2.3.6 Power Management Setup

The power management setup controls the single board computer's "green" features to
save power. The following screen shows the manufacturer's defaults.
2.3.6.1

PCI Express PME

The choices are "Enabled" and "Disabled".
2.3.6.2

ACPI Function

The choices are "Enabled" and "Disabled".
2.3.6.3

ACPI Suspend Type

This item allows you to set ACPI suspend type to S1/POS(Power On Suspend),
S3/STR(Suspend To RAM) , S1&S3 .
2.3.6.4

Run VGABIOS if S3 Resume

Select "Auto" to run VGA BIOS if S3 resume automatically. The "Yes" enables running VGA
BIOS if S3 resume. The "No" disables this function.
2.3.6.5

Power Management

There are three selections for Power Management, and each of them has fixed mode
settings.
Item
Min. Saving
Max. Saving
User Defined
Minimum power management, HDD Power Down = 15 Min
Maximum power management, HDD Power Down =1 Min
Allows you to set each mode individually. When not disabled, each
of the ranges are from 1 min. to 1 hr. except for HDD Power Down
Description
