NAME PLATE ASSY. PAGE 40 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 41 DECAL; CAUTION OPER. AT 3600 RPM ONLY ..1..S-4461 8700611804 DECAL; WARNING DANGEROUS GAS ..... 1..S-4984 8700611904 DECAL; DANGER ELECTRICAL SHOCK HAZ..1..S-4985 GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 41...
  • Page 42 GA-6H/GA-6HA — GENERATOR ASSY. GENERATOR ASSY. PAGE 42 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 43 GUIDE PANEL, AIR 7871331003 COVER 7901316004 SET BOLT, STATOR 0040008000 SPRING WASHER 0041208000 PLAIN WASHER 7871329514 GROMMET 0601851760 CAP, 0B-13 0013608020 HEX, HEAD BOLT 0040008000 SPRING WASHER GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 43...
  • Page 44 GA-6H — CONTROL BOX ASSY. CONTROL BOX ASSY. (GA-6H) PAGE 44 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 45 0601831620 OPERATION SWITCH, C1550WA 0021004015 MACHINE SCREW 0207004000 HEX, NUT µ A3262800004 CAPACITOR ASSY., VR1H102MHA, 50V 1000 0017106016 HEX, HEAD BOLT 0017105010 HEX, HEAD BOLT GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 45...
  • Page 46 GA-6HA — CONTROL BOX ASSY. CONTROL BOX ASSY. PAGE 46 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 47 0601831620 OPERATION SWITCH, C1550WA 0021004015 MACHINE SCREW 0207004000 HEX, NUT µ A3262800004 CAPACITOR ASSY., VR1H102MHA, 50V 1000 0017106016 HEX, HEAD BOLT 0017105010 HEX, HEAD BOLT GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 47...
  • Page 48 GA-6H/GA-6HA — MUFFLER ASSY. MUFFLER ASSY. PAGE 48 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 49 BOLT HEX HEAD 7905469004 BRACKET 0017108025 BOLT HEX HEAD 020708000 HEX NUT 0017108020 BOLT HEX HEAD 7905469004 BRACKET 0017106020 BOLT HEX HEAD 0017106012 BOLT HEX HEAD GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 49...
  • Page 50 GA-6H/GA-6HA — PIPE FRAME ASSY. PIPE FRAME ASSY. PAGE 50 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 51 HEX, HEAD BOLT 0037908000 HEX, NUT 0042108000 PLAIN WASHER 0019206016 HEX, HEAD BOLT 7915456004 STOPPER 0017106016 HEX, HEAD BOLT 7915455103 COVER 55455003 COVER 0017106016 HEX, HEAD BOLT GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 51...
  • Page 52 HONDA GX340K1EDE2 ENGINE — AIR CLEANER ASSY. AIR CLEANER ASSY. PAGE 52 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 53 CLIP A, AIR CLEANER WIRE 17236899000 CLIP B, AIR CLEANER WIRE 17252899000 SEAL, AIR CLEANER 17367413690 FILTER, DRAIN TUBE 9405005000 NUT, FLANGE (5MM) 9405006000 NUT, FLANGE (6MM) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 53...
  • Page 54 HONDA GX340K1EDE2 ENGINE — CAMSHAFT ASSY. CAMSHAFT ASSY. PAGE 54 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 55 14773ZE2000 RETAINER, EX. VALVE SPRING 14775ZE2010 SEAT, VALVE SPRING 14781ZE2000 ROTATOR, VALVE 14791ZE2010 PLATE, PUSH ROD GUIDE 90012ZE0010 BOLT, PIVOT (8MM) 90206ZE1000 NUT, PIVOT ADJ. GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 55...
  • Page 56 HONDA GX340K1EDE2 ENGINE — CARBURETOR ASSY. CARBURETOR ASSY. PAGE 56 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 57 950053500810M BULK HOSE, VACUUM (3.5X8000) (3.5X130) 99101ZH80950 JET, MAIN (#95) (OPTIONAL) 99101ZH80980 JET, MAIN (#98) (OPTIONAL) 99101ZH81000 JET, MAIN (#100) 99204ZE00350 JET SET, PILOT (#35) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 57...
  • Page 58 HONDA GX340K1EDE2 ENGINE — CONTROL ASSY. CONTROL ASSY. PAGE 58 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 59 CONTROL ASSY..........1 ... INCLUDES ITEMS W/ 16584883300 SPRING, CONTROL ADJUSTING 90013883000 BOLT, FLANGE (6X12) (CT200) 90015ZE5010 BOLT, GOVERNOR ARM 93500050350A SCREW, PAN (5X35) 9405006000 NUT, FLANGE (6MM) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 59...
  • Page 60 HONDA GX340K1EDE2 ENGINE — CRANKCASE COVER ASSY. CRANKCASE COVER ASSY. PAGE 60 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 61 PIN, DOWEL (8X12) 92102ZE3004 OIL SEAL (35X52X8) 9410106800 WASHER, PLAIN (6MM) 957010804000 BOLT, FLANGE (8X40) 961006202000 BEARING, RADIAL BALL (6202) 961006207000 BEARING, RADIAL BALL (6207) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 61...
  • Page 62 HONDA GX340K1EDE2 ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PAGE 62 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 63 HONDA GX340K1EDE2 ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PART NO. PART NAME QTY. REMARKS 13310ZE3701 CRANKSHAFT (E-TYPE) 13351ZE3010 WEIGHT, BALANCER 961006207000 BEARING, RADIAL BALL (6207) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 63...
  • Page 64 HONDA GX340K1EDE2 ENGINE — CYLINDER BARREL ASSY. CYLINDER BARREL ASSY. PAGE 64 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 65 O-RING (13.5X1.5) (ARAI) 9405010000 NUT, FLANGE (10MM) 9410912000 WASHER, DRAIN PLUG (12MM) 9425110000 PIN, LOCK (10MM) 957010601200 BOLT FLANGE (6X12) 961006202000 BEARING, RADIAL BALL (6202) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 65...
  • Page 66 HONDA GX340K1EDE2 ENGINE — CYLINDER HEAD ASSY. CYLINDER HEAD ASSY. PAGE 66 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 67: Cylinder Head Assembly

    BOLT 2, STUD (8X32) 90441ZE2010 WASHER, HEAD COVER 9430112200 PIN A, DOWEL (12X20) 957011008000 BOLT, FLANGE (10X80) 9807955846 SPARK PLUG (BPR5ES) (NGK) (OPTIONAL) 9807955855 SPARK PLUG (W16EPR-U) (DENSO) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 67...
  • Page 68 HONDA GX340K1EDE2 ENGINE — FAN COVER ASSY. FAN COVER ASSY. PAGE 68 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 69 PART NAME QTY. REMARKS 19610ZE3700ZB COVER, FAN *NH1* (BLACK) 19631ZE3W00 SHROUD 81329567020 GROMMET, DRAIN HOLE 90013883000 BOLT, FLANGE (6X12) (CT200) 90654SA4003 CLIP, WIRE HARNESS (6MM) (WHITE) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 69...
  • Page 70 HONDA GX340K1EDE2 ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PAGE 70 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 71 HONDA GX340K1EDE2 ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PART NO. PART NAME QTY. REMARKS 19511ZE3000 FAN, COOLING 31100ZE3712 FLYWHEEL, LAMP 90201ZE3V00 NUT, SPECIAL 16MM 90741ZE2000 KEY, SPECIAL WOODRUFF (25X18) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 71...
  • Page 72 HONDA GX340K1EDE2 ENGINE — IGNITION COIL ASSY. IGNITION COIL ASSY. PAGE 72 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 73 GROMMET, WIRE 36101ZE3800 WIRE, STOP SWITCH (470MM) 36103ZE1000 HOLDER, STOP SWITCH WIRE 90012888000 BOLT, FLANGE (6X40) 90013883000 BOLT, FLANGE (6X12) (CT200) 90015883000 BOOT, FLANGE (6X28) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 73...
  • Page 74 HONDA GX340K1EDE2 ENGINE — PISTON ASSY. PISTON ASSY. PAGE 74 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)

  • Page 75: Piston Assembly

    PISTON (STD) 13111ZF6000 PIN, PISTON 13200ZE3010 ROD ASSY., CONNECTING (STD) ..... 1 ..INCLUDES ITEMS W/ 90001ZE8000 BOLT, CONNECTING ROD 90601ZE3000 CLIP, PISTON PIN (20MM) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 75...
  • Page 76 HONDA GX340K1EDE2 ENGINE — RECOIL STARTER ASSY. RECOIL STARTER ASSY. PAGE 76 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 77 RETAINER, SPRING 28445ZE2W01 HOLDER, SPRING 28461ZE2W02 GRIP, STARTER 08560ZG92111 ROPE, RECOIL STARTER ........1 ..REPLACES P/N 28462ZE3W01 90004ZE2W01 SCREW, CENTER 90008ZE2003 BOLT, FLANGE (6X10) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 77...
  • Page 78 HONDA GX340K1EDE2 ENGINE — SOLENOID ASSY. SOLENOID ASSY. PAGE 78 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 79 PART NO. PART NAME QTY. REMARKS 16268893000 SPRING, CHOKE RETURN 17850ZD1E30 LEVER, THROTTLE 36160ZB4003 SOLENOID ASSY. 90013883000 BOLT, FLANGE (6X12) (CT200) 93500050080A SCREW, PAN (5X8) GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 79...
  • Page 80 HONDA GX340K1EDE2 ENGINE — LABELS ASSY. LABELS ASSY. PAGE 80 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 81 HONDA GX340K1EDE2 ENGINE — LABELS ASSY. LABELS ASSY. PART NO. PART NAME QTY. REMARKS 87521ZE3W01 EMBLEM 87528898620 MARK, CHOKE 87533ZC0630 MARK, AIR CLEANER 87594ZB4A00 MARK, OIL CAUTION GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 81...

  • Page 82: Terms And Conditions Of Sale - Parts

    Multiquip’s designated receiving point. at the time of any price change. PAGE 82 — GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05)
  • Page 83 NOTE PAGE GA-6H/GA-6HA A.C. GENERATORS — OPERATION & PARTS MANUAL — REV. #0 (06/02/05) — PAGE 83...
  • Page 84 800-421-1244 310-537-3700 TECHNICAL ASSISTANCE FAX: 310-631-5032 800-478-1244 WARRANTY DEPARTMENT 800-421-1244, EXT. 279 FAX: 310-537-1173 310-537-3700, EXT. 279 Your Local Dealer is: MULTIQUIP INC..18910 WILMINGTON AVE. CARSON, CALIFORNIA 90746 800-421-1244 • 310-537-3700 FAX: 310-537-3927 E-mail:mq@multiquip.com Internet:multiquip.com...
