2.3.6.6
Video Off Method
Use this to select the method to turn off the video. The choices are "Blank Screen", "V/H
SYNC+ Blank", and "DPMS".
2.3.6.7
Video Off In Suspend
When the system is in suspend mode, the video will turn off. The choices are "No" and
"Yes".
2.3.6.8
Suspend Type
Setting is "Stop Grant" and "PwrOn Suspend"
2.3.6.9
Modem Use IRQ
Setting is "NA , 3 , 4, 5, 7, 9 , 10 ,11
2.3.6.10 Suspend Mode
Setting is "Disable" and 1,2,4,8,12,20,30min and etc.
2.3.6.11 HDD Power Down
Setting is "Disable" and 1,2,3,4,5,6,7min and etc.
2.3.6.12 Soft-Off by PWR-BTTN
If you choose "Instant-Off", then pushing the ATX soft power switch but- ton once will switch
the system to "system off" power mode. You can choose "Delay 4 sec". If you do, then
pushing the button for more than 4 seconds will turn off the system, whereas pushing the
button momentarily (for less than 4 seconds) will switch the system to "suspend" mode.
2.3.6.13 Wake-up by PCI Card
The choices are "Enabled" and "Disabled".
2.3.6.14 Power On by Ring
The choices are "Enabled" and "Disabled".
2.3.6.15 USB KB Wake-up From S3
The choices are "Enabled" and "Disabled".
2.3.6.16 Resume by Alarm
When Enabled, your can set the date and time at which the RTC (real-time clock) alarm
awakens the system from Suspend mode.
44
IX945GSE2 User's Manual
which ranges from 1 min. to 15 min. and disable.
