Specifications and options

Tone generator system: MMT (Multiple Modeling Technology)
• Programs:
Number of timbres: maximum 2 (when using Layer, Split, or Multi)
Maximum polyphony: 8 voices
Structure:
Synth:
2 oscillators + noise generator
Oscillator1:
Wave: 8 Types: Sawtooth, Pulse, Triangle, Sine, Formant,
Noise, DWGS, Audio In
Modulation: Waveform, Cross, Unison, VPM
Oscillator2:
Wave: 4 Types: Sawtooth, Square, Triangle, Sine
Modulation: Ring, Sync, Rng+Sync
Wave Shape:
Type: Drive, Decimator, HardClip, OctSaw, MultiTri,
MultiSin, SubOSCSaw, SubOSCSqu, SubOSCTri,
SubOSCSin, Pickup, LevelBoost
Multimode filters:
Filter1: -24 dB/oct LPF – -12 dB/oct LPF – -12 dB/oct BPF –
-12 dB/oct HPF – Thru
Filter2: LPF, HPF, BPF, COMB
EG1, EG2, EG3, LFO1, LFO2
Vocoder: 16 channel vocoder, adjustable level and pan for each chan-
nel, Formant Shift function, Formant motion function,
Formant hold function
Keyboard:
37 notes (full size keys, velocity sensitive, no aftertouch)
Effects:
Timbre: 2 band EQ, Insert effect (per timbre)
Program: Master effect
Arpeggiator: Six Types: UP, DOWN, ALT1/2, Random, Trigger, Individual step
on/off function
Programs: 128 programs (16 banks x 8 programs), 16 formant motion data sets (7.5
second x 16)
Inputs
• [AUDIO INPUT 1] jack (with MIC/LINE switch) –Rear panel
Connector: 1/4" phone jack (unbalanced)
• MIC/LINE switch: LINE
Input impedance: 600 [ ]
Maximum input level: –10 [dBu] (AUDIO INPUT1 knob: Max)
• MIC/LINE switch: MIC
Input impedance: 600 [ ]
Maximum input level: –33 [dBu] (AUDIO INPUT1 knob: Max)
• AUDIO INPUT 1 [MIC] jack – Front panel
Connector: XLR jack (balanced)
Input impedance: 600 [ ]
Maximum input level: –33 [dBu] (AUDIO INPUT1 knob: Max)
• [AUDIO INPUT 2] jack
Connector: 1/4" phone jack (unbalanced)
Input impedance: 600 [ ]
Maximum input level: –10 [dBu] (AUDIO INPUT1 knob: Max)
Outputs
• [L/MONO, R] jacks
Connector: 1/4" phone jack (unbalanced)
Output impedance: 1.1 [k ] (MONO: 550 )
Maximum output level: +7.5 [dBu] or more
Load impedance: 10 [k ] or mor e
• [PHONES] jack
Connector: 1/4" phone stereo jack
Output impedance: 10 [ ]
Maximum output level: 35 [mW]
Load impedance: 33 [ ]
Foot switch: ASSIGNABLE [SW] jack, ASSIGNABLE [PEDAL] jack
MIDI: IN, OUT, THRU connectors,
USB: B connector
Display:
Main display: 8-charactors x 2 line LCD module
Sub display x4: 8-charactors x 1 line LCD module
Power supply: DC12V, 6.5 W
Dimensions: 635 x 270 x 76 mm / Inches: 25.00" x 10.63" x 2.99" (W x D x H)
Weight: 2.8kg / 6.17 lbs.
Included items: Gooseneck microphone, AC adaptor (DC12V), CD-ROM
Options: EXP–2 foot controller, XVP–10 EXP/VOL pedal, PS–1 pedal switch
*
Appearance and specifications of this product are subject to change without
notice.
