Parts List - Icom IC-718 Service Manual Addendum

January 2013
SECTION 5.
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1110004080 S.IC UPC2709T-E3
IC1701 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC1751 1110002700 S.IC NJM2904M-TE1-#FMZB
IC2001 1110004870 S.IC TA4101F (TE12L.F)
IC2101 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC2102 1130006221 S.IC TC4W53FU(TE12L,F)
IC2201 1140005281 S.IC UPC5023GS-077-E1-A
IC2301 1110004840 S.IC NJM1496V-TE1-#ZZZB
IC2351 1110002700 S.IC NJM2904M-TE1-#FMZB
IC2701 1110003300 S.IC M5282FP 70CD
IC2702 1110007850 S.IC TA7368PL-R10-R <SLVJ>
IC2801 1130004201 S.IC TC4S66F(TE85R,F)
IC2901 1110003091 IC LA4425A-E
IC3001 1130007700 S.IC BU4094BCF-E2
IC3002 1160000132 S.IC TD62783AFG(O,S,EL)
IC3003 1160000132 S.IC TD62783AFG(O,S,EL)
IC3004 1130007700 S.IC BU4094BCF-E2
IC3005 1160000132 S.IC TD62783AFG(O,S,EL)
IC3006 1130007700 S.IC BU4094BCF-E2
IC3301 1110004310 S.IC M62352GP 75EC
IC3401 1110002031 IC TA7808S(Q)
IC3501 1110001401 S.IC UPC1555G2-E1-A
Q101 1580000751 S.FET 3SK294(TE85L,F)
Q102 1580000751 S.FET 3SK294(TE85L,F)
Q151 1560001420 S.FET 2SK882-GR T5LICOMF
Q201 1530003340 S.TRA 2SC3357-T1 RF
Q501 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q502 1560001420 S.FET 2SK882-GR T5LICOMF
Q503 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q511 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q701 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q1001 1510000510 S.TRA 2SA1576A T106R
Q1002 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q1101 1560000641 S.FET 2SK1740-4/5-TB-E
Q1102 1560000641 S.FET 2SK1740-4/5-TB-E
Q1103 1560000641 S.FET 2SK1740-4/5-TB-E
Q1104 1560000641 S.FET 2SK1740-4/5-TB-E
Q1201 1580000751 S.FET 3SK294(TE85L,F)
Q1301 1580000751 S.FET 3SK294(TE85L,F)
Q1401 1560000721 S.FET 2SK2171-4-TD-E
Q1402 1560000721 S.FET 2SK2171-4-TD-E
Q1501 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1502 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1503 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1504 1530004140 S.TRA L2SC4081RT1G <SLVJ>
Q1505 1510000510 S.TRA 2SA1576A T106R
Q1506 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q1507 1530004140 S.TRA L2SC4081RT1G <SLVJ>
Q1508 1530004140 S.TRA L2SC4081RT1G <SLVJ>
Q1509 1590004310 S.TRA LDTA114EET1G <SLVJ>
Q1601 1530004140 S.TRA L2SC4081RT1G <SLVJ>
Q1602 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1603 1580000751 S.FET 3SK294(TE85L,F)
Q1611 1530004140 S.TRA L2SC4081RT1G <SLVJ>
Q1703 1510000510 S.TRA 2SA1576A T106R
Q1705 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q1706 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q1801 1590004840 S.TRA MUN5316DW1T1G
Q1802 1590004840 S.TRA MUN5316DW1T1G
Q1803 1590004840 S.TRA MUN5316DW1T1G
Q1805 1530004140 S.TRA L2SC4081RT1G <SLVJ>
Q2302 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q2381 1530004140 S.TRA L2SC4081RT1G <SLVJ>
Q2383 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q2384 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q3101 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q3601 1540000550 S.TRA 2SD1664 T100Q
Q3701 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q3702 1590004310 S.TRA LDTA114EET1G <SLVJ>
Q3801 1590004060 S.TRA LDTC114EET1G <SLVJ>
Q3802 1590004310 S.TRA LDTA114EET1G <SLVJ>
Q4601 1530004210 S.TRA DSC7004S0L
Q4801 1590004060 S.TRA LDTC114EET1G <SLVJ>
D201 1790000620 S.DIO MA77(TX)
D202 1790000620 S.DIO MA77(TX)
D301 1790000620 S.DIO MA77(TX)
D302 1790000620 S.DIO MA77(TX)
D303 1790000620 S.DIO MA77(TX)
D304 1790000620 S.DIO MA77(TX)
D305 1790000620 S.DIO MA77(TX)
D306 1790000620 S.DIO MA77(TX)
D401 1750000431 S.DIO HSB88WSTR-E
D501 1160000070 S.DIO DAN202K T146
D502 1750002020 S.DIO DA2S10100L
D503 1160000070 S.DIO DAN202K T146
D601 1160000080 S.DIO DAP202K T146
D602 1160000070 S.DIO DAN202K T146
D603 1160000080 S.DIO DAP202K T146
D604 1160000070 S.DIO DAN202K T146
D605 1160000080 S.DIO DAP202K T146
D606 1160000070 S.DIO DAN202K T146
D607 1160000080 S.DIO DAP202K T146
D608 1160000070 S.DIO DAN202K T146
D701 1750002750 S.DIO RN142S TE61
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.

PARTS LIST

DESCRIPTION
[MAIN UNIT]
REF ORDER
NO. NO.
D702 1750002750 S.DIO RN142S TE61
D801 1750002750 S.DIO RN142S TE61
D802 1750002750 S.DIO RN142S TE61
D803 1790000620 S.DIO MA77(TX)
D804 1790000620 S.DIO MA77(TX)
D805 1790000620 S.DIO MA77(TX)
D806 1790000620 S.DIO MA77(TX)
D807 1790000620 S.DIO MA77(TX)
D808 1790000620 S.DIO MA77(TX)
D809 1790000620 S.DIO MA77(TX)
D810 1790000620 S.DIO MA77(TX)
D811 1790000620 S.DIO MA77(TX)
D812 1790000620 S.DIO MA77(TX)
D813 1790000620 S.DIO MA77(TX)
D814 1790000620 S.DIO MA77(TX)
D815 1790000620 S.DIO MA77(TX)
D816 1790000620 S.DIO MA77(TX)
D821 1750002750 S.DIO RN142S TE61
D822 1750002750 S.DIO RN142S TE61
D901 1790000620 S.DIO MA77(TX)
D902 1790000620 S.DIO MA77(TX)
D903 1790000620 S.DIO MA77(TX)
D904 1790000620 S.DIO MA77(TX)
D1301 1790000620 S.DIO MA77(TX)
D1302 1790000620 S.DIO MA77(TX)
D1501 1750001210 S.DIO HSB88ASTR-E
D1503 1750002020 S.DIO DA2S10100L
D1510 1750002020 S.DIO DA2S10100L
D1631 1160000070 S.DIO DAN202K T146
D1632 1790000620 S.DIO MA77(TX)
D1701 1730002451 S.ZEN MAZ8043GHL
D1702 1750001980 S.ZEN DZ2J056M0L
D1703 1750002020 S.DIO DA2S10100L
D1704 1160000080 S.DIO DAP202K T146
D1705 1160000080 S.DIO DAP202K T146
D1706 1750002020 S.DIO DA2S10100L
D1707 1750002020 S.DIO DA2S10100L
D1801 1750001210 S.DIO HSB88ASTR-E
D1802 1750002020 S.DIO DA2S10100L
D1803 1750001210 S.DIO HSB88ASTR-E
D1901 1750001210 S.DIO HSB88ASTR-E
D2101 1750002020 S.DIO DA2S10100L
D2201 1750000370 S.DIO DA221 TL
D2202 1750000370 S.DIO DA221 TL
D2301 1750002020 S.DIO DA2S10100L
D2381 1750001210 S.DIO HSB88ASTR-E
D2701 1160000080 S.DIO DAP202K T146
D3001 1160000070 S.DIO DAN202K T146
D3002 1160000070 S.DIO DAN202K T146
D3502 1750000370 S.DIO DA221 TL
D3503 1730002830 S.ZEN DZ2J051M0L
D3701 1160000070 S.DIO DAN202K T146
D4220 1790001241 S.DIO MA2S7280GL
D4801 1750002020 S.DIO DA2S10100L
FI301 2010002470 XTA 64M15B1 64.45500 MHz (FL-315)
FI611 2020000210 CER CFJ455K5 (FL-65)
FI1301 2020001330 CER CFWLA455KHFA-B0 (CFWS455HT)
L1 6200003261 S.COI NLV32T-101J
L2 6200003001 S.COI NLV32T-R22J
L100 6200004790 S.COI MLF1608D R47K-T
L101 6200003001 S.COI NLV32T-R22J
L102 6200003011 S.COI NLV32T-R27J
L103 6200001851 S.COI NLV32T-5R6J
L104 6200003261 S.COI NLV32T-101J
L105 6140003210 S.COI LR-358
L106 6150004270 COI LS-483A (C-14924)
L151 6150004280 COI LS-484B (C-14927)
L152 6200003261 S.COI NLV32T-101J
L153 6200003550 S.COI MLF1608A 4R7K-T
L201 6200001831 S.COI NLV32T-100J
L202 6200003001 S.COI NLV32T-R22J
L301 6150005110 COI LS-540
L302 6150004270 COI LS-483A (C-14924)
L303 6150005110 COI LS-540
L401 6140003210 S.COI LR-358
L402 6140003530 COI LR-395
L501 6150005420 COI LS-554 7QM
L701 6200003261 S.COI NLV32T-101J
L702 6200003261 S.COI NLV32T-101J
L703 6200003261 S.COI NLV32T-101J
L801 6200003261 S.COI NLV32T-101J
L802 6200012670 S.COI LB3218T331K
L811 6200002961 S.COI NLV32T-4R7J
L812 6200003321 S.COI NLV32T-3R3J
L813 6200003261 S.COI NLV32T-101J
L814 6200003261 S.COI NLV32T-101J
L821 6200001851 S.COI NLV32T-5R6J
L822 6200003111 S.COI NLV32T-6R8J
L831 6200003261 S.COI NLV32T-101J
L832 6200003091 S.COI NLV32T-2R7J
L833 6200003101 S.COI NLV32T-3R9J
L835 6200002961 S.COI NLV32T-4R7J
L836 6200001851 S.COI NLV32T-5R6J
L841 6200003261 S.COI NLV32T-101J
1
DESCRIPTION
S.=Surface mount
