Specifications (Generator) - MULTIQUIP GA3.6HR Operating Manual

Model
Type
Excitation
AC generator
Speed
Cooling System
Fuel Capacity
Continuous Power Output
Max Power Output
Rated Voltage
Current Max/Continuous (120V)
60 hz AC power
source
Current Max/Continuous (240V)
Phase
Frequency
Power Factor
dimensions
(l x W x h)
dry Net Weight
pAgE 12 — ga3.6HR 60 hz gENERATOR• OpERATiON ANd pARTs mANuAl — REv. #0 (09/17/14)

SPECIFICATIONS (GENERATOR)

Table 1. specifications (generator)
NOTICE
In keeping with Multiquip's policy of constantly
improving its products, the specifications quoted herein
are subject to change without prior notice.
GA3.6HR
Brushless Revolving Field Type
Solid State, Statically Excited System
3,600 RPM
Self-Ventilation
5 gallons (19 liters)
3.2 kW
3.6 kW
120/240V
30/26.7 amps
15/13.3 amps
Single Phase (4 wire)
60 Hz
1
28.0 x 30.9 X 29.7 in.
(710 X 785 X 755 mm)
196 lbs. (89 kg.)
