Back Panel I/O Port
Internal I/O
Mechanical & Environment
Power Type
Operating Temp.
Operating Humidity
Size (L x W)
Specifications are subject to change without notice.
6 IX945GSE2 User's Manual
1 *PS/2 Keyboard , 1 *PS/2 Mouse , 1 * VGA port
2 * COM Port , 2 * RJ45 port , 4 * USB 2.0/1.1 , 1 * Audio Jack (3 ports)
2 * Power COM port, 1 * 4-in-1 COM port , 1 * 20-pin ATX power connector, 1 *
CPU fan connector, 1 * Chassis fan connector, 1 * USB header supports
additional 2 USB ports, 1 * 18/24bit LVDS connector , 1 * LVDS inventor
connector, 1 * IDE connector, 2 * SATA connectors, 1 * Digital IO header, 1 *
Front panel header,1 * S/PDIF Out header, 1 * Audio Amplifier header(optional),
1 * Front audio header, 1 * Mini-PCI Express , 1 * PS/2 KB&MS header
ATX mode
0 ~ 60℃ (32 ~ 140℉)
0%~90% relative humidity, non-condensing
170 mm x 170 mm
